Bose Lifestyle 135 Operating Manual
Hide thumbs Also See for Lifestyle 135:

Advertisement

L
IFESTYLE
H
E
OME
NTERTAINMENT
L
IFESTYLE
H
E
OME
NTERTAINMENT
L
IFESTYLE
H
OME
Operating Guide | Guía del usuario | Guide d'utilisation
®
235/135
®
V35/V25
®
T20/T10
T
HEATER
S
YSTEMS
S
YSTEMS
S
YSTEMS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lifestyle 135 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bose Lifestyle 135

  • Page 1 ® 235/135 IFESTYLE NTERTAINMENT YSTEMS ® V35/V25 IFESTYLE NTERTAINMENT YSTEMS ® T20/T10 IFESTYLE HEATER YSTEMS Operating Guide | Guía del usuario | Guide d’utilisation...
  • Page 2 Please save this guide for future reference. All Bose products must be used in accordance with local, state, federal, and industry regulations. The lightning flash with arrowhead symbol within an equilateral triangle alerts the user to the presence of uninsulated, dangerous voltage within the system enclosure that may be of sufficient magnitude to constitute a risk of electric shock.
  • Page 3 • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by Bose Corporation could void the user’s authority to operate this equipment. These devices comply with FCC and Industry Canada RF radiation exposure limits set forth for the general population.
  • Page 4 AFETY NFORMATION Applicable only for: ® • LIFESTYLE V25/V35/135/235 home entertainment systems “Made for iPod” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod or iPhone,respectively, and has been certified by the developer to meet Apple performance standards.
  • Page 5: Table Of Contents

    Playing audio/video devices ........Listening to a Bose ®...
  • Page 6 CONTENTS (235/135/V35/V25 ISTENING TO THE ADIO ONLY Selecting the radio ..........Tuning to a station .
  • Page 8: Controls And Indicators

    Numeric Keypad – Allows manual entry of channels and settings TV Input – Changes inputs on your TV *For system delivering sound to another room through Bose ® link OUT (not applicable to systems sold in Japan) 8 – English...
  • Page 9: Navigation Controls

    ONTROLS AND NDICATORS Navigation controls Page Up/Down – Moves to next/previous page MENU – Displays the menu GUIDE – Displays your set top box for a connected device or TV program guide, or Blu-ray Disc™ player popup menu INFO – Displays program EXIT –...
  • Page 10 ONTROLS AND NDICATORS Information display (235/135 and V35/V25 systems only) The display provides operating and system status information. Examples: Source identification Volume Cable Cable Radio tuner iPod iPod 90.9 - WBUR90.9 Album Operating prompt Hold number key to set preset Remote glow button Pressing the glow button on the rear of the remote illuminates the remote buttons (and the display for 235/135 and V35/V25 systems).
  • Page 11: Control Console

    ONTROLS AND NDICATORS Control Console Power light • Red.....System is off (Standby) • Blinking green ..System is starting • Steady green ..System is on and ready to use in the main room or other rooms • Amber....System off and charging iPod or iPhone Front A/V inputs Used for temporarily connecting an audio/video device such as a camcorder.
  • Page 12: Speaker Array (135 Systems Only)

    ONTROLS AND NDICATORS Speaker Array (135 systems only) Status Status indicator: Off ..........Speaker array and Acoustimass ® module are connected Slow blinking orange.....Speaker array is available to make a wireless connection Fast blinking orange......Speaker array is disconnected and trying to connect Solid red.........System error ®...
  • Page 13: Power O N /Off Controls

    OWER FF CONTROLS Starting your system Press the power button on the remote or on the console to start your system. In several seconds the power LED on the console changes from blinking to steady green. The system is now ready to use. You can also start the system in two other ways: Pressing the remote SOURCE button also starts your system and puts the SOURCE menu on your TV screen.
  • Page 14: Operating Your Connected Devices

    When listening to audio sources like iPod, the system will automatically enter Note: screensaver mode in order to prevent the risk of screen burn-in. Press any button on the Bose remote to restore the picture. To disable the screensaver, see “Changing system options” on page 22. ®...
  • Page 15: Watching Tv

    Your TV may be receiving its program content through a set top box or the tuner built into your TV. Note: Since most televisions come with an IR (infrared) remote, you may need to point the Bose ® remote at your TV to operate it.
  • Page 16: Playing Audio/Video Devices

    Connect that system to the Bose link IN connector on the rear panel of the control console. To listen to the Bose link source, press the SOURCE button and select Bose link. Be sure to connect your Bose link device before attempting to select it. It will not appear in the SOURCE list until it is connected.
  • Page 17: Playing An Ipod Or Iphone (235/135 Or V35/V25 Systems Only)

