Personal Audio
Docking System
©2012 Sony Corporation
Printed in China
RDP-X200iP
— with respect to the supply to the public of the RLAN
WARNING
access to telecom networks and services, by the
Ministerial Decree 28.5.2003, as amended, and Art.
25 (general authorization for electronic communications
To reduce the risk of fire or electric shock, do
networks and services) of the Code of electronic
not expose this apparatus to rain or moisture.
communications.
To reduce the risk of fire, do not cover the ventilation of
On Copyrights and Licenses
The Bluetooth word mark and logos are owned by the
the apparatus with newspapers, tablecloths, curtains, etc.
And do not place lighted candles on the apparatus.
Bluetooth SIG, Inc. and any use of such marks by Sony
Corporation is under license. Other trademarks and trade
To reduce the risk of fire or electric shock, do not expose
names are those of their respective owners.
this apparatus to dripping or splashing, and do not place
objects filled with liquids, such as vases, on the apparatus.
iPhone, iPod, iPod classic, iPod nano, and iPod touch are
trademarks of Apple Inc., registered in the U.S. and other
Do not install the appliance in a confined space, such as a
countries. iPad is a trademark of Apple Inc.
bookcase or built-in cabinet.
"Made for iPod, " "Made for iPhone, " and "Made for iPad"
Do not expose the batteries (battery pack or batteries
mean that an electronic accessory has been designed to
installed) to excessive heat such as sunshine, fire or the like
connect specifically to iPod, iPhone, or iPad, respectively,
for a long time.
and has been certified by the developer to meet Apple
performance standards. Apple is not responsible for the
As the main plug is used to disconnect the unit from the
operation of this device or its compliance with safety and
mains, connect the unit to an easily accessible AC outlet.
regulatory standards. Please note that the use of this
Should you notice an abnormality in the unit, disconnect
accessory with iPod, iPhone, or iPad may affect wireless
the main plug from the AC outlet immediately.
performance.
The unit is not disconnected from the AC power source
(mains) as long as it is connected to the wall outlet, even if
Use of this radio equipment is not allowed in the
the unit itself has been turned off.
geographical area within a radius 20km from the centre of
Ny-Alesund, Svalbard in Norway.
The nameplate and important information concerning
safety are located on the bottom exterior of the main unit
and on the surface of the AC adaptor.
Precautions
CAUTION
Danger of explosion if battery is incorrectly replaced.
To disconnect AC power, grasp the plug itself, not the cord.
Replace only with the same type.
Since a strong magnet is used for the speaker, keep credit
cards using magnetic coding or spring-wound watches,
Notice for customers: the following information is
CRT-based TVs, or projectors, etc., away from the unit
only applicable to equipment sold in countries
to prevent possible damage from the magnet.
applying EU directives
Do not leave the unit in a location near a heat source such
The manufacturer of this product is Sony Corporation, 1-
as a radiator or airduct, or in a place subject to direct
7-1 Konan, Minato-ku, Tokyo, 108-0075 Japan. The
sunlight, excessive dust, mechanical vibration, or shock.
Authorized Representative for EMC and product safety is
Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327
Allow adequate air circulation to prevent internal heat
Stuttgart, Germany. For any service or guarantee matters,
build-up. Do not place the unit on a surface (a rug, a
please refer to the addresses given in separate service or
blanket, etc.) or near materials (a curtain) which might
guarantee documents.
block the ventilation holes.
Should any solid object or liquid fall into the unit,
unplug the unit and have it checked by qualified
personnel before operating it any further.
Hereby, Sony Corp., declares that this equipment is in
During a thunderstorm, do not touch the antenna
compliance with the essential requirements and other
(aerial) and plug.
relevant provisions of Directive 1999/5/EC. For details,
Do not touch the unit with wet hands.
please access the following URL:
Do not place the unit anywhere near water.
http://www.compliance.sony.de/
NOTES ON LITHIUM BATTERY
Use of the RLAN network is governed:
Wipe the battery with a dry cloth to assure a good
— with respect to private use, by the Legislative Decree of
contact.
1.8.2003, no. 259 ("Code of Electronic
Be sure to observe the correct polarity when installing
Communications"). In particular Article 104 indicates
the battery.
when the prior obtainment of a general authorization is
Do not hold the battery with metallic tweezers,
required and Art. 105 indicates when free use is
otherwise a short-circuit may occur.
permitted;
Disposal of Old Electrical & Electronic
Equipment (Applicable in the European
4-400-214-32(1)
Union and other European countries with
separate collection systems)
This symbol on the product or on its packaging indicates
that this product shall not be treated as household waste.
Instead it shall be handed over to the applicable collection
point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative
Reference Guide
GB
consequences for the environment and human health,
which could otherwise be caused by inappropriate waste
handling of this product. The recycling of materials will
help to conserve natural resources. For more detailed
information about recycling of this product, please contact
your local Civic Office, your household waste disposal
service or the shop where you purchased the product.
Applicable accessory: Remote control.
