Edelbrock PERFORMER-PLUS 2182 Installation Instructions

• PLEASE study these instructions carefully before installing your new camshaft. If you have any questions or problems, do not hesitate to call our
Technical Hotline at: 1-800-416-8628.
• CAMSHAFT: Edelbrock Performer-Plus camshafts are ground specifically for use with the corresponding Performer manifold. The Performer
manifold #2181 or #3781, and Performer-Plus camshaft #2182, are designed to work as a team to give you better driveability and performance.
They are dyno-matched and street-proven. For best results, use the Edelbrock manifold/camshaft package with the carburetor and headers we
recommend.
NOTE: Maximum performance is achieved when packages are used with a 4-bbl carburetor and headers, however packages may be used with
any of the following equipment:
• manifold/camshaft package only
• 1-5/8" headers
• IMPORTANT: This instruction sheet provides general installation guidelines which can affect your warranty. Read it carefully. It is not our intent to
cover each detail of installation here; a step-by-step procedure manual would be far too lengthy. We want to caution you that installing a camshaft
is a complicated procedure that requires a good general knowledge of automotive engines. If you are not confident that you can complete the
camshaft installation successfully, we suggest you consider having it installed by an experienced mechanic.
CAUTION: Improper installation will result in LOW MILEAGE, POOR PERFORMANCE, COSTLY RE-INSTALLATION, and ENGINE DAMAGE. TO AVOID
THESE PROBLEMS YOU MUST DO THE FOLLOWING: Carefully study and understand all instructions. Examine the camshaft for possible shipping
damage (if damaged contact you dealer immediately).
TOOLS AND EQUIPMENT
• box and open-end wrenches
• socket set
• distributor wrench
• pliers (channel locks & hose clamp)
• screw drivers (regular and phillips)
• torque wrench
• hammer
• gasket scraper or putty knife
• timing light
• vacuum gauge
• rags
• water bucket
• harmonic balancer puller
• gear puller for crankshaft sprocket
• INSTRUCTIONS FOR ENGINE PARTS REMOVAL BEFORE CAMSHAFT INSTALLATION
1. Disconnect battery.
2. For ease of installation, keep all parts in some sort of order.
WARNING: Do not remove radiator cap or radiator hose if engine is
hot.
3. Drain radiator coolant, move fan shroud back and remove fan and
spacer from water pump. On air conditioned vehicles, remove lower
idler pulley and compressor-to- water pump mount. Disconnect
hoses and brackets. NOTE: Do not disconnect a/c hoses unless
necessary. Before disconnecting hoses, a/c system must be
evacuated by an authorized repair center. Most vehicles will require
radiator removal prior to cam removal. Remove water pump.
4. Disconnect all linkage from carburetor such as throttle, throttle
springs, transmission, cruise control and automatic choke.
5. Tag and remove vacuum lines.
©2008 Edelbrock Corp.
®
PREPARATION CHECKLIST
Use the following checklist for items needed.
• aftermarket carburetor specified in instructions and catalog
• aftermarket/re-curved distributors
HARDWARE & PARTS TO BUY
• pipe plugs, if needed
• Edelbrock Gasgacinch, #9300
• RTV Silicone Gasket Sealant
• chalk
• paper and pencil
• radiator coolant
• teflon tape
• Edelbrock Performer-Link True Rolling Timing Chain and Gear
Set #7811 or #7820
• Edelbrock Sure Seat Valve Springs, #5882 (non-rotators)
or #5982 (rotators)
• Intake gasket set-Fel-Pro Printoseal or OE replacement
• front cover oil seal- OEM or equivalent
• Manifold bolt kit #8584
6. Remove valve covers.
7. Remove distributor cap and wires, rotate engine until rotor points
towards number 1 terminal in cap and pointer on front cover is on Top
Dead Center (TDC) and remove distributor. Note the approximate
position of the vacuum advance canister in relation to the manifold to
assist in getting the distributor properly located during re-installation.
8. Remove carburetor and intake manifold. Remove fuel pump.
9. Remove rocker arms and pushrods.
CAUTION: If your engine has non-adjustable rocker arms (1969-1/2 or
later), care must be taken to keep the pushrods and rocker arms in
proper order, as they may be different lengths.
10. Remove hydraulic valve lifters.
11. Remove crankshaft pulley and, using a suitable puller, crankshaft
dampener.
PERFORMER-PLUS
Camshaft/Lifters/Lube Kit
CATALOG #2182
MODEL: 351-Windsor Ford V8
Rev. 9/08 - AJ/mc
Brochure #63-2182
