- Page 1 HP 2310mfa/2310mfd LCD Mul func on Monitors (MFM) User Guide...
- Page 2 © 2009 Hewlett-Packard Development Company, L.P. Microsoft, Windows, and Windows Vista are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services.
-
Page 3: Table Of Contents
TABLE OF CONTENT FOR YOUR SAFETY ..........................3 PRECAUTIONS AND REMINDERS ....................4 IMPORTANT SAFETY INSTRUCTIONS ..................5 PACKAGE CONTENTS ........................7 SETTING UP THE MFM ........................8 ATTACHING THE BASE ..................................8 PREPARING THE MFM FOR WALL MOUNTING ........................8 SELECTING A GOOD LOCATION ..............................9 INSTALLING THE MONITOR DRIVER .................. - Page 4 NOTICES ............................. 32 TECHNICAL SPECIFICATIONS ....................33 TROUBLESHOOTING ........................36 TIPS ............................... 37 GLOSSARY ............................37...
-
Page 5: For Your Safety
SYMBOL SYMBOL DEFINITION DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may SA 1965 be of sufficient magnitude to constitute a risk of electrical shock to persons. INSTRUCTIONS: The exclamation point within on equilateral triangle to alert the user to the presence of important operating and maintenance (servicing) instruction in the literature accompanying the appliance. -
Page 6: Precautions And Reminders
PRECAUTIONS AND REMINDERS Place unit on even surfaces. Unplug immediately if other Do not cover or block any foreign materials are put vents and openings. Inadequate inside MFM box or if the MFM ventilation may shorten the fell down. life of the display unit and cause overheating. -
Page 7: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read before operating equipment Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any of the ventilation openings. Install in accordance with the manufacturers instructions. - Page 8 21. Wall or Ceiling Mounting – The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer. 22. Power Lines – An outdoor antenna should be located away from power lines. 23. Outdoor Antenna Grounding – If an outside antenna is connected to the receiver, be sure the antenna system is grounded to provide some protection against voltage surges and built up static charges.
-
Page 9: Package Contents
HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC. LCD panel The LCD panel used in this product is mode of glass. Therefore, it can break when the product is dropped or impacted upon by other objects. The LCD panel is a very high technology product, giving you finely detailed pictures. -
Page 10: Setting Up The Mfm
SETTING UP THE MFM PREPARING THE MFM FOR WALL MOUNTING IMPORTANT: Do not apply pressure to the screen display area, which may compromise Place the MFM at least 2.36 inches (60 mm) from the integrity of the display. The manufacturer’s the wall to prevent cable interference. -
Page 11: Selecting A Good Location
Remote control: SELECTING A GOOD LOCATION Remove the cover of the battery Please make sure to connect the power plug to compartment. Insert the 2 batteries supplied the wall outlet socket after connecting the MFM (Type AAA 1.5V). to the power cord! Install the base stand;... -
Page 12: Installing The Monitor Driver
INSTALLING THE MONITOR DOWNLOADING UPDATED DRIVERS FROM THE INTERNET DRIVER To download the latest version of drivers and The CD that is included with the MFM contains software files from the HPSupport site: the monitor driver that you can install on your computer. -
Page 13: Locating The Mfm Connectors And Controls
LOCATING THE MFM CONNECTORS AND CONTROLS Before connecting any external equipment to the monitor, turn off all main power switches on the external equipment. If there is no switch, remove the main power plug from the wall socket. Connect the power cord into the AC IN socket found at the back of the MFM. NOTE: •... - Page 14 DTV Connectors RGB/PC VIDEO AV OUT COMPONENT VIDEO AV IN VIDEO AC IN (COAXIAL) (OPTICAL) SERV.C HDMI1, 2 (input terminals) — High-Definition Multimedia Interface input receives digital audio and uncompressed digital video from an HDMI device or uncompressed digital video from a DVI device ( page 20-21).
