MX520/MX703
Digital Projector
User Manual

Advertisement

Table of Contents
loading

Related Manuals for BenQ MX520

Summary of Contents for BenQ MX520

  • Page 1 MX520/MX703 Digital Projector User Manual...

  • Page 2: Table Of Contents

    Table of contents Important safety Using the teaching templates ....34 Shutting down the projector ....35 instructions ......3 Direct power off........35 Introduction ......7 Menu operation ........36 Projector features........7 Maintenance......46 Shipping contents ........8 Care of the projector......46 Projector exterior view......9 Lamp information ........

  • Page 3: Important Safety Instructions

    Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. Safety Instructions Please read this manual before In some countries, the line voltage is...
  • Page 4 Safety Instructions (Continued) The lamp becomes extremely hot Do not place this product on an during operation. Allow the projector unstable cart, stand, or table. The to cool for approximately 45 minutes product may fall, sustaining serious damage. prior to removing the lamp assembly for replacement.
  • Page 5 Safety Instructions (Continued) Do not place this projector in any of Do not block the ventilation holes. the following environments. - Do not place this projector on a blanket, bedding or any other soft - Space that is poorly ventilated or surface.
  • Page 6 If you intend to mount your projector on the ceiling, we strongly recommend that you use a proper fitting BenQ projector ceiling mount kit and that you ensure it is securely and safely installed.

  • Page 7: Introduction

    3D Function supported Various 3D formats make the 3D function more flexible. By presenting the depth of the images, you can wear BenQ 3D glassed to enjoy the 3D movies, videos and sporting events in a more realistic way. •...

  • Page 8: Shipping Contents

    Shipping contents Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. Standard accessories The supplied accessories will be suitable for your region, and may differ from those illustrated. *The warranty card is only supplied in some specific regions.

  • Page 9: Projector Exterior View

    USB Mini-B port Rear IR remote sensor HDMI-input port RGB signal output jack Rear/lower side RGB (PC)/Component Video (YPbPr/ YCbCr) signal input jack MX520 18 19 S-Video input jack Video input jack Audio (L/R) input jacks Audio input jack Audio output jack...

  • Page 10: Controls And Functions

    Controls and functions Projector MX520 MX703 Focus ring POWER indicator light Adjusts the focus of the projected image. Lights up or flashes when the projector is Zoom ring under operation. 10. AUTO Adjusts the size of the image. LAMP indicator light Automatically determines the best picture timings for the displayed image.

  • Page 11: Remote Control

    Remote control Aspect Selects the display aspect ratio. 10. Page Up/Page Down Operate your display software program (on a connected PC) which responds to page up/ down commands (like Microsoft PowerPoint). 11. Digital Zoom (+, -) Magnifies or reduces the projected picture size. 12.

  • Page 12: Remote Control Effective Range

    Remote control effective range The remote control must be held at an angle within 30 degrees perpendicular to the projector's IR remote control sensor(s) to function correctly. The distance between the remote control and the sensor(s) should not exceed 8 meters (~ 26 feet). Make sure that there are no obstacles between the remote control and the IR sensor(s) on the projector that might obstruct the infra-red beam.

  • Page 13: Positioning Your Projector

    Note that a special rear projection screen portability. and the BenQ Projector Ceiling Mount Kit are required for this installation location. Set Rear Ceiling in the SYSTEM SETUP: Basic > Projector Installation menu after you turn the projector on.

  • Page 14: Obtaining A Preferred Projected Image Size

    Minimum zoom Maximum zoom Screen Center of lens Diagonal Diagonal Vertical offset Projection distance MX520 The screen aspect ratio is 4:3 and the projected picture is 4:3 Screen size Projection distance (mm) Vertical Diagonal distance distance offset...
  • Page 15 All measurements are approximate and may vary from the actual sizes. BenQ recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector in situ before you permanently install it, so as to make allowance for this projector's optical characteristics.

  • Page 16: Connection

    The connection illustrations below are for reference only. The rear connecting jacks available on the projector vary with each projector model. Notebook or desktop computer A/V device Monitor (VGA) (DVI) Speakers MX520 MX703 VGA cable S-Video cable VGA to DVI-A cable Video cable USB cable Audio cable...