Disposal of waste batteries (applicable
in the European Union and other
European countries with separate
collection systems)
This symbol on the battery or on the packaging indicates
that the battery provided with this product shall not be
treated as household waste.
On certain batteries this symbol might be used in
combination with a chemical symbol. The chemical
symbols for mercury (Hg) or lead (Pb) are added if the
battery contains more than 0.0005% mercury or 0.004%
lead.
By ensuring these batteries are disposed of correctly, you
will help prevent potentially negative consequences for the
environment and human health which could otherwise be
caused by inappropriate waste handling of the battery. The
recycling of the materials will help to conserve natural
resources.
In case of products that for safety, performance or data
integrity reasons require a permanent connection with an
incorporated battery, this battery should be replaced by
qualified service staff only.
To ensure that the battery will be treated properly, hand
over the product at end-of-life to the applicable collection
point for the recycling of electrical and electronic
equipment.
For all other batteries, please view the section on how to
remove the battery from the product safely. Hand the
battery over to the applicable collection point for the
recycling of waste batteries.
For more detailed information about recycling of this
product or battery, please contact your local Civic Office,
your household waste disposal service or the shop where
you purchased the product.
On Bluetooth communication
Bluetooth wireless technology operates within a range of
about 10 meters.
Maximum communication range may vary depending
on obstacles (human body, metal, wall, etc.) or
electromagnetic environment.
The unit
Steel cabinet
Optimal performance
Limited performance
The following conditions may affect the sensitivity of
Bluetooth communication.
— There is an obstacle such as a person, metal, or wall
between this unit and iPod.
— A device using 2.4 GHz frequency, such as a wireless
LAN device, cordless telephone, or microwave oven,
is in use near the unit.
— The unit is installed on a shelf made of steel.
Because Bluetooth devices and wireless LAN
(IEEE802.11b/g/n) use the same frequency, microwave
interference may occur and resulting in communication
speed deterioration, noise, or invalid connection if this
unit is used near a wireless LAN device. In such a case,
perform the following.
— Use this unit at least 10 m away from any wireless
LAN device.
— If this unit is used within 10 m of a wireless LAN
device, turn off the wireless LAN device.
— Install this unit and iPod as near to each other as
possible.
Microwaves emitting from a Bluetooth device may affect
the operation of electronic medical devices. Turn off this
unit and iPod in the following locations, as it may cause
an accident.
— where inflammable gas is present, in a hospital, train,
airplane, or a petrol station
— near automatic doors or a fire alarm
This unit supports security capabilities that comply with
the Bluetooth standard to provide a secure connection
when the Bluetooth wireless technology is used, but
security may be insufficient, depending on the setting.
Be careful when communicating using Bluetooth
wireless technology.
We do not take any responsibility for leakage of
information during Bluetooth communication.
Connection with all Bluetooth devices cannot be
guaranteed.
— A device featuring Bluetooth function is required to
conform to the Bluetooth standard specified by
Bluetooth SIG, Inc. and be authenticated.
— Even if the connected device conforms to the above
mentioned Bluetooth standard, some devices may not
be connected or work correctly, depending on the
features or specifications of the device.
Depending on the device to be connected, it may require
some time to start communication.
Note
Troubleshooting
In the Reference Guide, "iPod" is used as a general
reference to functions on an iPod, iPhone or iPad, unless
otherwise specified by the text or illustrations.
General
If you have any questions or problems concerning your
The power does not turn on when the AC adaptor is
unit, please consult your nearest Sony dealer.
connected.
Make sure the AC adaptor is connected to the wall outlet
General information
firmly.
There is no sound.
Adjust VOLUME +/− (VOL +/− on the remote).
Specifications
Noise is heard.
Ensure that the unit is not near in-use portable phones,
etc.
iPod
The power indicator flashes.
DC out: 5 V
The power indicator flashes when the unit receives a
MAX: 2.1 A
signal from the remote. In this case, the flashing does
not mean there is an error or fault.
Bluetooth
Output
When using an iPod on the Dock
Bluetooth Specification Power Class 2
Maximum communication range
There is no sound.
Line of sight approx. 10 m*
1
Make sure the iPod is connected firmly.
Make sure that the function for iPod is activated.
Frequency band
Operation is not performed.
2.4 GHz band (2.4000 GHz – 2.4835 GHz)
Make sure the iPod is connected firmly.
Communication System
Check that the iPod is compatible with this unit. (See
Bluetooth Specification Version 2.1 + EDR (Enhanced
"Dock Connector compatible models.")
Data Rate)
The iPod does not charge.
Compatible Bluetooth Profiles *
2
Make sure the iPod is connected firmly.
A2DP (Advanced Audio Distribution Profile)
Make sure the AC adaptor is connected firmly.
AVRCP*
(Audio/Video Remote Control Profile)
3
Check that the iPod is compatible with this unit. (See
Supported codec *
4
"Dock Connector compatible models. " )
SBC (Subband Codec)
*
1
The actual range will vary depending on factors such as obstacles
When using the Bluetooth connection
between devices, magnetic fields around a microwave oven,
static electricity, reception sensitivity, aerial performance,
There is no sound.
operating system, application software, etc.
