Eclipse CD5405 Owner's Manual

Eclipse - fujitsu ten high-power cd receiver owner's manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

CUSTOMER NOTICE
Please retain this booklet and write in the serial number
of your CD5405 for identification.
The serial number is labeled or stamped on the chassis.
Serial No.
FUJITSU TEN LIMITED
Contact:FUJITSU TEN CORP. OF AMERICA
19600 So. Vermont Avenue, Torrance, CA 90502
Call:800-233-ECLIPSE
www.eclipse-web.com
"ECLIPSE" is a registered trademark of
FUJITSU TEN LIMITED in 48 countries
including the U.S. and Japan.
090001-14660700 0411MT (F.O)
OWNER'S MANUAL
CD5405
ESN E5 High-Power CD Receiver
We appreciate your purchase of this receiver.
Please read through this manual for correct operation.
We suggest that after reading it you keep this manual
in a safe place for future reference.

Advertisement

Table of Contents
loading

Related Manuals for Eclipse CD5405

Summary of Contents for Eclipse CD5405

  • Page 1 CUSTOMER NOTICE Please retain this booklet and write in the serial number of your CD5405 for identification. The serial number is labeled or stamped on the chassis. Serial No. FUJITSU TEN LIMITED Contact:FUJITSU TEN CORP. OF AMERICA 19600 So. Vermont Avenue, Torrance, CA 90502 Call:800-233-ECLIPSE www.eclipse-web.com...
  • Page 2 CD5405 Warnings and caution signs, illustrated below, are posted throughout this manual as well as on the CD5405. They show safe and correct ways to handle the product so as to prevent personal injury to you, others and to avoid property damage.
  • Page 3 • Before installation, remove the negative (-) battery terminal to prevent shocks, electrical arcing, fires, and damage to vehicle wiring and the equipment you are installing. • Secure wiring with tape or plastic ties so that wires do not interfere with vehicle operation, including brake pedal, gear shifter and steering.
  • Page 4 • Do not let water or foreign objects enter the internal parts of this equipment. Smoke, fires or shocks may result. • Pay attention to where the remote control is left. Traffic accidents or problems with driving may result if the remote control makes its way under the brake pedal etc.
  • Page 5 • Avoid installing in places where it cannot be fastened securely or where there are strong vibrations. Also, if you installed the unit with double-sided tape, first wipe away dirt and wax from the installation area. Otherwise, the unit may come loose due to vibration while driving, causing problems for driving and resulting in traffic accidents or injuries.
  • Page 6 • Do not use batteries other than those specified. Also, do not mix old and new batteries. Injuries or pollution to the surroundings may result from battery ruptures and leakage. • When inserting batteries into the equipment, be careful of the polarity (positive/negative), and insert them as indicated.

  • Page 7: Table Of Contents

    Table of Contents Operating precautions ... 10 Notes on operation ... 10 About compact discs ... 11 About cleaning a CD ... 13 Names of controls and parts ... 14 ESN security operating procedure ... 15 About ESN ... 15 How to operate the ESN (Key CD) security ...
  • Page 8 How to operate the CD player ... 32 Listening to CDs ... 32 Advancing to the next track or returning to the beginning of the track being played ... 33 Fast Forward/Rewind ... 33 Playing the beginning of tracks (SCAN) ... 33 Repeating the same track (REPEAT) ...
  • Page 9 If you have a question: ... 49 Displayed information (for troubleshooting) ... 50 Specifications ... 53 Before installation ... 54 Components ... 54 Installation angle ... 54 Mounting instruction ... 55 Mounting the main unit ... 55 Names of lead wires and destinations ... 58 System ...

  • Page 10: Operating Precautions

    Operating precautions Operating precautions <Your CD5405 will perform well over a long period of time through correct handling and care.> Notes on operation • For your safety, play only at volume levels that allow outside sounds to be heard. • We recommend using with this player a disc with the logo shown to the left.

