How to operate the Sound Adjustment Mode

Time alignment adjustment (Time Alignment)

The delay time and level of the sound from each speaker can
be adjusted in order to correct any phase mismatches in the
sound resulting from the listening position.
Turn the [SEL] button to select Time Alignment.
1
The selected item will be highlighted.
Press the [SEL] button.
2
The mode will change to time alignment adjustment mode.
3
Press the [SEL] button for less than one second to
select the speaker band to be adjusted.
Each time the button is pressed, the selection changes in
the following order.
Hi-L ➔ Hi-R ➔ Mid-L ➔ Mid-R ➔ Low-L ➔ Low-R ➔
4
Turn the [SEL] button to select the speaker that is
furthest away, and then adjust the delay time for the
sound to arrive.
The delay time can be adjusted within 0.0 to 5.0 ms (in
units of 0.1 ms).
Turn to the right: Increases the time.
Turn to the left: Decreases the time.
128
[SEL] button
