- Page 1 USER MANUAL FERRUPS 0800-2000 - 0800-7500...
- Page 2 Ver el CD CheckUPS para el Manual de Información sobre Seguridad FERRUPS. Se CD-skivan CheckUPS CD för FERRUPS säkerhetsmanual. LTM-1319A ® User Manual 0800-2000 through 0800-7500 2 kVA-7.5 kVA 50 and 60 Hz Uninterruptible Power Systems IMPORTANT SAFETY INSTRUCTIONS. SAVE THESE INSTRUCTIONS.
-
Page 3: Best Power Offices
Best Power Offices Best Power P.O. Box 280 Necedah, WI 54646 U.S.A. Telephone: 1-608-565-7200 Toll-Free: 1-800-356-5794 (U.S.A. and Canada) FAX: 1-608-565-2221 International FAX: 1-608-565-7675 Worldwide Service P.O. Box 11 Necedah, WI 54646 U.S.A. Telephone: 1-608-565-2100 Toll-Free: 1-800-356-5737 (U.S.A. and Canada) FAX: 1-608-565-7642 Best Power Technology Mexico, S.A. -
Page 4: Table Of Contents
Contents 100 Introduction ..............3 200 UPS Features . -
Page 5: 200 Ups Features
200 UPS Features The drawings below will help you identify the features on your UPS and separate battery cabinets. Back Panel of Standard Units* Output Receptacles (optional) Battery Cabinet Connector (behind plate) * Only one FERRUPS model is shown; sizes vary. The unit shown is a soft-wired (plug-in) model with output receptacles; some units do not have a power cord, plug, or output receptacles. -
Page 6: 300 Starting The Ups
300 Starting the UPS Note: If you plan to store your UPS, the storage temperature must be between –20° and +40° Celsius (–4° and +104° Fahrenheit). If the UPS does not have internal batteries, you can store it at –20° to +60° C (–4° to +140°... - Page 7 Models with permanently attached power cords (shown): Plug in the UPS. If the plug on the UPS’ power cord does not match your outlet (receptacle), an electrician must install the proper outlet. Models with power cords that must be plugged in: Do not use the cord that came with your UPS to plug it in;...
- Page 8 If your UPS has output receptacles/outlets on the back panel (shown) or on an attached internal bypass switch, plug the equipment you want to protect into the UPS’ receptacles. If you used the cord from your own equipment to plug in the UPS (see step 2), use the cord provided with the FERRUPS to...
- Page 9 b. Press the t button twice until the display shows “3 System Status Info.” c. Press ¿ once. The display will now show “3 1 Unit Time.” d. Press ¿. A cursor will appear in the time shown. e. Notice that the bottom line of the display has changed to “<–...
-
Page 10: 400 Using The Ferrups' Front Panel Lights
400 Using the FERRUPS’ Front Panel Lights The FERRUPS display includes three lights that show you the status of FERRUPS operation. Alarm Light Battery Light Line (AC Input) Light The red Alarm light means the UPS has detected a problem. When this happens, the display shows an alarm message, and the UPS beeps the Morse Code for the alarm. -
Page 11: 502 Displaying A Parameter By Entering The Parameter Number
To scroll down through menus or menu items in the same level: Press the t button on the right side of the display. To scroll up through menus or menu items in the same level: Press the s button. You can also look at the bottom line of the display, which includes the words “Top” and “ESC.”... -
Page 12: Menu Map
Menu map for the User Interface 1 Enter password Enter password 2 1 System Control 2 System Status 2 2 System Mode 2 3 Mode Flags 3 1 Unit Time 3 System Status 3 2 Unit Date Info 3 3 Unit Year 3 4 AC Input Volts 4 1 Model Number 4 System ID... -
Page 13: 503 Entering A Password
503 Entering a Password Before you can change the setting of some FERRUPS parameters or menu items, you must enter a password. To do this, follow the steps below. The User password is 0377. 1. If the display is not already showing the menus, press the bottom right button (below the word “Menu” on the bottom line of the display). -
Page 14: 505 Parameters
3. Move the cursor to the first digit you want to change, and use the s and t buttons to increase or decrease the number. Repeat this step for each digit that needs to be changed. 4. When you have finished, press ¿ to save the new setting. If you decide not to change the setting, press the bottom right button below the word “ESC”... - Page 15 Menu 2: System Status (continued) Item and Sample Password to Display Change No change allowed. Show Alarm Code #2 almcode2 0000 hex No change Transfer Code allowed. xfercode User Test Control testcon No change Test Results allowed. tresults 2 10 None Test Alarm testalarm...