    PERATING ONNECTED EVICES Playing an iPod or iPhone (235/135 or V35/V25 systems only) ® Your LIFESTYLE system can play audio and video from your iPod or iPhone. Be sure to dock your iPod before attempting to select it. It will not appear in the SOURCE list until you dock it.
  • Page 18: Using The Front Console Inputs

    PERATING ONNECTED EVICES Using the front console inputs The front of the console provides analog A/V inputs plus a USB and an HDMI input. These inputs appear in the SOURCE menu as A/V (Front), USB, and HDMI (Front) only when a device is connected. These inputs are provided for temporarily connecting devices such as digital cameras and video cameras.
  • Page 19: Front Analog A/V Input

    You need to use the controls on the device itself or the remote that came with it. Front HDMI™ input You can use this input for devices that have an HDMI output. The Bose remote does not control a device connected to this input. You need to use the controls on the device itself or the remote that came with it.
  • Page 20: Istening To The Adio

    ISTENING TO THE ADIO (235/135/V35/V25 ONLY Selecting the radio 1. Press the SOURCE button. 2. Keep pressing the SOURCE button to select FM or AM in the SOURCE list. Tuning to a station • Press (increase) or (decrease) to tune up or down the frequency band. •...
  • Page 21: More Buttons And System Options

    MORE B UTTONS AND YSTEM PTIONS MORE buttons Press the MORE button to display additional button functions along the top of your TV screen for the current source. The functions that appear depend on the selected source. The following example shows how these buttons appear on your TV.
  • Page 22: Changing System Options

    MORE B UTTONS AND YSTEM PTIONS Button function definitions (continued) Accesses Red, Green, Yellow, or Blue functions on Blu-ray Disc™ players, set-top boxes and Teletext. Accesses the system menu for your set-top box. Accesses A, B, C, or D functions in an interactive program guide.
  • Page 23 MORE B UTTONS AND YSTEM PTIONS 4. Using the up/down ( ) navigation buttons, highlight the option you want to change. 5. Using the left/right ( ) navigation buttons, select the setting. 6. Press the remote EXIT button when done. OPTIONS menu Factory settings are in bold type.
  • Page 24 MORE B UTTONS AND YSTEM PTIONS Option Available Settings System Adjusts bass level: –9 to Normal to +6 (After ADAPTiQ ® calibration) Bass –14 to Normal to 14 (No ADAPTiQ calibration) ® System Adjusts treble level: –9 to Normal to +6 (after ADAPTiQ calibration) Treble –14 to Normal to +14 (no ADAPTiQ calibration)
  • Page 25: Changing Your System Setup

    It helps you to choose the right cables and inputs, and to program the Bose remote to operate your connected devices. After completing the initial setup, you can use the UNIFY system at any time to change your system setup and configuration.
  • Page 26: Adding Sound To Another Room

    • Room codes – The speaker system and the remote in your other room must be set to the same room code. See the owner’s guide that came with the Bose link product for information on setting room codes.
  • Page 27: Are And Aintenance

    Acoustimass module. • (135 systems only) Make sure that the audio input cable is firmly ® plugged into the Audio Out connector (not Bose link) on the control console and the other end is firmly seated into the Console connector on the speaker array.
  • Page 28 ® Sound is marred by a loud • Contact Bose Customer Service to determine if and how other hum or buzz, which may electrical devices in the room may be creating unwanted signals, be electrical in nature (not and to obtain possible remedies.
  • Page 29: Resetting The System

    2. Using the remote navigation buttons, select Update. 3. Follow the instructions on the screen. Note: To make sure your Bose ® remote is updated, hold the remote near the front of the control con- sole while it is being updated.
  • Page 30: Contacting Customer Service

    Bose. Failure to do so will not affect your limited warranty. What you must do to obtain limited warranty service: Return the product, with proof of purchase from an authorized Bose dealer, using the following procedures: 1. Contact the Bose organization in your country/region (visit http://Global.Bose.com/ register for Bose contact information in your country/region) for specific return and shipping instructions, including a Return Authorization Number.
  • Page 31: Technical Information

    ARE AND AINTENANCE 2. Label and ship the product, freight prepaid, to the address provided by the Bose organization in your country. 3. Place any necessary Return Authorization Number prominently on the outside of the carton. Cartons not bearing a Return Authorization Number, where required, will be refused.
  • Page 32 To receive a copy of the source code for the open source software programs included in this product, please mail your written request to: Licensing Manager, Mailstop 6A2, Bose Corporation, The Mountain, Framingham, MA 01701-9168. Bose Corporation will distribute such source code to you on a disc for a charge covering the cost of performing such distribution, such as the cost of media, shipping and handling.
  • Page 33 ARE AND AINTENANCE English – 33...
  • Page 34 2011 Bose Corporation, The Mountain, Framingham, MA 01701-9168 USA AM342774 Rev 00...
