To erase all the pairing registration
4
Select "ON" or "OFF. "
information
Press / repeatedly.
1
Select the BLUETOOTH function.
5
Turn off the system.
Press BLUETOOTH FUNCTION on the remote
Press / .
or press FUNCTION on the unit repeatedly.
When it is set to on, you can listen to music from
The function indicator flashes slowly in blue and "BT
the system that if it is turned on by operating the
AUDIO" appears in the display.
Bluetooth connection on the Bluetooth device.
When the system is connecting with a Bluetooth
Note
device, the Bluetooth device name that is set with the
If you erase the pairing information, Bluetooth Standby mode will
Bluetooth device appears.
set to off.
Press
(Bluetooth) to cancel the connected
Bluetooth device. "BT AUDIO" appears.
2
Press and hold SHIFT and CLEAR .
Using optional audio components
"DELETE" flashes.
1
Prepare the sound source.
3
.
Press
Connect additional audio component to the AUDIO
"COMPLETE" appears and all the pairing
IN jack
on the unit using an audio analog cord
information is erased.
(not supplied).
Notes
2
Turn down the volume.
If you erase the pairing information, you cannot make a Bluetooth
connection unless pairing is performed. In order to connect with
Press VOLUME
.
a Bluetooth device after performing this operation, you must enter
3
the passkey again.
Select the AUDIO IN function.
If you erase the pairing information, the Bluetooth Standby mode
Press AUDIO IN FUNCTION
on the remote or
setting is set to off.
press FUNCTION
on the unit repeatedly.
Playing music from a Bluetooth device
The function indicator lights in amber.
4
Start playback.
You can operate a Bluetooth device by connecting the
system and a Bluetooth device using AVRCP.
Start playback of the connected component and
Check the following before playing music:
adjust the volume.
The Bluetooth function of the Bluetooth device is enabled.
Note
Pairing has been completed.
The system may enter Standby mode automatically if the volume
1
Select the BLUETOOTH function.
level of the connected component is too low. Adjust the component's
volume accordingly. See "To turn off the Automatic Standby
Press BLUETOOTH FUNCTION on the remote
function. "
or press FUNCTION on the unit repeatedly.
The function indicator flashes slowly in blue and "BT
AUDIO" appears in the display.
Adjusting the sound
2
Establish connection with the Bluetooth device.
For details on operations of the Bluetooth device,
To
Press
refer to the operation manual supplied with your
Adjust the volume VOLUME +/
.
Bluetooth device.
Generate a more
BASS BOOST .
Once the connection is established, "LINKED"
dynamic sound
appears then the Bluetooth device name that is set
SOUND EFFECT repeatedly
Set the sound
with the Bluetooth device appears.
effect
until desired sound effect is
If already connected with a Bluetooth device that has
displayed.
been connected with this system in the past, you may
be connected automatically without operating the
Bluetooth device.
Changing the display
3
Start playback.
Press (or on the unit).
To
Press
Depending on the Bluetooth device, you may have to
Change
DISPLAY
repeatedly when the
press
twice.
information on
system is on.
Depending on the Bluetooth device, you may have
the display
1)
to start up the AV software of the Bluetooth device
Change Display
DISPLAY
repeatedly when the
beforehand.
mode (see below.)
system is off.
2)
4
Adjust the volume.
1)
For example, you can view CD/MP3 disc information, such as:
Press VOLUME +/ .
CD-DA disc
Other operations
remaining playing time of a track during playback
total remaining playing time
To
Press
MP3 disc
Pause playback
(or
on the
1)
1)
track or file name ("
")
unit).
artist name (" ")
album name ("
")
Stop playback
.
You can also view DAB/DAB+ station information such as the
Select a folder
service name, channel label, preset number, frequency, DLS
+/ .
(Dynamic Label Segment), or ensemble label.
Select a file
/ .
The STANDBY indicator
on the unit lights up when the system is
2)
Find a point in a file
off.
Hold down / (or
The system offers the following display modes.
/ on the unit).
1) Depending on the Bluetooth device, you may have to press
Display mode
When the system is off
1)
( on the unit) twice.