  • Page 17: Connecting Video Source Devices

    • Many notebooks do not turn on their external video ports when connected to a projector. Usually a key combo like FN + F3 or CRT/LCD key turns the external display on/off. Locate a function key labeled CRT/ LCD or a function key with a monitor symbol on the notebook. Press FN and the labeled function key simultaneously.

  • Page 18: Operation

    Operation Starting up the projector Plug the power cord into the projector and into a power outlet. Turn on the power outlet switch (where fitted). Check that the POWER indicator light on the projector lights orange after power has been applied. Please use the original accessories (e.g.

  • Page 19: Adjusting The Projected Image

    Adjusting the projected image Adjusting the projection angle The projector is equipped with 1 quick-release adjuster foot and 1 rear adjuster foot. These adjusters change the image height and projection angle. To adjust the projector: Press the quick-release button and lift the front of the projector.

  • Page 20: Correcting Keystone

    Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom. It occurs when the projector is not perpendicular to the screen. To correct this, you will need to manually correct it following ONE of these steps. •...

  • Page 21: Using The Menus

    Front Table Digital Zoom Menu Settings Teaching Template Operation Settings Front+Rear Remote Receiver Panel Key Lock Background Color BenQ Analog RGB MENU Exit Splash Screen BenQ Analog RGB MENU Exit Press MENU/EXIT twice* on to highlight the SYSTEM the projector or remote control SETUP: Basic menu.

  • Page 22: Securing The Projector

    Securing the projector Using a security cable lock The projector has to be installed in a safe place to prevent theft. Otherwise, purchase a lock, such as the Kensington lock, to secure the projector. You can locate a Kensington lock slot on the rear side of the projector. See item 24 on page for details.

  • Page 23: Entering The Password Recall Procedure

    BenQ Customer Center. Write down the number and turn off your projector. Recall Code: Seek help from the local BenQ service 255 255 255 255 center to decode the number. You may be required to provide proof of purchase MENU...

  • Page 24: Switching Input Signal

    Press to highlight Power On Lock and press to select Off. You will not have to enter the password next time when turning on the projector. ii. If the password is incorrect, the password error message displays lasting for three seconds, and the message “INPUT PASSWORD” displays for your retry.

  • Page 25: Magnifying And Searching For Details

    Magnifying and searching for details If you need to find the details on the projected picture, magnify the picture. Use the direction arrow keys for navigating the picture. • Using the remote control Press Digital Zoom+/- to display the Zoom bar. Press Digital Zoom+ to magnify the center of the picture.
  • Page 26 About the aspect ratio • In the pictures below, the black portions are inactive areas and the white portions are active areas. • OSD menus can be displayed on those unused black areas. 16:9: Scales an image so that it is Auto Scales an image proportionally to fit displayed in the center of the...

  • Page 27: Optimizing The Image

    Optimizing the image Using Wall Color In the situation where you are projecting onto a colored surface such as a painted wall which may not be white, the Wall Color feature can help correct the projected picture’s colors to prevent possible color difference between the source and projected pictures. To use this function, go to the DISPLAY >...

  • Page 28: Adjusting Brightness

    Press to select a menu item to be changed and adjust the value with . See "Fine-tuning the image quality in user modes" below for details. Fine-tuning the image quality in user modes According to the detected signal type and selected picture mode, some of the below functions may not be available.
  • Page 29 Setting a preferred color temperature To set a preferred color temperature: Highlight Color Temperature and select Warm, Normal or Cool by pressing on the projector or remote control. Press to highlight Color Temperature Fine Tuning and press MODE/ ENTER. The Color Temperature Fine Tuning page displays. Press to highlight the item you want to change and adjust the values by pressing...

  • Page 30: Setting The Presentation Timer

    Please refer to the illustration to the right for how the colors relate to each other. For example, if you select Red and set its Yellow range at 0, only pure red in the projected GREEN picture will be selected. Increasing its range will include red close to yellow and red close to magenta.

  • Page 31: Remote Paging Operations

    Press to highlight Timer Position and set the timer position by pressing Top-Left Bottom-Left Top-Right Bottom-Right Press to highlight Timer Counting Direction and select your desired counting direction by pressing Selection Description Count Up Increases from 0 to the preset time. Count Down Decreases from the preset time to 0.

  • Page 32: Hiding The Image

    Hiding the image In order to draw the audience's full attention to the presenter, you can use ECO BLANK on the projector or remote control to hide the screen image. When this function is activated with an audio input connected, the audio can still be heard. SYSTEM SETUP: Basic >...