  • Page 11: About Compact Discs

    About compact discs • The signal recorded on a compact disc is read by a laser beam, so nothing touches the disc surface. A scratch on the recorded surface or a badly warped disc may cause deteriorated sound quality or intermittent playback.
  • Page 12 Operating precautions About brand new CDs • You may notice that some brand new discs are rough around the center hole or outside edge. Remove the rough edges with the side of a ballpoint pen, etc. Rough edges may prevent proper loading in the deck.

  • Page 13: About Cleaning A Cd

    About borrowed CDs • Do not use a CD with glue or remnants of adhesive tape or labels. They may cause the CD to get stuck inside or damage the deck. How to remove CDs • When removing the ejected disc, pull it straight out along the slot.

  • Page 14: Names Of Controls And Parts

    Names of controls and parts Names of controls and parts ① ② ③ ⑭ ⑬ ⑫ (EJECT) ] button [DISC] button [FM AM] button Disc slot [DISP FUNC] button [SOUND] button [SEL] button ] button [RTN] button [RESET] button Buttons [1] to [6] [AUDIO CONTROL] button [PWR] button [MUTE] button...

  • Page 15: Esn Security Operating Procedure

    ESN security operating procedure ESN security operating procedure About ESN This deck incorporates ESN (ECLIPSE Security Network). The ESN is a security system which disables all deck functions when the power is restored if the deck is stolen from the vehicle. Once the ESN is activated, removing power to the deck or vehicle will activate the security feature.

  • Page 16: How To Operate The Esn (Key Cd) Security

    A [SEC] message appears, then in two seconds it will change to [DISC]. The CD5405 is now ready to accept your Key CD in the CD slot. •If a CD has already been inserted, a [SEC] message appears, and then the CD is ejected.

  • Page 17: How To Cancel The Key Cd

    A [SEC] message appears, then in two seconds it will change to [DISC]. The CD5405 is now ready to accept your Key CD in the CD slot. If a CD has already been inserted, a [SEC] message appears, and then the CD is ejected.

  • Page 18: How To Change The Key Cd

    When the power is turned on after disconnecting the battery power, a [SEC] message will appear for two seconds. Thereafter, the message changes to [DISC] and the CD5405 is ready to accept your Key CD into the slot. Insert your Key CD into the slot.

  • Page 19: What Happens If An Incorrect Cd Is Inserted

    What happens if an incorrect CD is inserted? After the 5th incorrect attempt, the display reads [HELP] for five seconds. [HELP] will appear for five seconds, after which the serial number will appear. Press button [6], then the [DISP FUNC] button, and hold them for five seconds.

  • Page 20: How To Turn The Security Indicator On/Off

    [ESN] appears on the display, followed by an eight-digit number; this number is your electronic serial number (ESN). You may use this number to identify your Eclipse CD5405 in the event it is recovered after being stolen. [DISP FUNC] button...

  • Page 21: Basic Operation

    Basic operation [PWR] button This section covers basic operating procedures. For additional details, please refer to the sections on specific functions. Turning the power on and off Turning the power on and off. When the power is turned on, the state used when the power was turned off such as CD and tuner playback is restored.

  • Page 22: Listening To A Cd

    Basic operation [DISC] button Listening to a CD Insert a CD into the disc slot, label side up. The CD will start playing. When a CD is already loaded, press the [DISC] button to switch to the CD mode. ATTENTION...

  • Page 23: Listening To The Tuner

    [FM AM] button Listening to the tuner Press the [FM AM] button. This will turn the tuner on. Press the [FM AM] button to switch to the desired FM or AM bands. Radio bands will switch from FM1 ➔ FM2 ➔ FM3 ➔ AM in order each time the button is pressed.

  • Page 24: Adjusting Audio Volume

    Basic operation [AUDIO CONTROL] button [MUTE] button Adjusting audio volume Turn the [AUDIO CONTROL] button to the left or right. Turn to the right: Increases the volume. Turn to the left: Press the [MUTE] button for less than one second to cut the volume or restore it instantly.

  • Page 25: Switching Audio Control Modes

    [AUDIO CONTROL] button Switching audio control modes Various audio control modes may be fine-tuned using this procedure. Press the [AUDIO CONTROL] button for less than one second to select the item to be adjusted. Modes will switch in the order shown below each time the button is pressed.