Ensure that this unit is not too far from the iPod, or this
*
2
Bluetooth standard profiles provide the specifications for
unit is not receiving interference from a wireless LAN,
Bluetooth communication between devices.
other 2.4 GHz wireless device, or microwave oven.
*
3
Some operations may not be available for some models of iPod.
Check that the Bluetooth connection is made properly
*
4
Codec: Audio signal compression and conversion format
between this unit and the iPod.
Pair this unit and the iPod again.
General
Keep away from metal objects or surfaces.
Speaker
Make sure that the Bluetooth function is activated.
Woofer: Approx. 76 mm dia. × 2
Tweeter: Approx. 25 mm dia. × 2
Sound skips or the correspondence distance is short.
If a device that generates electromagnetic radiation, such
Input
as a wireless LAN, other Bluetooth device(s), or a
AUDIO IN jack (ø 3.5 mm stereo minijack)
microwave oven is nearby, move away from such
Impedance: 50 kΩ
sources.
Average input level: 245 mV
Remove any obstacle between this unit and the iPod or
Power output
move away from the obstacle.
20 W + 20 W (at 1% harmonic distortion)
Locate this unit and the iPod as close to each other as
Power source
possible.
Rated external power source: DC IN 20 V (with supplied AC
Re-position this unit.
adaptor (AC 100 V - 240 V, 50 Hz/60 Hz))
Re-position the iPod.
Dimensions
Connecting cannot be done.
Approx. 356.0 mm × 168.1 mm × 155.8 mm (w/h/d)
Perform pairing again. (See "To pair with an iPod. " )
(incl. projecting parts and controls)
Check that the iPod is compatible with this unit. (See
Mass
"Wireless music streaming compatible models. " )
Approx. 2.2 kg
Pairing cannot be done.
Supplied accessories
Bring this unit and the iPod closer together.
Remote control (with a lithium battery) (1)
Delete the unit from the iPod and perform pairing again.
AC adaptor (1)
Check that the iPod is compatible with this unit. (See
AC power cord (1)
"Wireless music streaming compatible models. " )
Reference Guide (this document) (1)
Cushion for small-size iPod (1)
Audio-in
Compatible iPod/iPhone/iPad
There is no sound.
models
Make sure the audio connecting cable is connected
firmly.
The compatible iPod/iPhone/iPad models are as follows.
Update the software of the iPod/iPhone/iPad to the latest
Make sure that the connected optional component is in
playback mode.
version before using it with this unit.
Make sure that the Audio-in function is activated.
Dock Connector compatible models
The sound is low.
iPod touch (4th generation)
Check the volume of the connected optional component.
iPod touch (3rd generation)
iPod touch (2nd generation)
Remote control
iPod nano (6th generation)*
iPod nano (5th generation)
The remote does not function.
iPod nano (4th generation)
Replace the battery in the remote with a new one if it is
iPod nano (3rd generation)
weak.
iPod classic 160GB (2009)
Make sure that you are pointing the remote at the
iPhone 4S
remote sensor on the unit.
iPhone 4
Do not cover or place any objects directly in front of the
iPhone 3GS
(Remote sensor) receiver.
iPhone 3G
Remove any obstacles in the path of the remote and the
iPad 2
unit.
iPad
Make sure the remote sensor is not exposed to strong
light such as direct sunlight or fluorescent lamp light.
Wireless music streaming compatible models
iPod touch (4th generation)
If the problem persists, consult your nearest Sony dealer.
iPod touch (3rd generation)
iPod touch (2nd generation)
Preparations
iPhone 4S
iPhone 4
iPhone 3GS
Power source
iPhone 3G
iPad 2
iPad
Auto power off
After playback of music (from an iPod on the Dock,
* The iPod nano (6th generation) cannot be controlled by the
Bluetooth connection, or optional component connected
remote when the command of "MENU, " ", " ", " and "ENTER"
to the AUDIO IN jack) has finished, and if no operation is
is pressed.
performed for about 20 minutes, the unit will
Design and specifications are subject to change without
automatically turn off.
notice.
To use the AC adaptor
1
Connect the supplied AC power cord to the AC
adaptor.
2
Connect the AC adaptor to the DC IN 20V jack
on the back of this unit firmly and plug it into a
wall outlet.
Note on the AC adaptor
Use the supplied Sony AC adaptor only. The polarity of
the plugs of other manufacturers may be different.
Failure to use the supplied AC adaptor may cause the
unit to malfunction.
Remote control
Before using the supplied remote for the first time, remove
the insulation film.
Aim the remote at the
(Remote sensor) of the unit.
The power indicator flashes when the remote's command is
received.
When to replace the battery
With normal use, the battery (CR2025) should last for about
6 months. When the remote can no longer operate the unit,
replace the battery with a new one.
side facing up
Note
If you are not going to use the remote for a long time,
remove the battery to avoid any damage that may be caused
by leakage or corrosion.
Continued on the reverse side
Advertisement