- Page 16 Menu 3: System Status Info (continued) Item and Sample Password to Display Change 3 10 No change % Full Load allowed. pctfload 90 % 3 11 No change Power Factor allowed. powerfact 0.70 3 12 No change Output Frequency allowed. freqout 60.4 Hz 3 13 No change...
-
Page 17: 506 Reading The Ferrups Logs
Menu 4: System ID (continued) Item and Sample Password to Display Change User Nominal Frequency nomfreq 60 Hz User Nominal AC V Out nomacvo 120 V Service Rated VA ratedva 2 KVA 4 10 Service Rated Watts ratedwts 1.4 KW 506 Reading the FERRUPS Logs Your FERRUPS makes an entry in its logs every time it sounds an alarm or runs on inverter (battery power). -
Page 18: Alarm Log
These are the inverter codes: Inverter Code System Test The FERRUPS went to inverter to test the batteries. Alarm Log The Alarm Log is in menu 6, submenu 3. If you have already displayed inverter log entries, press the bottom right button to display “6 2 Inverter Log,”... - Page 19 2. Find the alarm in the table below, and follow the instructions in the third column of the table. To clear an alarm when the problem has been solved, press the middle button below the display. If the problem that caused the alarm is still present, the alarm will sound again after a short delay.
-
Page 20: 700 Communication
Alarm Message Morse What It Means Code K Circuit Breaker — • — Your equipment is drawing more current Warning (amps) than the UPS is designed to provide. Shutdown (See your model’s output current rating.) The unit will shut down; the time until shutdown depends on the amount of overcurrent. -
Page 21: 702 Db9 Port Pin Functions
Optional Interface Kits: Optional Internal Bestlink™ SNMP/Web Adapter: BestDock™ FERRUPS has a communication slot that allows quick installation of an optional SNMP card. Emergency Power Off (EPO): You can connect your FERRUPS to your Emergency Shutdown switch to provide a method for emergency FERRUPS shutdown. -
Page 22: 800 Maintenance And Service
1. a. Press the bottom right button (below “Menu” on the display) to switch from the normal display to the menus. The display will show the top menu, “1 Enter Password.” b. Press t four times (until the display shows “5 System Config”). c. -
Page 23: 900 Specifications
900 Specifications Model 0800-2000 2 kVA/1.4 kW AC Input Voltage 110 = 22 amps 115 = 22 amps and Current 120 = 22 amps 127 = 22 amps 208 = 12 amps 220 = 12 amps 230 = 12 amps... -
Page 24: Lightning And Surge Protection
AC Output with Nominal Input Power and Loads (Protected Equipment) Voltage Regulation: ±3% load regulation. Total voltage regulation under any line, load, or battery condition to within –8.3% and +5% of nominal. Input Voltage Range: At low voltages: 85-135 VAC. At high voltages: 165-275 VAC. Overload Capability: 150% surge and 125% for 10 minutes. -
Page 25: Batteries And Battery Charger
Protection DC Input: Output Protection: Batteries and Battery Charger Standard batteries are sealed, gas recombinant, and lead-acid, especially designed for UPS use. 2 kVA to 7.5 kVA: Nominal battery voltage is 48 VDC. The standard battery charger is rated at 10 amperes at 48 VDC. - Page 26 incompatible or defective. Replacement or repair will be made at BEST POWER’s Worldwide Service, Highway 80, Necedah, Wisconsin 54646, U.S.A. Such repair or replacement shall be at BEST POWER’s expense. This warranty does not cover any taxes which may be due in connection with replacement or repair, nor any installation, removal, transportation or postage costs.
- Page 27 This warranty does not include any taxes which may be due in connection with replacement or repair nor any installation, transportation or postage costs. These expenses will be paid by PURCHASER. Replacement or repair will be made at BEST POWER’s Worldwide Service, Highway 80, Necedah, Wisconsin 54646, U.S.A.
-
Page 28: 1100 Notices
1100 Notices 2-3 kVA Soft-wired (Plug-in) and 50 Hz Models: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference that may cause undesired operation.