-
Page 15: Front Panel Controls
FRONT PANEL CONTROLS VOL + VOL +: Press to increase the sound volume level. VOL - VOL - : Press to decrease the sound volume level. CH ▲ CH ▲: Press to select the next higher Programme number. CH ▼ CH ▼: Press to select the next lower Programme number. -
Page 16: Using The Remote Control
USING THE REMOTE CONTROL POWER ZOOM Press to turn ON/OFF (standby) Select the display aspect from the MFM. Auto, Normal (4:3), Wide (16:9), subtitle, full screen, or 14:9 mode. SOURCE Press repeatedly to choose the DUAL various input sources. Press to select from mono, stereo, or TV channel. - Page 17 TELETEXT Press to display or close the Teletext. Display the Teletext with TV. SIZE Press to change the font size: Full screen, Top half and Bottom half. SUBPAGE Display the sub page (when available). INDEX Press to return to page 100 or the index page.
-
Page 18: Viewing Mode Illustrations
VIEWING MODE ILLUSTRATIONS Normal Mode The original content would be at the centre of the screen. 16:9 Content 4:3 Content Wide Mode The original content in this mode has to fill the entire screen of the display. 16:9 Content 4:3 Content Zoom Mode For those wide format images which are originally programmed into 4:3 frames with black bars around, this mode would stretch the image in both width and height for full display with active data. -
Page 19: Connecting To The Mfm
• The unauthorized recording of television CONNECTING TO THE MFM programmes, DVDs, video tapes and other materials may infringe upon the provisions of BACK CONNECTIONS copyright law. ATV Connection example • COMPONENT VIDEO INPUT TV back view consists of three component video signals PC IN (Y, P ) and provides the best picture... - Page 20 Connecting an amplifier equipped Connecting an amplifier equipped with a Dolby Digital decoder with an MPEG decoder ATV Connection ATV Connection Amplifier equipped with Amplifier equipped with Dolby Digital decoder MPEG decoder To Coaxial Type To Coaxial Type digital audio input digital audio input Coaxial digital cable Coaxial digital cable...
-
Page 21: Side Connections
Connecting an amplifier equipped SIDE CONNECTIONS with a digital audio (optical or coaxial) ATV Connection example input TV side view ATV Connection Amplifier equipped with Mini Stereo Plug digital audio input decoder DVD video player (with composite video outputs) To Coaxial Type digital audio input Coaxial digital cable (not supplied) -
Page 22: Connecting An Hdmi Or A Dvi Device
CONNECTING AN HDMI OR A DVI CONNECTING AN HDMI DEVICE DEVICE One HDMI cable (type A connector) NOTE: ATV Connection • When turning on your electronic TV back view components, turn on the MFM first, and then the HDMI or DVI device. •... -
Page 23: Connecting A Dvi Device
CONNECTING A DVI DEVICE CONNECTING A COMPUTER An analogue RGB (15 pin) computer cable can be One HDMI(type A connector)-to connected. DVI adapter cable (not provided with MFM) and audio cables ATV Connection TV back view ATV Connection PC IN RGB/PC AUDIO TV back view... -
Page 24: Selecting The Input Source
• A bar may appear in the upper, lower, right USING THE OSD MENUS or left side of the screen, or parts of the picture may be obscured depending on some FOR ATV MODEL signals. This is not the malfunction. Press the MENU/EXIT button to display •... -
Page 25: Sound Menu
▲ ▼ ◄ ► to select one of the Press • SOUND MENU following picture settings. Use smart sound • Smart picture: Accesses pre-defined smart picture settings. Use smart sound to apply pre-defined sound • Backlight: Adjusts the backlight brighter settings. -
Page 26: Features Menu
▲ ▼ ◄ ► to select one of the Press • FEATURES MENU following sound settings. Set the TV clock • Smart sound: Accesses pre-defined You can display a clock on the TV screen. smart sound settings. • Bass: Adjusts the bass value to fit your Press MENU. - Page 27 Automatically switch the TV on Enter your current code using the (On timer) Numeric buttons. On timer switches the TV to a specified channel at If the code is validated, a new dialogue box a specified time from standby. will prompt you to enter your new code. Enter the new code using the Numeric Press...
