26" LCD T V 720p

QUICK SETUP GUIDE

DX-26L100A13
Remote control and
two AAA batteries
TV stand and six screws (M4, 16 mm)
WE ARE GOING GREEN!
A copy of your User Guide is not provided
in the box but is available online.
Go to www.dynexproducts.com, then click
Support & Service. Enter your model number
in the Search field, then press Enter.
Click Support/Downloads.

Front features

Menu
Input
Volume +/-
Channel
Power button
Power indicator
Remote
control sensor

Installing the stand

1 Carefully place your TV screen face-down on a cushioned, clean surface to
protect the screen from damage and scratches.
2 Secure the stand to the screen with the six provided screws.

Installing a wall-mount bracket

1 Carefully place your TV screen face-down on a
cushioned, clean surface to protect the screen
from damage and scratches.
2 Remove the four screws that secure the stand
column, then remove the column.
3 Attach the wall-mount bracket to your TV using
the mounting holes on the back of your TV.
See the instructions that came with the
wall-mount bracket for information about
how to correctly hang your TV.
Warning
This apparatus is intended to be supported by a UL Listed wall mount bracket.

Identifying cables

Your TV has several connection types for connecting devices. For the best video quality,
connect a device to the best available connection.
Connection type
Video quality
Cable connector
HDMI video/audio
Best
OR
Better
Component video
and analog audio
OR
Good
Composite video
and analog audio
You can use the HDMI1/DVI jack to connect a DVI device to your TV. You need to attach an
HDMI-to-DVI adapter to the end of the HDMI cable that connects to the DVI device's jack.
Connecting a DVD or Blu-ray player, cable box,
satellite receiver, or game station
Using HDMI (best)
/
Note: Cable is not provided.
Using component cables (better)
COMPONENT
OUT
Note: Cable is not provided.
Using composite cables (good)
AUDIO/VIDEO
OUT
Note: Cable is not provided.
Connecting an antenna/cable wall jack
Note: Cable is not provided.
USB flash drive
Connecting a Home Theater System
Using Digital audio
Note: Cable is not provided.
Using Analog audio
AUDIO IN
Note: Cable is not provided.

Connecting a home theater system with multiple devices

Cable or satellite TV box
Blu-ray player/DVD player/VCR
AV receiver
Game console
or camera
Antenna or
Computer
cable TV
(no box)
COAXIAL
AUDIO IN
We recommend that you connect
the AV receiver's HDMI OUT jack
to one of your TV's HDMI IN jacks.
Then, connect the AV receiver's
DIGITAL AUDIO INPUT jack to
your TV's DIGITAL OUTPUT jack
to route Dolby Digital audio.
