S
PECIFICATIONS
MODEL
Length
Width (w/rear handle)
Height
Weight (dry)
(w/side handle)
Engine Type
Displacement
Bore
Stroke
Carburetor
Ignition System
Spark Plug
Exhaust System
Fuel
Fuel/Oil Ratio
Gasoline
Oil
Fuel T ank Capacity
Recoil Starter System
Wide Open Throttle Speed (RPM)
Idle Speed (RPM)
Maximum Air Volume
Maximum Air Speed w/pipes (MPH)
Specifications, descriptions and illustrative material in this literature are as accurate as known at the time of publication,
but are subject to change without notice. Illustrations may include optional equipment and accessories, and may not
include all standard equipment.
ES-2100
330 mm (13.0 in.) (w/o vacuum attachment)
340 mm (13.37 in.) (in blower configuration w/side handle)
4.3 kg (9.5 lb.) (in blower configuration)
5.15 kg (11.35 lb.) (in vacuum configuration)
Air cooled, two-stroke, single cylinder gasoline engine
21.2 cc (1.29 cu. in.)
32.2 mm (1.268 in.)
Zama Diaphragm, model C1U w/primer bulb
Flywheel Magneto, capacitor discharge ignition type
NGK BPM-7Y Gap 0.65 mm (0.026 in.)
Mixed (Gasoline and Two-stroke Oil)
50:1 ECHO High Performance, two-stroke air cooled engine oil
89 Octane unleaded. DO NOT use fuel containing methyl alcohol, more
than 10% ethyl alcohol or 15% MTBE.
50:1 ECHO High Performance, two-stroke air cooled engine oil
Automatic Recoil Starter Centrifugal Type
7500
8.49 cu. m/min. (300 cu. ft./min.)
217 KM/H (135 mph)
S
HRED
O '
PERATOR
290 mm (11.42 in.)
4.5 kg (9.9 lb.) (in blower configuration)
5.21 kg (11.49 lb.) (in vacuum configuration)
23.6 cc (1.44 cu. in.)
34.0 mm (1.34 in.)
26.0 mm (1.024 in.)
Spark Arrestor Muffler
0.5 lit. (17.0 US fl. oz.)
2500 - 3000
8.91 cu. m/min. (315 cu. ft./min.)
225 KM/H (140 mph)
'N' V ® 11
AC
M
S ANUAL
ES-2400
8000
