Operating Instructions

Dishwasher
Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and ful ll your needs for many years to come.
Scandinavian design combines clean lines, everyday functionality, and high quality. These
are key characteristics of all our products and the reason they are greatly appreciated
throughout the world.
To get the most out of your new dishwasher, we recommend that you read the operating
instructions before using it. The operating instructions also include information on how
you can help protect the environment.
ASKO D5638XLHS
Operating Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D5638 and is the answer not in the manual?

Questions and answers

Related Manuals for Asko D5638

Summary of Contents for Asko D5638

  • Page 1: Operating Instructions

    Dishwasher Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and ful ll your needs for many years to come. Scandinavian design combines clean lines, everyday functionality, and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.

  • Page 2: Table Of Contents

    Contents Before washing for the first time Service Read the operating instructions Warranty Be careful with certain materials How to contact ASKO Appliances Inc. Checking water hardness Quick guide Program key Important safety instructions Winter storage/Transport Overflow guard function Care and maintenance...

  • Page 3: Before Washing For The First Time

    Before washing for the first time Do you need this Use&Care Guide in Spanish? Log on to www.askousa.com/customer-care to download. ¿Necesita esta Instrucciones de uso y cuidado en español? Entre en www.askousa.com/customer-care y descárguesela. Read the operating instructions Read through the operating instructions before using the dishwasher, especially the sections Important safety instructions, Child safety, and Dishwashing.

  • Page 4: Important Safety Instructions

    Important safety instructions SAVE THESE INSTRUCTIONS FOR FUTURE • When removing an old dishwasher from service or REFERENCE discarding it, remove the door to the washing compartment. • Do not store or use combustible materials, gasoline, or other flammable vapors and liquids in the vicinity WARNING! of this or any other appliance.

  • Page 5: Child Safety

    Child safety TIP! Dishwasher detergents and rinse aids are corrosive, so always keep them out of reach of children. • Should a child swallow dishwasher detergent or rinse aid, give plenty to drink immediately, i.e., one or two glasses of milk or water. Do not try to induce vomiting.

  • Page 6: Dishwasher Components

    Dishwasher components* 1. Filters 2. Cutlery basket 3. Detergent compartment 4. Upper basket 5. Spray arms 6. Serial number plate 7. Lower basket 8. Rinse aid compartment 9. Panel *Specifications may differ depending on the model and market. Customer Care Center 1-800-898-1879 www.askousa.com...

  • Page 7: Dishwasher Baskets

    Dishwasher baskets* Upper basket 1. Wine glass shelf 2. Cup shelf 3. Knife guard Lower basket 1. Fold-down plate support 2. Forward mount for plate support (used for plates with a diameter greater than 9 3/4" (25 cm)) 3. Handle Cutlery basket *Specifications may differ depending on the model and market.

  • Page 8: Front Panel

    Front panel The panel is fitted with touch buttons with audible feedback (see the chapter Settings). Main power switch Child lock (button lock) Program selector High temperature Program symbol Long dry Display Delayed start Rinse aid indicator Start/Stop NOTE! • The touch buttons only react to use when the door is open.

  • Page 9: Detergent/Rinse Aid Dispenser

    Detergent/Rinse Aid Dispenser 1. Prewash detergent compartment 2. Main wash detergent compartment 3. Rinse aid compartment 4. Detergent compartment lid 5. Rinse aid compartment lid Customer Care Center 1-800-898-1879 www.askousa.com...

  • Page 10: Economic Dishwashing

    Economic dishwashing Run programs only with a full load Wait until the dishwasher is fully loaded before running a program, this way you save energy. Use the Rinse & Hold program to rinse the dishes if there are any unpleasant odors while you wait for the dishwasher to become fully loaded.

  • Page 11: Fragile Dishes

    Fragile dishes Some cookware is not dishwasher safe. This can be for several reasons. Some materials cannot withstand high temperatures, others can be damaged by dishwasher detergent. Fragile decoration Porcelain with decoration on top of the glazing (the items feel rough) should not be washed in a dishwasher. Crystal / Glass Position items so that they do not touch each other during the wash.

  • Page 12: Dishwashing

    Dishwashing Below are step-by-step instructions to help you achieve Cutlery basket the best possible dishwashing results. Place cutlery with the handles facing down, except for knives, and spread them out as much as possible. Load the baskets correctly Ensure that spoons do not stack inside each other. The Do not rinse dishes under running water before cutlery basket is placed in the lower basket.
  • Page 13 Dishwashing NOTE! NOTE! We recommend that you do not add prewash detergent Use only dishwasher detergent! Liquid hand-washing for the programs Quick or Super Quick. detergent must not be used as the foam that forms prevents the dishwasher from operating effectively. Dishwasher tablets NOTE! Halve the tablet if it is difficult to close the dispenser lid.

