Abit GC-02 User Manual

G u r u C
G u r u C
G u r u C
r d
r d
r d
T h e 3 E y e
T h e 3 E y e
T h e 3 E y e
Easy Installation
PC Power On/Off
H/W Monitor & Warning
Prompt OverClocking
Current Time Indicating
Room Temperature Indicating (10°C~50°C)
MSN Checking
E-Mail Checking
Large LCD Screen (4x7cm)
Guru Linking Cable (1.8m)
4200-0417-02
l o c k
l o c k
l o c k
O n Y o u r P
O n Y o u r P
O n Y o u r P
PC Connection:
The Guru Clock is a hot-swappable device, no needs to power-off your computer to do the connection. All you
have to do is to install the ABIT uGuru Utility first (bundled in the driver-CD) and restart the system before
connecting Guru Clock to your computer. A µGuru icon appears at the lower right of the status bar represents
your system is ready to connect Guru Clock.
This device only works together with top-of-the-rank of ABIT's motherboards equipped with uGuru technology.
DO NOT connect this device with regular USB cable or on any other motherboards.
C
C
C
Rev. 1.01 ABIT Computer Corporation
Attach the end of the linking cable's 5-pin-plug to the
GURU1 header on your ABIT motherboard.
Screw the I/O shield with the linking cable passing
through into any position with empty PCI slot at the
computer's back panel.
Attach the other end of the linking cable to the linking
connector at the back of the Guru Clock, no matter
when the system is on or off.
The Guru Clock is now ready to serve at your fingertips.
Guru Clock
