3. Lift the load lever in the direction of the
arrow until the load plate is completely
lifted.
4. Remove the PnP cap from the CPU
socket by lifting the tab only.
5. Position the CPU over the socket,
ensuring that the gold triangle is on the
bottom-left corner of the socket, and
then fit the socket alignment keys into
the CPU notches.
The CPU fits in only one correct
orientation. DO NOT force the CPU
into the socket to prevent bending
the connectors on the socket and
damaging the CPU!
ASUS P8H67-M PRO
Load plate
Gold
triangle
mark
Alignment keys
PnP cap
CPU notches
1-9
