HP dx2700 Illustrated Parts Map

HP Compaq Business Desktop
dx2700/dx2708
Microtower Models
Illustrated Parts Map
Conroe, Pentium D (Presler/Smithfield), Pentium 4,
and Celeron D Processors
System Unit
1 Front bezel (1 solid silver) with diskette drive bezel
and 2 - 5.25" bezel. (See Miscellaneous parts for kit
contents) for dx2700 MT model
2 Front bezel (carbonite and silver) with diskette drive
bezel and 2- 5.25" bezel blanks for dx2708 MT
models
3 Power supply, 250W PFC
* Power supply, 250W non-PFC
* Power supply, 300W non-PFC
4 Access panel used on all models
5 Chassis
* Not shown
Mass Storage Devices
1 Diskette drive, 3.5-inch
2 40GB, SATA 1.5G
* 80GB, SATA 3G
* 160GB, SATA 3G
* 250GB, SATA 3G
* 52X CD-ROM drive
* 16X DVD +/- RW drive (LS/DL/DF)
* 16X/48X DVD-ROM drive
* 48X/32X Combo Drive
* Not shown
dx2700/dx2708 © 2006 Hewlett-Packard Development
HP and the HP logo are trademarks of Hewlett-Packard
Intel and Celeron are US registered trademarks of Intel
Corporation. All other product names mentioned herein
may be trademarks of their respective companies.
HP shall not be liable for technical or editorial errors or
omissions contained herein. The information in this
document is provided "as is" without warranty of any kind
and is subject to change without notice. The warranties for
HP products are set forth in the express limited warranty
statements accompanying such products. Nothing herein
should be construed as constituting an additional
Blanks Cables
435333-001
Cable kit
1 Diskette drive cable
435334-001
2 Hard drive cable, primary SATA (1 device)
* Optical drive cable, secondary SATA (2 devices)
435332-001
435303-001
3 Audio cable for Linux
435330-001
* Not shown
435331-001
not spared
Keyboards (not illustrated)
Keyboard, PS2
International
Peoples Republic of China
Taiwanese
Thai
KOR
Keyboard, USB
International
Peoples Republic of China
Taiwanese
Thai
KOR
* Not shown
435420-001
416737-001
391945-001
391741-001
391937-001
419619-001
419498-001
419496-001
419497-001
Company, L.P.
Development Company, L.P.
warranty.
September 2006
Document Part Number 431673-001
435309-001
419207-001
382925-xxx
-B31
-AA1
-AB1
-281
-AD1
382926-xxx
-B31
-AA1
-AB1
-281
-AD1
Standard and Optional Boards
Memory modules
1 256MB, PC2-4200
* 512MB, PC2-4200
* 1GB, PC2-4200
* 256MB, PC2-5300
* 512MB, PC2-5300
* 1GB, PC2-5300
Intel Processors with alchohol pad and thermal grease
* Celeron 3.33GHz/512K/D-0, LGA775 processor
* Celeron 3.46GHz/512K/D-0, LGA775 processor
2 Celeron 3.2GHz LGA775 processor
* Celeron 2.8GHz LGA775 processor
* Celeron 3.06GHz LGA775 processor
* Celeron 2.66GHz LGA775 processor
* Celeron 2.53GHz LGA775 processor
* Conroe, 1.86GHz/1066, 2M, B-2
* Conroe, 2.13GHz/1066, 2M, B-2
* Conroe, 2.4GHz/1066, 4M, B-2
* Conroe, 2.66GHz/1066, 4M, B-2
* Presler-915, Mnstm, 2.8GHz, 4M, C-1
* Presler-945, Mnstm, 3.4GHz, 4M, C-1
* Presler-925, Mnstm, 3.0GHz, 4M, C-1
* Smthfld-820, Mnstm, 2.8G, 2M, B-0
* Smthfld-805, Mnstm, 2.66G,2M, B-0
* P4-541, Mstrm, 3.2G, 1M, G-1
* P4-531, Mstrm, 3.0G, 1M, G-1
* P4-524, Mstrm, 3.06G/533MHz
3 Front I/O PCA with cable for MT
System board with alcohol and thermal grease
* System board
Other boards
* Intel Gb NIC PCIe, FH
* Broadcom Gb NIC PCIe, FH
* MDM, PCI modem, V92, FH
* Not shown
# Spared with alcohol wipe and thermal grease
Miscellaneous Parts
Miscellaneous hardware kit. Includes:
1 5.25" drive bezel blank without metal shield (1 ea)
2 Diskette drive bezel without metal shield, silver (1 ea)
6 3.5" diskette drive bezel without metal shield (carbonite) (1 ea)
5 Cover slot (2 ea)
4 Cover slot lock (1 ea)
3 Heatsink with alcohol pad and thermal grease
* System Fan
* USB scroll mouse carbonite
* USB optical mouse carbonite
* PS/2 scroll mouse
* PS/2 optical Mouse
* Sensor, intrusion
* Internal speaker
* Battery, real-time clock
Miscellaneous screw kit, includes :
* #6-32 x 0.25 lg pan head (11 ea, for power supply, cover slot lock
and motherboard.)
* #6-32 x 0.187 lg hi top (10 ea, 2 for I/O bracket, 4 for Hard Disk
Drive, 2 for Optical drive, 2 for Hard disk drive bracket)
* #6-32 x 0.312 lg hi top (1 ea, for Access panel)
* #6-32 flat screw (1 ea, for Power supply bracket)
* M3 x 0.5 screw for Diskette Drive (3 ea)
* Screw for system fan (4 ea)
393392-001
393393-001
393394-001
396519-001
396520-001
398038-001
433508-001
434708-001
382503-001
391941-001
405693-001
391940-001
407322-001
418947-001
418948-001
418949-001
418950-001
433843-001
433890-001
433510-001
432623-001
433912-001
433860-001
394642-001
360734-413
435304-001
435316-001
430654-001
398754-001
398661-001
435308-001
435313-001
435307-001
390939-001
390938-001
390937-001
417966-001
435312-001
435327-001
153099-001
435305-001
