Your sander has been engineered and manufactured to our high standard for dependability, ease of operation, and operator
safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
18 VOLT RANDOM ORBIT SANDER
P410
BATTERIES AND CHARGERS
SOLD SEPARATELY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P410 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ryobi P410

  • Page 1 OPERATOR’S MANUAL 18 VOLT RANDOM ORBIT SANDER P410 BATTERIES AND CHARGERS SOLD SEPARATELY Your sander has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
  • Page 2: Table Of Contents

    The replacement power tool will be covered by the limited warranty for the balance of the two year period from the date of the original purchase. WHAT THIS WARRANTY COVERS: This warranty covers all defects in workmanship or materials in your RYOBI power ®...
  • Page 3: General Safety Rules

     Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool MODEL BATTERY PACK (P100) CHARGER (P110) or these instructions to operate the power tool. Power P410 130255004 1423701, 140237023 tools are dangerous in the hands of untrained users. or 130224028 or 140237021 ...
  • Page 4: Specific Safety Rules

    GENERAL SAFETY RULES  Use the power tool, accessories and tool bits etc., in connection from one terminal to another. Shorting the accordance with these instructions and in the manner battery terminals together may cause burns or a fire. intended for the particular type of power tool, taking ...
  • Page 5: Safety Rules For Charger

    SAFETY RULES FOR CHARGER  An extension cord should not be used unless WARNING! absolutely necessary. Use of improper extension cord could result in a risk of fire and electric shock. If extension READ AND UNDERSTAND ALL INSTRUCTIONS. cord must be used, make sure: Failure to follow all instructions listed below, may result in a.
  • Page 6: Symbols

    SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second)
  • Page 7 If you servicing, use only identical replacement parts. do not understand the warnings and instructions in the operator’s manual, do not use this product. Call Ryobi customer service for assistance. WARNING: The operation of any power tool can result in foreign objects being thrown into your eyes, which can result in severe eye damage.
  • Page 8: Features

    FEATURES PRODUCT SPECIFICATIONS Charger Input ........120 V, 60 Hz, AC only Orbit Diameter ............1/16 in. Charge Rate ..............1 hour Motor ..............18 Volt DC No Load Speed ........10,000 r/min. (RPM) ON ( I ) / OFF ( O ) SWITCH HOOK-AND-LOOP SANDING DISCS Fig.
  • Page 9: Assembly

    FEATURES KNOW YOUR SANDER ORBITAL SANDING ACTION See Figure 1. The oscillating action of your sander produces a very quick, The safe use of this product requires an understanding of the small circular motion of the sanding pad. The motion is ideal information on the product and in this operator’s manual as for producing a fine finished grain.
  • Page 10: Operation

    OPERATION NOTE: Batteries will not reach full charge the first time they WARNING: are charged. Allow several cycles (operation followed by recharging) for them to become fully charged. Do not allow familiarity with products to make you CHARGING A COOL BATTERY PACK careless.
  • Page 11 OPERATION CHARGING A HOT BATTERY PACK P100 BATTERY When using the product continuously, the batteries in the P110 PACK battery pack will become hot. You should let a hot battery pack CHARGER cool down for approximately 30 minutes before attempting to recharge.
  • Page 12 OPERATION TO INSTALL BATTERY PACK DEPRESS LATCHES TO BATTERY See Figure 4. RELEASE BATTERY PACK PACK  Place the battery pack on the tool.  Make sure the latches on each side of the battery pack snap into place and the battery pack is secured on the tool before beginning operation.
  • Page 13 OPERATION OPERATING THE SANDER See Figure 6.  Secure the workpiece to prevent it from moving during operation. WARNING: Unsecured workpieces could be thrown towards the operator causing injury. WARNING: Keep your head away from the sander and the sanding area.
  • Page 14: Maintenance

    MAINTENANCE GENERAL MAINTENANCE WARNING: Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of When servicing, use only identical replacement parts. commercial solvents and may be damaged by their use. Use Use of any other parts may create a hazard or cause clean cloths to remove dirt, dust, oil, grease, etc.
  • Page 15 NOTES...
  • Page 16 When ordering repair parts, always give the following information: P410 • MODEL NUMBER • SERIAL NUMBER Ryobi is a registered trademark of Ryobi Limited used under license. ® ONE WORLD TECHNOLOGIES, INC. 1428 Pearman Dairy Road, Anderson, SC 29625 Phone 1-800-525-2579 www.ryobitools.com...