  • Page 26: Mid (Middle) Mode

    Basic operation [AUDIO CONTROL] button MID (MIDDLE) Mode Adjusts middle level. Mid mode can be adjusted for each source (CDP, FM and AM). Turn the [AUDIO CONTROL] button to the left or right. Turn to the right: Emphasizes medium sounds. Turn to the left: Softens medium sounds.

  • Page 27: Nf-P (Non-Phase) Mode

    [AUDIO CONTROL] button NF-P (NON-FADER PHASE) Mode The merging of sound between the front and rear speakers and the woofer can be improved by selecting the phase. Switch the phase to a phase which lets the speakers combine without any disharmony. Turn the [AUDIO CONTROL] button to select NORMAL or REVERSE.

  • Page 28: Changing The Equalizer Mode

    Basic operation Changing the equalizer mode EQ (equalizer) mode can be used to adjust the frequency of the audio channels being played back in accordance with the genre and instruments of the music being played. Apart from four equalizer modes, this deck offers the audio adjustment mode in which you can store set BASS, MIDDLE, and TREBLE adjustment values, and the CUSTOM Mode in which and you can apply these adjustment values.

  • Page 29: Making Changes With Function Mode

    Making changes with Function Mode A variety of settings can be changed. Press the [DISP FUNC] button for more than one second. The function mode is activated. Turn the [SEL] button in either direction to display setting items for selection. Setting items will be displayed in the following order when the [SEL] button is turned to the right.

  • Page 30: Setting The Time

    Basic operation Setting the time This receiver uses the 12-hour display notation. Turn the [SEL] button to select CLOCK. Press the [SEL] button. The clock adjustment mode is activated. Press the [SEL] button to display the item to be selected for adjustment. Hours or minutes will be switched each time the button is pressed.

  • Page 31: Changing The Line Out Mode

    Changing the LINE OUT mode When you select NON-F as the LINE OUT mode, you can make the NON-F and NF-P settings in the audio control mode. Turn the [SEL] button to select LINE OUT. Press the [SEL] button. Turn the [SEL] button to select REAR or NON-F. Press the [SEL] button for more than five seconds.

  • Page 32: How To Operate The Cd Player

    How to operate the CD player How to operate the CD player [DISC] button First press the [DISC] button to switch to the disc mode. It is assumed here that a CD has already been loaded into the unit. Listening to CDs Press the [DISC] button.

  • Page 33: Advancing To The Next Track Or Returning To The Beginning Of The Track Being Played

    Advancing to the next track or returning to the beginning of the track being played Turn the [SEL] button to the left or right. Turn to the right: Advances to the next track. Turn to the left: Fast Forward/Rewind Fast forward or rewind the song currently being played. Press and hold the [ ] or [ ] button.

  • Page 34: Repeating The Same Track (Repeat)

    How to operate the CD player Repeating the same track (REPEAT) Press button [5] to repeat the track being played. To cancel, press button [5] again. Playing tracks in random order (RANDOM) Press button [6] to play the tracks in random order. To cancel, press button [6] again.

  • Page 35: Ejecting The Disc

    (EJECT)] button Ejecting the disc Press the [CD Disc is ejected. Switching the display Press the [DISP FUNC] button for less than one second. Each time the button is pressed, the following will be displayed in order. Elapsed time ➔ Clock How to operate the CD player [DISP FUNC] button (EJECT)] button.

  • Page 36: How To Operate The Tuner

    How to operate the tuner How to operate the tuner [FM AM] button First, press the [FM AM] button to start tuner operation. There are automatic and manual methods for setting stations in memory. The receiver will accept up to 24 stations in memory: 6 in AM and 18 in FM (6 each for FM1, FM2 and FM3.) (Initial setting) Tuning to a station Press the [FM AM] button to switch to the desired FM or...

  • Page 37: Entering Stations Into Memory Automatically (The Automatic Preset Mode: Asm)

    [FM AM] button Entering stations into memory automatically (The automatic preset mode: ASM) Press the [FM AM] button to switch to the desired FM or AM bands. Radio bands will switch from FM1 ➔ FM2 ➔ FM3 ➔ AM in order each time the button is pressed.