Power Saving
The display is turned off to
mode
conserve power. The timer and
Note
2)
These operations may not be available for certain Bluetooth devices.
clock continue to operate.
In addition, the actual operations may differ depending on the
Clock
3)
The clock is displayed.
connected Bluetooth device.
1)
The STANDBY indicator
on the unit lights up when the system is
To check the address of a connected Bluetooth
off.
device
You cannot set the clock in Power Saving mode.
2)
Press DISPLAY while the Bluetooth device name that
3)
The clock display automatically turns to Power Saving mode after 8
seconds.
is set with the Bluetooth device is displayed.
The Bluetooth device address appears in two
Notes on the display information
installments on the system display for 8 seconds.
Characters that cannot be displayed appear as "_. "
The following are not displayed:
To cancel the connection with a Bluetooth
total playing time for an MP3 disc.
device
total remaining playing time for an MP3 disc.
remaining playing time for an MP3 file.
Press
(Bluetooth) on the unit until "UNLINKED"
The following are not displayed correctly:
appears.
elapsed playing time of an MP3 file encoded using VBR (variable
Depending on the Bluetooth device, the connection with
bit rate).
the Bluetooth device may be cancelled automatically if
folder and file names that do not follow either the ISO9660
you stop playback.
Level 1, Level 2 or Joliet in the expansion format.
The following are displayed:
total playing time for a CD-DA disc (except when PGM mode is
Setting/Canceling Bluetooth Standby
selected and the player is stopped).
mode
remaining playing time for a track of CD-DA disc.
remaining playing time for a CD-DA disc (only when Normal
Bluetooth Standby mode can be entered when
Play mode is selected during playback).
the system goes into Wait mode for the Bluetooth
ID3 tag information for MP3 files when ID3 version 1 and
connection, even when the system is turned off.
version 2 tags are used (ID3 version 2 tag information display has
You cannot set Bluetooth Standby mode if pairing has
priority when both ID3 version 1 and version 2 tags are used for a
single MP3 file).
been not completed or the pairing information is erased.
up to 64 characters for an ID3 tag, where characters allowed are
1
Select the BLUETOOTH function.
uppercase letters (A to Z), numbers (0 to 9), and symbols (˝ $ % '
( ) * + , – . / < = > @ [ \ ] _ ` { | } ! ? ^ ~).
Press BLUETOOTH FUNCTION on the remote
or press FUNCTION on the unit repeatedly.
Notes on the DAB/DAB+ display information
The following is also displayed;
The function indicator flashes in blue.
up to 8 characters of service name, up to 128 characters of DLS
If already connected with Bluetooth device that
(Dynamic Label Segment) and up to 16 characters of ensemble
has been connected with this system in the past by
label.
(Bluetooth) to
automatic connection, press
a value between 0 and 100 indicating the signal quality is
displayed.
cancel the connected Bluetooth device. "BT AUDIO"
appears.
2
Press TOOL MENU .
Using the timers
"BT STBY" appears.
If the system has no pairing information, "NOT
The system offers 2 timer functions. If you use both
USED" flashes.
timers, the Sleep Timer has priority.
3
.
Press
"ON" or "OFF" appears.
Sleep Timer:
There is no sound.
You can fall asleep to music. This function works even if
Press VOLUME + to turn up the volume.
the clock is not set.
Make sure the headphone is not connected to the
Press and hold SHIFT
and press SLEEP
(phones) jack .
repeatedly.
Make sure additional audio components are connected
With each press of SLEEP
with SHIFT
held
correctly.
pressed, the setting time is decreased by 10 minutes,
Make sure the function is set to AUDIO IN.
from a maximum of 90 minutes to minimum of 10
Is anything blocking the ventilation holes of the
minutes. To cancel the Sleep Timer, select "OFF. "
system?
The specified station may have temporarily stopped
Play Timer:
broadcast.
You can wake up to CD, FM reception, DAB/DAB+
reception, or iPod/iPhone/iPad at a preset time. Make
Severe hum or noise.
sure you have set the clock.
Move the system away from sources of noise.
