1.10 Hardware Management Subsystem

The hardware management features enable the board to be compatible with the Wired
for Management (WfM) specification. The Winbond W83627DHG-B I/O controller is
used to implement hardware monitoring and fan control. The features of this I/O
controller include:
• Internal ambient temperature sensor
• Two remote thermal diode sensors for direct monitoring of processor temperature
and ambient temperature sensing
• Power supply monitoring of four voltages (+5 V, +V_1P8__CORE, +VCCP, and
+12 V) to detect levels above or below acceptable values
• Thermally monitored closed-loop fan control, for system fan, that can adjust the
fan speed or switch the fans on or off as needed
• SMBus interface
1.10.1

Fan Monitoring

Fan monitoring can be implemented using Intel
or third-party software.
For information about
The functions of the fan connectors

1.11 Power Management

Power management is implemented at several levels, including:
• Software support through Advanced Configuration and Power Interface (ACPI)
• Hardware support:
⎯ Power connector
⎯ Fan connectors
⎯ LAN wake capabilities
⎯ Instantly Available PC technology
⎯ Resume on Ring
⎯ Wake from USB
⎯ Wake from PS/2 devices
⎯ Power Management Event signal (PME#) wake-up support
Product Description
Desktop Utilities, LANDesk* software,
®
Refer to
Section 1.11.2.2, page 31
27