  • Page 38: Manually Setting Stations Into Memory

    How to operate the tuner [FM AM] button Manually setting stations into memory This section covers the setting of stations in memory under the numbered buttons. Press the [FM AM] button to switch between FM and AM. Turn the [SEL] button to the right or left to tune to the station to be entered in memory.

  • Page 39: Preset Station Scan

    Preset station scan This function enables reception of all the stations in the preset buttons for five seconds each. Press the [SEL] button for less than one second. [P SCAN] will appear on the display, and stations stored under preset buttons [1] through [6] will be played for five seconds each.

  • Page 40: Changing The Reception Sensitivity For Automatic Scanning

    How to operate the tuner [FM AM] button Buttons [1] and [3] Changing the reception sensitivity for automatic scanning The deck lets you select the reception sensitivity to be used for automatic scanning of stations. The two sensitivity modes available for this deck are AUTO mode and DX mode.

  • Page 41: Fm Reception Characteristics

    FM reception characteristics In general, FM has much better tonal quality than AM. However, FM and FM stereo reception encounter several characteristic problems not encountered with AM. FM is more difficult to receive than AM in a moving vehicle. The following are explanatory notes on what to expect from FM reception and on how to get satisfactory performance.

  • Page 42: Reception Area Of Fm Broadcasts

    How to operate the tuner Reception area of FM broadcasts A home receiver can catch weak FM stereo signals through the use of a tall, directional or ultra-sensitive antenna. In a moving vehicle, the area for good reception is limited because of varying conditions encountered while driving, including the types and heights of broadcast antenna structures, signal strength, engine noise, etc.

  • Page 43: How To Use An Optional Remote Control

    How to use an optional remote control Precautions in use of the remote control • Be careful when handling the remote control, especially because it is small and light. Dropping or striking it hard may damage it, wear out the battery or cause a malfunction. •...

  • Page 44: Turning The Power On/Off

    How to use an optional remote control Remote-control light receptor Turning the power on/off When the power is turned on, the state used when the power was turned off such as CD and tuner playing is restored. Press the [PWR] button. The power turns on or off each time the button is pressed.

  • Page 45: Switching Playback Modes

    [TU] button [BAND] button Switching playback modes Press the [MODE] button. Press the button to switch modes in the following sequence: Tuner How to play the tuner Select the tuner mode first. Selecting the FM/AM band Press the [BAND] or [TU] button. Each press will switch tuner modes from FM1 ➔...

  • Page 46: Selecting A Station (Manually Or Automatically)

    How to use an optional remote control [BAND] button PRESET CH ] buttons Selecting a station (manually or automatically) A short tap of the button will allow manual station tuning. Pressing for more than one second will start automatic tuning. Press the [ TUNE•SEEK ] button.

  • Page 47: Advancing To The Next Track Or Returning To The Beginning Of The Track Being Played

    Advancing to the next track or returning to the beginning of the track being played Press the [ ] button: Skips to the next track. ] button: Returns to the beginning of the track being played. (Press repeatedly to move to previous tracks.) Hold the [ ] button down to fast forward, or the [...

  • Page 48: Replacing The Battery

    How to use an optional remote control Replacing the battery To prevent accidents, store batteries out of the reach of children. If a child has swallowed one, consult a doctor Warning immediately. Use two AAA-size batteries. Remove the back cover of the remote control unit by gently pressing and sliding it in the direction indicated by the arrow.

  • Page 49: If You Have A Question

    If you have a question: First check the items mentioned below before attempting to troubleshoot problems. If a problem occurs, for instance when the unit does not respond to any button presses, or the display doesn't work correctly, Caution press the [RESET] button using a paper clip or similar item. Pressing the [RESET] button will delete all the entries from memory.