-
Page 28: Installation
Step 2 Install Channels • INSTALLATION Select your country for proper channel installation. Install channels Press MENU. The first time you set up your TV, you are Installation ► Channel install ► Select prompted to select a menu language and to install Channel assistant. - Page 29 Press ◄ ► to select Yes and press OK to Manually install channels store the new channel. This section describes how to search and store Press MENU to exit. analogue TV channels manually. Fine tune analogue channels Press MENU. You can manually fine tune analogue channels when Installation ►...
-
Page 30: For Dtv Model
Rename channels FOR DTV MODEL Channels can be renamed so that a name of your Press the MENU/EXIT button to display choice appears whenever the channel is selected. or close the main menu. When watching TV, press CH LIST to Use the Navigation Ring to move around display the channel list. - Page 31 Advanced Video: • SOUND MENU The Sound menu provides audio adjustment to • - To filter out and reduces the modify the audio setting. image noise and improve picture quality. Select the effect degrees from Off, Low, Middle, High, or Auto. Picture Sound Mode Personal...
- Page 32 • Channel sort - Changes the order of • TV MENU the Channel List. The TV menu provides channel selection features. • Channel Edit - Enters the Channel Edit in the channels submenu to edit the Picture Channels channel number and channel name by Subtitle Sound using the number buttons 0~9.
-
Page 33: Features Menu
• FEATURES MENU • PARENTAL MENU The Features menu in TV mode, shown below, The Parental Menu enables and defines parental gives the most flexibility for general demands. The controls for the MFM. various requirements in different source modes, allow some features to be hidden (disable) on the Picture Channel Block menu. -
Page 34: Notices
NOTICES Power Cord Set Requirements The MFM power supply is provided with Automatic Line Switching (ALS). This feature allows the MFM to operate on input voltages between 100–120V or 200–240V. The power cord set (flexible cord or wall plug) received with the MFM meets the requirements for use in the country where you purchased the equipment. -
Page 35: Technical Specifications
TECHNICAL SPECIFICATIONS Acceptable Video signals through HDMI terminals Format Resolution V. Frequency H. Frequency Pixel Clock Frequency 480i 720 x 480i 60.000Hz 15.734kHz 27.000MHz 480p 720 x 480p 60.000Hz 31.500kHz 27.000MHz /27.030MHz 576i 720 x 576i 50.000Hz 15.625kHz 27.000MHz 576p 720 x 576p 50.000Hz 31.250kHz... - Page 36 Analogue TV Model Specifications Input/Output terminals Model Input 2310mfa RCA Component Video Y, PB/CB, PR/CR RCA Composite Video CVBS Power source Audio : RCA L/Mono+R 220 V-240 V AC, 50 Hz Input RCA/Mini-Din(4 pin) Power consumption Composite Video(CVBS) +S-video 2310mfa: 65W Audio : RCA L/Mono+R (shared between...
- Page 37 Digital TV Model Specifications Aspect ratio 16 : 9 Model 2310mfd Visible size (diagonal) 477.41x268.41mm Power source 220 V-240 V AC, 50 Hz Number of pixels 1,366 (H) dots x 768 (V) dots Power consumption 2310mfd: 65W Sound output (at 10 distortion) 3W + 3W Standby...
-
Page 38: Troubleshooting
TROUBLESHOOTING Please make these simple checks before calling service. These tips may save you time and money since charges for receiver installation and adjustments of customer controls are not covered under your warranty. Symptoms Items to Check and Actions to follow “Ghost ”... -
Page 39: Tips
Online Technical Support For the online access to technical support information, self-solve tools, online assistance, community forums of IT experts, broad mutlivendor knowledge base, monitoring and diagnostic tools, go to http://www.hp.com/support. Preparing to Call Technical Support If you cannot solve a problem using the trouble shooting tips in this section, you may need to call technical support.