1
Prepare the sound source.
Connect the system to a different wall outlet.
Prepare the sound source, and then press VOLUME
Install a noise filter (not supplied) to the power cord.
+/ to adjust the volume.
The remote does not function.
To start from a specific CD track, audio file, and
radio station create your own program.
Remove any obstacles between the remote and the
remote sensor
on the unit, and position the unit
2
Select the timer set mode.
away from fluorescent lights.
Press and hold SHIFT
and TIMER MENU
.
Point the remote at the system's sensor
.
3
Set the play timer.
Move the remote closer to the system.
Press /
repeatedly to select "PLAY SET, " then
The STANDBY indicator
remains lit after
press
.
unplugging the power cord.
4
Set the time to start playback.
The STANDBY indicator
may not turn off
Press /
repeatedly to set the hour, then press
immediately after unplugging the power cord. The
. Use the procedure above to set the minutes.
indicator will turn off after about 40 seconds. This is
not a malfunction.
5
Use the same procedure as in step 4 to set the time
to stop playback.
CD/MP3 disc
6
Select the sound source.
Press /
repeatedly until the desired sound
The system does not eject the disc and
source appears, then press
.
"LOCKED" appears.
7
Consult your nearest Sony dealer or local authorized
Turn off the system.
Sony service facility.
Press
. The system automatically turns on
before the preset time.
The disc cannot be inserted.
If the system is on at the preset time, the Play Timer
Check that the system is turned on.
will not play. Do not operate the system from the
Do not insert a disc into the disc slot until "NO DISC"
time the system turns on until the playback starts.
appears in the display.
If the sound source is set to an FM station for a timer,
a disc that has not been finalized (a disc to which data
can be added).
the system automatically turns on 15 seconds before
the preset time. If the sound source is set to CD, the
The sound skips, or the disc will not play.
system automatically turns on 90 seconds before the
Wipe the disc clean, and replace it.
preset time. If the sound source is set to iPod/iPhone/
iPad, the system automatically turns on 30 seconds
Move the system to a location away from vibration (for
example, on top of a stable stand).
before the preset time.
Play does not start from the first track.
To check the setting
Return to normal play by pressing PLAY MODE
1
Press and hold SHIFT and TIMER MENU .
repeatedly until both "PGM" and "SHUF" disappear.
2
Press /
repeatedly to select "SELECT, " and
Starting playback takes more time than usual.
then press
.
The following discs can increase the time it takes to
3
Press /
repeatedly to select "PLAY SEL, " and
start playback:
then press
.
a disc recorded with a complicated tree structure.
To cancel the timer
a disc that has many folders.
Repeat the same procedure as above until "OFF" appears
Erroneous display.
in step 3, and then press
.
The data stored in the CD-DA, MP3 disc may have
To change the setting
been corrupted, perform the transferring again.
Start over from step 1.
The character code that can be displayed by this
system are as follows:
Notes
Upper cases (A to Z).
When the sound source for a Play Timer is set to an FM station
tuned from a preset radio station, the radio station tuning for the
Numbers (0 to 9).
Play Timer is fixed at what you set for it. Even if you change the
Symbols (< > * +, [ ] \ _).
radio station after setting the Play Timer, the radio station setting
Other characters appear as "_. "
for the Play Timer will not change.
When the sound source for a Play Timer is set to an FM station that
you set using auto tuning or manual tuning, if you change the radio
iPod/iPhone/iPad
station after setting the Play Timer, the radio station setting for the
Play Timer also will be changed.
There is no sound.
Notes for the iPod/iPhone/iPad user
Make sure the iPod/iPhone/iPad is connected securely.
Make sure the iPod/iPhone/iPad is not playing when using the Play
Make sure the iPod/iPhone/iPad is playing music.
Timer.
Make sure the iPod/iPhone/iPad is updated with the
The Play Timer may not be activated depending on the status of the
connected iPod/iPhone/iPad.
latest software. If not, update the iPod/iPhone/iPad
before using with the system.
Tip
Adjust the volume.
The Play Timer setting remains as long as the setting is not cancelled
manually.