  • Page 50: Displayed Information (For Troubleshooting)

    If you have a question: Displayed information (for troubleshooting) The information listed in the chart below is displayed to show the status of the CD player. Refer to the chart for the appropriate action. Information Contents INFO 3 DISCS ARE DIRTY OR DAMAGED INFO 5 CD PLAYER FAILS MECHANICALLY...
  • Page 51 Mode Problem Is the volume control up sufficiently? Is MUTE functioning? Dead or Is the fader or balance control set far weak sound to one side? Other probable causes include broken audio-signal wiring or a faulty speaker. Are too many electrical items installed, causing a lack of power? Power does not turn on.
  • Page 52 If you have a question: Mode Problem The disc cannot be inserted. The disc is ejected as soon as it is inserted. Or, the disc cannot be ejected. Sound skips around. Sound is intermittent. Sound is bad in quality. The disc cannot be ejected.

  • Page 53: Specifications

    Specifications < > GENERAL Power Supply Current Drain Dimensions (W x H x D) In-Dash Unit Mass (weight) Usage temperature range Storage temperature range < > FM TUNER Frequency Range USA: Asia: Australia: Latin America: Usable Sensitivity 50dB Quieting Sensitivity Frequency Response Stereo Separation <...

  • Page 54: Before Installation

    Before installation Before installation G Note G Be sure to disconnect the vehicle battery's negative terminal before installing the receiver. Components Main unit Mounting sleeve Side bracket Rear bracket Bezel Bushing Self-tapping screw (6 x 16 mm) Stud bolt Flat head screw (red:5 x 8 mm) Hex-head bolt (red:5 x 8 mm) Hex-head bolt (6 x 20 mm) Hex nut (5 mm)

  • Page 55: Mounting Instruction

    Mounting instruction Mounting the main unit -If installing the main unit by the mounting sleeve- Insert the mounting sleeve into the opening in the vehicle dash board or console box. Use a screwdriver or the like to bend the tabs in the mounting sleeve to secure the mounting sleeve.
  • Page 56 Mounting instruction Mount the stud bolt to the main unit. Insert the main unit into the mounting sleeve until it locks in place. Fasten the rear of the main unit using either method [A] or [B]. Select method [A] or [B] to suit the interior configuration of the vehicle.
  • Page 57 -If installing the main unit by the side brackets of the vehicle- Remove the pocket and any other accessories from the center cluster to make room for the main unit. Remove the mouiting side brackets for the pocket. CENTER CLUSTER Attach the side brackets to the main unit.

  • Page 58: Names Of Lead Wires And Destinations

    Mounting instruction Names of lead wires and destinations (refer to Page 60) G Caution G Never connect the power supply to the speaker leads, otherwise it cause damage to the main unit. G Note G To prevent unconnected leads from shorting out, insulate them by wrapping their tips with electrical tape.

  • Page 59: System

    Mounting instruction System...
  • Page 60 Mounting instruction...
  • Page 61 Mounting instruction...

  • Page 62: How To Contact Customer Service

    How to contact customer service How to contact customer service Should the product require service, please contact your nearest following Eclipse dealer. < > U.S.A/CANADA DIVISION OF FUJITSU TEN CORP. OF AMERICA 19600 SOUTH VERMONT AVENUE, TORRANCE, CA 90502 Phone: (310) 327-2151 <...
  • Page 63 < > KOREA Transpectra Co., Ltd. 115-16 nonhyun dong kangnam ku Seoul, Korea. Phone: 02-540-4595 Fax: 02-2-540-4666 HYUNDAI AUTONET Co., LTD. 1st FL. Namhyoung Bldg, 746-23 Yeoksam-Dong, Kangnam-Ku, Seoul, Korea 135-080 Phone: 02-508-6001 Fax: 02-2-508-6067 < > TAIWAN Sentrek Taiwan, LTD. 1, 9F, Lane 155, Section 3, Peishen RD., Shenkeng, Taipei Hsien, Taiwan, R.O.C.
  • Page 64 MEMO M e m o • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •...
  • Page 65 MEMO M e m o • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •...
  • Page 66 MEMO M e m o • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •...
  • Page 67 IMPORTANT RECORD YOUR “KEY CD” HERE… STORE YOUR “KEY CD” ALONG WITH YOUR OWNER’S MANUAL TAKE THIS OUT.
