- Page 1 OWNER’S INSTRUCTIONS Indoor Unit Outdoor Unit SC05ZA8 SC05ZA8X SC05ZB8 SC05ZB8X Split-type Room Air Conditioner (Cool) E R DB98-07878A(1)
-
Page 2: Safety Precautions
Safety Precautions The following safety precautions must be taken when using your air conditioner. Make sure that the indoor unit is correctly ventilated at all times; do NOT place clothing or other materials over it. NEVER spill liquid of any kind into the indoor unit. Should this happen, switch off the breaker used for your air conditioner and contact your installation specialist. -
Page 3: Table Of Contents
Contents REPARING YOUR AIR CONDITIONER Safety Precautions ....... . View of the Unit ........Remote Control-Buttons and Display . -
Page 4: View Of The Unit
View of the Unit Indoor Unit SC05ZA8 Air flow blades (outlet) Air inlet Air filter(under the grille) Remote control sensor Timer indicator On/Off button & (yellow) operating indicator (orange) Indoor Unit SC05ZB8 Air flow blades (outlet) Air inlet Air filter(under the grille) Remote control sensor Timer indicator On/Off button &... -
Page 5: Outdoor Unit
Outdoor Unit Air Inlet(Rear) Air Outlet Connection Valve (Inside) -
Page 6: Remote Control-Buttons And Display
Remote Control - Buttons and Display Remote control transmission indicator Mode selection button Operating mode (AUTO, COOL, DRY, FAN) AUTO, COOL, DRY, FAN) Temperature adjustment Temperature setting buttons Turbo mode Turbo/Sleep mode Sleep mode selection button Fan speed Fan speed adjustment button Air flow direction Swing button... -
Page 7: Getting Started
etting Started You have just purchased a split type air conditioner and it has been installed by your installation specialist. Your Owner’s Instructions contains valuable information on using your air conditioner. Please take the time to read it as it will help you take full advantage of the unit’s features. -
Page 8: Inserting The Remote Control Batteries
Inserting the Remote Control Batteries You must insert or replace the remote control batteries when : You purchase the air conditioner The remote control does not work correctly Use two AAA, LR03 1.5V batteries. Do not use old batteries or different kinds of batteries together. Batteries may be completely discharged after 12 months, even if they have not actually been used. -
Page 9: Selecting The Automatic Operating Mode
Selecting the Automatic Operating Mode You can start the air conditioner in Automatic mode from your remote control. In the Automatic mode, the standard temperature and the opti- mum fan speed is selected automatically. You can adjust the standard temperature but not the fan speed. If necessary, press the (On/Off) button. -
Page 10: Cooling Your Room
Cooling Your Room You must select the Cool mode if you wish to adjust the: Cooling temperature Fan speed when cooling If necessary, press the (On/Off) button. Result: The operating indicator on the indoor unit comes on. The air conditioner starts up in the mode selected when the unit was last used. -
Page 11: Changing The Room Temperature Quickly
Changing the Room Temperature Quickly The Turbo cooling function is used to cool your room as quickly as possible. You have just come home and find that the room is very hot. You wish to cool it down as quickly as possible. The Turbo function operates for 30 minutes with the maximum settings before returning automatically to the mode and temperature previously selected. -
Page 12: Removing Excess Humidity
Removing Excess Humidity If the atmosphere in your room is very humid or damp, you can remove excess humidity without lowering the room temperature too much. If necessary, press the (On/Off) button. Result: The operating indicator on the indoor unit comes on. The air conditioner starts up in the mode selected when the unit was last used. -
Page 13: Airing Your Room
Airing Your Room If the atmosphere in your room is stale, you can air the room using the Fan feature. If necessary, press the (On/Off) button. Result: The operating indicator on the indoor unit comes on. The air conditioner starts up in the mode selected when the unit was last used. -
Page 14: Adjusting The Air Flow Direction Vertically
Adjusting the Air Flow Direction Vertically Depending on the position of the indoor unit on the wall of your room, you can adjust the position of the outer air flow blade on the bottom of the unit, thus increasing the efficiency of the air conditioner. Press the SWING button one or more times as required. -
Page 15: Adjusting The Air Flow Direction Horizontally
Adjusting the Air Flow Direction Horizontally There are two sets of inner air flow blades. Just as the outer air flow blade can be adjusted vertically, the inner blades can be adjusted horizontally. Adjust each set of inner blades to the required position, by pushing or pulling them sideways. -
Page 16: Setting The On Timer
Setting the On Timer The On Timer enables you to switch on the air conditioner automatically after a given period of time. You can set the period of time from 30 minutes to 24 hours. To set the operating time, press the ON TIMER button one or more times until the required time is displayed. -
Page 17: Setting The Off Timer
Setting the Off Timer The Off Timer enables you to switch off the air conditioner automatically after a given period of time. You can set the period of time from 30 minutes to 24 hours. To set the operating time, press the OFF TIMER button one or more times until the required time is displayed. -
Page 18: Setting The Sleep Timer
Setting the Sleep Timer The Sleep Timer can be used when you are cooling your room to switch the air conditioner off automatically after a period of six hours. If you wish to switch the unit off at a specific time, refer to page 17. -
Page 19: Operating Recommendations
Operating Recommendations Here is a recommendation that you should follow when using your air conditioner. Topic Recommendation Power failure If a power failure occurs when the air conditioner is operating, the unit is switched off. When the power returns, the air conditioner starts up again automatically. -
Page 20: Temperature And Humidity Ranges
Temperature and Humidity Ranges The following table indicates the temperature and humidity ranges within which the air conditioner can be used. If the air conditioner is used at... Then... High temperatures The automatic protection feature may be triggered and the air conditioner stopped. Low temperatures A water leak or some other malfunction may occur if the heat exchanger freezes. -
Page 21: Solving Common Problems
Solving Common Problems Before contacting the after-sales service, perform the following simple checks. They may save you the time and expense of an unnecessary call. Problem Explanation/Solution The air conditioner does not Check that the breaker used for the air conditioner is switched on. operate at all Check that the operating indicator on the indoor unit is on;... -
Page 22: Installing A Filter (Option)
Installing a Filter (Option) The air conditioner can be fitted with a deodorizing and Bio-Pure fil- ter to remove minute dust particles or odours. The service life of the filter is approximately three months depending on the time during which the air conditioner is used. Remove the vinyl packing from the filter. -
Page 23: Technical Specifications
Technical Specifications Model Indoor unit Power Supply SC05ZA8 220-240V~, 50Hz SC05ZB8... - Page 24 THIS AIR CONDITIONER IS MANUFACTURED BY: ELECTRONICS Printed in Korea...