  • Page 14: Select The Program

    Dishwashing Press the main power switch until the display lights up Super Quick Short program lasting about 15 minutes with acceptable results for very lightly soiled dishes. Select the program Press the Program selector one or more times Delicate until the desired program symbol appears on the If the dishes are only lightly soiled, you can select display.
  • Page 15 Dishwashing Program chart Customer Care Center 1-800-898-1879 www.askousa.com...

  • Page 16: Select Options

    Dishwashing Select options Delayed start To select an option, press one of the option When you select Delayed start, the dishwasher will start buttons. The field under the button lights when 1-24 hours after you press the Start/Stop button. the option is activated. The available options depend on the selected program.

  • Page 17: After Dishwashing

    Dishwashing Time remaining Do you want to add more dishes? Once you have selected a program and options, the Open the door. The dishwasher stops automatically. display indicates how long the program took the last Add the dishes, close the door, and the dishwasher time it was used.

  • Page 18: Settings

    Settings Do as follows to open the settings menu: First, open the door. Turn off the dishwasher using the main power switch (press and hold). Release the button. Press and hold the main power switch until the display lights up. Within five seconds, press and hold the Program selector and the Long dry button.
  • Page 19 Settings Button Options Settings Description press Operation volume This sound is used to confirm each button (Off) press. (Low) (High) Press Start/Stop to save the setting value and continue to the next setting. LCD contrast For adjusting the contrast of the display on the (Display on the front of the door) front door.

  • Page 20: Care And Maintenance Instructions

    Care and maintenance instructions The dishwasher tub is made of stainless steel and is 1. Turn the handle counterclockwise once. kept clean through normal use. However, if you have hard water, limescale deposits may form in the dishwasher. If this happens, run the Heavy program with high temperature and two tablespoons of citric acid or commercially available dishwasher cleaner in the detergent compartment (with no dishes in the machine).

  • Page 21: Drain Pump

    Care and maintenance instructions Drain pump NOTE! The pump can be accessed from inside the dishwasher. Do not forget to reinstall the drain pump access cover. 1. Cut the power to the dishwasher by unplugging the unit from the power outlet. 2.
  • Page 22 Care and maintenance instructions Door When cleaning the edge around the door, use only a slightly damp cloth (with a little cleaner if necessary). WARNING! Do not use a spray bottle or the like around the door lock. This is to ensure that water does not penetrate the door catch and come into contact with the electrical components.

  • Page 23: Rinse Aid

    Rinse aid Select dosage The rinse aid dispenser can be adjusted between 0 (off) Drying is faster if you use rinse aid. When the rinse aid and 6. needs topping up, the above symbol lights on the display. Increase the rinse aid dosage: Top up with rinse aid •...

  • Page 24: Troubleshooting

    Troubleshooting Display Type of fault Action Overfilling Call the Customer Care Center. Water outlet fault See "Water remains in the dishwasher above the filters" in the table below. Water inlet fault Check that the water supply valve is on. Inlet valve leakage Turn off the water supply valve and call the Customer Care Center.
  • Page 25 Troubleshooting Problem Possible causes Action Spots left after washing. Lipstick and tea can be difficult to wash Use a detergent with a bleaching agent. off. Rattling sound when dishwashing. The dishes are not correctly placed or Check that the dishes are placed secure- the spray arms are not rotating.
  • Page 26 Troubleshooting Problem Possible causes Action The dishes are not dry enough. Drying power too low. Activate the Long dry option. The dishwasher is not fully loaded. Fully load the dishwasher. Rinse aid needs topping up or dosage Top up with rinse add or increase the is set too low.

  • Page 27: Technical Information

    Technical information Information for test institute Energy standard USA: Energy label FTC, 10 CFR Part 430 Wash performance ANSI/AHAM DW-1-2005 CAN: Energy label CSA C 373-04 Program for test: Normal 130 °F (55 °C), No Options Dosages during testing Rinse aid dosage: Loading for wash performance test Upper basket with 10 place settings AHAM DW-1 Lower basket with 10 place settings AHAM DW-1...
  • Page 28 For residential installations only ASKO Appliances Inc. will pay for: Length of warranty Two-Year Full ASKO replacement parts and/or repair labor to correct defect in materials or workmanship. Service must be provided by From date of purchase. an authorized ASKO service agent.
  • Page 29 5. Replacement parts or repair labor costs for units operated outside the continental United States. 6. Pickup and delivery. ASKO washers are designed to be repaired in the home. In no event shall ASKO Appliances Inc. be responsible for any incidental or consequential damages.
  • Page 30 Notes Customer Care Center 1-800-898-1879 www.askousa.com...
  • Page 31 Notes Customer Care Center 1-800-898-1879 www.askousa.com...
  • Page 32 Quick guide Load the baskets Press the main power switch until the display lights up Do not rinse dishes under running water before loading them in the dishwasher. Simply scrape off large food particles before loading the Select a program and any options dishwasher.