  • Page 33: Adjusting The Sound

    heating. In cases like this, you should switch to High Altitude mode to solve these symptoms. However, this is not to state that this projector can operate under any and all harsh or extreme conditions. Adjusting the sound The sound adjustments made as below will have an effect on the projector speaker(s). Be sure you have made a correct connection to the projector audio input.

  • Page 34: Using The Teaching Templates

    Using the teaching templates The projector provides several preset patterns for various teaching purposes. To activate the pattern: Open the OSD menu and go to the DISPLAY > Teaching Template and press to select Blackboard or Whiteboard. Press to choose the pattern you need. Press MODE/ENTER to activate the pattern.

  • Page 35: Shutting Down The Projector

    Shutting down the projector Press POWER and a confirmation message will display prompting you. If you don't respond in a few seconds, the message will disappear. Press POWER a second time. The POWER indicator light flashes orange, the projection lamp shuts down, and the fans will continue to run for approximately 90 seconds to cool down the projector.

  • Page 36: Menu Operation

    Menu operation Menu system Please note that the on-screen display (OSD) menus vary according to the signal type selected and the projector model you are using. Main menu Sub-menu Options Off/Light Yellow/Pink/Light Wall Color Green/Blue/Blackboard Aspect Ratio Auto/Real/4:3/16:9/16:10 Keystone Position Phase H.

  • Page 37: System Setup

    Settings Instant Restart On/Off Disable/5 min/10 min/15 min/20 Blank Timer min/25 min/30 min Disable/30 min/1 hr/2 hr/3 hr/4 hr/ Sleep Timer 8 hr/12 hr Remote Receiver (for MX703) Front+Rear/Front/Rear Panel Key Lock On/Off Background Color Black/Blue/Purple/BenQ Splash Screen Black/Blue/BenQ Operation...
  • Page 38 Main menu Sub-menu Options High Altitude Mode On/Off Mute On/Off Volume Audio Settings Power On/Off On/Off Ring Tone Lamp Mode Normal/Economic/SmartEco Lamp Settings Reset Lamp Timer Equivalent Lamp Hour Change Password Security Change Security Settings Power On Lock Settings 2400/4800/9600/14400/19200/ Baud Rate 38400/57600/115200 Test Pattern...

  • Page 39: Description Of Each Menu

    Description of each menu Function Description Corrects the projected picture’s color when the projection surface is Wall Color not white. See "Using Wall Color" on page 27 for details. There are several options to set the image's aspect ratio depending on Aspect Ratio your input signal source.

  • Page 40: Function Description

    Function Description Teaching "Using the teaching templates" on page 34 for details. Template Pre-defined picture modes are provided so you can optimize your Picture Mode projector image set-up to suit your program type. See "Selecting a picture mode" on page 27 for details.
  • Page 41 Function Description Quick Auto "Switching input signal" on page 24 for details. Search Color Space "Changing Color Space" on page 24 for details. Conversion Presentation Reminds the presenter to finish the presentation within a certain time frame. See "Setting the presentation timer" on page 30 for details.

  • Page 42: Function Description

    Function Description Direct Power On Allows the projector to turn on automatically once the power is fed through the power cord. Signal Power On Sets whether to turn the projector directly on without pressing POWER or ON when the projector is in standby mode and the signal is feed through the VGA cable.
  • Page 43 Function Description Panel Key Disables or enables all panel key functions except POWER on the projector and keys on the remote control. See "Locking control keys" Lock on page 32 for details. Background Sets the background color for the projector. Color Splash Allows you to select which logo screen will display during projector...

  • Page 44: Monitor Out

    See "Connection" on page 16 for how to make the connection. Enabling this function slightly increases the standby power consumption. Wired LAN BenQ Network Projector Operation Guide for details. Network AMX Device Discovery Settings (for When AMX Device Discovery is On, the projector can be detected by AMX controller.
  • Page 45 Function Description Source Shows the current signal source. Picture Mode Shows the selected mode in the PICTURE menu. Resolution Shows the native resolution of the input signal. Current 3D Format System Shows the current 3D mode. Status Color System Shows input system format: NTSC, PAL, SECAM, YUV, or RGB. Equivalent Lamp Hour Displays the number of hours the lamp has been used.

  • Page 46: Maintenance

    Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens and case clean. Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing.

  • Page 47: Lamp Information

    Lamp information Getting to know the lamp hour When the projector is in operation, the duration (in hours) of lamp usage is automatically calculated by the built-in timer. "Setting Lamp Mode as Economic or SmartEco" below for more information on Economic mode. To obtain the lamp hour information: Press MENU/EXIT and then press to highlight the SYSTEM SETUP:...

  • Page 48: Timing Of Replacing The Lamp

    47), you may continue to operate the Lamp>XXXX Hours projector until the next hour lamp warning appears. Order a new lamp at lamp.benq.com Press MODE/ENTER to dismiss the message. It is strongly recommended that you replace the Notice lamp at this age. The lamp is a consumable item.

  • Page 49: Replacing The Lamp

    Replacing the lamp • To reduce the risk of electrical shock, always turn the projector off and disconnect the power cord before changing the lamp. • To reduce the risk of severe burns, allow the projector to cool for at least 45 minutes before replacing the lamp.

  • Page 50: Resetting The Lamp Timer

    Use the handle to slowly pull the lamp out of the projector. • Pulling it too quickly may cause the lamp to break and scatter broken glass in the projector. • Do not place the lamp in locations where water might splash on it, children can reach it, or near flammable materials.
  • Page 51 After the startup logo, open the On-Screen Display (OSD) menu. Go to the SYSTEM SETUP: Advanced > Lamp Settings menu. Press MODE/ENTER. The Lamp Settings page displays. Highlight Reset Lamp Timer. A warning message displays asking if you want to reset the lamp timer. Highlight Reset and press MODE/ENTER.
  • Page 52 Indicators Light Status & Description Power events Stand-by mode Orange Green Powering up Flashing Normal operation Green Orange Normal power-down cooling Flashing Download CW start fail Green Scaler shutdown fail (data abord) Red Flashing Scaler reset fail (video projector only) LAN download fail LAN download processing Green...

  • Page 53: Troubleshooting

    Troubleshooting The projector does not turn on. Cause Remedy Plug the power cord into the AC power jack on the projector, and plug the power cord into the There is no power from the power cord. power outlet. If the power outlet has a switch, make sure that it is switched on.

  • Page 54: Specifications

    Audio signal input Audio in Output terminals RCA audio jack (L/R) x 2 RGB output PC audio jack x 1 (MX520) D-Sub 15-pin (female) x 1 PC audio jack x 2 (MX703) Speaker USB port (Mini-B x 1) (Stereo) 2 watt x 1 (MX520)

  • Page 55: Dimensions

    Dimensions 287.3 mm (W) x 114.4 mm (H) x 232.6 mm (D) 287.3 232.6 114.4 Ceiling mount installation 207.6 Ceiling Mount screw: M4 x 8 (Max L = 8 mm) 199.6 Unit: mm 83.38 123.0 141.88 232.6 286.90 Specifications...

  • Page 56: Timing Chart

    1024 x 768 XGA_85 84.997 68.667 94.500 XGA_120** 119.989 97.551 115.5 (Reduce Blanking) 1152 x 864 1152 x 864_75 67.5 BenQ 1024 x 576 60.0 35.820 46.966 Notebook_timing BenQ 1024 x 600 64.995 41.467 51.419 Notebook_timing 1280 x 720 1280 x 720_60* 45.000...
  • Page 57 119.989 97.551 115.5 (Reduce Blanking) 1152 x 864 1152 x 864_75 67.5 1280 x 768 1280 x 768_60* 59.87 47.776 79.5 BenQ Notebook 1024 x 576@60Hz 60.00 35.820 46.996 Timing BenQ Notebook 1024 x 600@65Hz 64.995 41.467 51.419 Timing 1280 x 720 1280 x 720_60 45.000...
  • Page 58 • The timings showing above may not be supported due to EDID file and VGA graphic card limitations. It is possible that some timings cannot be chosen. Vertical Horizontal Pixel Timing Resolution Frequency Frequency Frequency Remark (Hz) (kHz) (MHz) 480i* 720 x 480 59.94 15.73...

  • Page 59: Warranty And Copyright Information

    Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ's only obligation and your exclusive remedy shall be replacement of any defective parts (labor included). To obtain warranty service, immediately notify the dealer from which you purchased the product of any defects.