The sound is distorted.
Make sure the iPod/iPhone/iPad is connected securely.
Troubleshooting
Turn down the volume.
Set the "EQ" setting of the iPod/iPhone/iPad to "Off "
or "Flat. "
1
Make sure the power cord is firmly connected.
The iPod/iPhone/iPad does not function.
2
Find your problem in the checklist below, and take
Shut down any other iOS applications running on the
the indicated corrective action.
iPod/iPhone/iPad. For details, refer to the operation
If the issue persists, contact your nearest Sony dealer.
manual supplied with the iPod/iPhone/iPad.
Make sure the iPod/iPhone/iPad is connected securely.
If the STANDBY indicator flashes
Make sure the iPod/iPhone/iPad is updated with the
Immediately unplug the power cord, and check the
latest software. If not, update the iPod/iPhone/iPad
following items.
before using with the system.
Is anything blocking the ventilation holes of the
Because the operation of the system and the iPod/
system?
iPhone/iPad are different, you may not operate the
Is the iPod/iPhone/iPad connector
short-
iPod/iPhone/iPad using buttons on the remote or unit.
circuited?
In this case, use the control buttons on the iPod/
iPhone/iPad.
After the STANDBY indicator
stops flashing,
reconnect the power cord, and turn on the system. If
The iPod/iPhone/iPad cannot be charged.
the issue persists, contact your nearest Sony dealer.
Make sure the iPod/iPhone/iPad is connected securely.
If you press DISPLAY while charging when the
General
system is off, the system stops charging an iPod/
iPhone/iPad. To restart charging of an iPod/iPhone/
The system does not turn on.
iPad, reconnect the iPod/iPhone/iPad when the display
mode is Power Saving mode.
Is the power cord plugged in correctly?
The ring volume of the iPhone does not
The system has entered Standby mode
change.
unexpectedly.
Adjust the ring volume on the iPhone.
This is not a malfunction. The system enters Standby
mode automatically in about 30 minutes when there is
Bluetooth device
no operation or audio signal output. See "To turn off
the Automatic Standby function. "
Pairing cannot be done.
The clock setting or the Play Timer operation
Move the Bluetooth device closer to the system.
has been cancelled unexpectedly.
Pairing may not be possible if other Bluetooth devices
If about a minute elapses with no operation, the clock
are present around the system. In this case, turn off the
setting or Play Timer setting is cancelled automatically.
other Bluetooth devices.
Perform the operation again from the beginning.
Enter the same passkey that was entered at the
when an iPod/iPhone/iPad is connected.
Bluetooth device correctly.
when a button on the remote or unit is pressed.
Connection is not possible.
To turn off the beep sound
The Bluetooth device you attempted to connect
The system is set at the factory for the key-touch
does not support the A2DP profile, and cannot be
confirmation beep to sound when you press a touch
connected with the system.
panel key on the unit. You can turn off the beep sound.
Enable the Bluetooth function of the Bluetooth device.
1
Press the / to turn on the system.
Establish a connection from the Bluetooth device.
The pairing registration information has been erased.
2
Press and hold and VOLUME – on the unit
Perform the pairing operation again.
for 3 seconds or longer.
While connected to a Bluetooth device, this system
If you want to set the beep sound to on, use the same
cannot be detected and a connection cannot be
procedure as in step 1, 2.
established from another Bluetooth device.
Note
Erase the pairing registration information of a
Even if the beep sound is set to on, the system does not
Bluetooth device and perform the pairing operation
beep to confirm key-touch while the Dock indicator
again.
is flashing, although operation of the touch panel is
The sound skips or fluctuates, or the
enabled even while the Dock indicator is flashing.
connection is lost.
The system and the Bluetooth device are too far apart.
If there are obstacles between the system and your
Messages
Bluetooth device, remove or avoid the obstacles.
If there is equipment that generates electromagnetic
radiation, such as a wireless LAN, other Bluetooth
CAN'T PLAY : You have inserted a disc that cannot be
device, or a microwave oven nearby, move them away.
played back on this system.
COMPLETE : The preset operation ended normally.
The sound of your Bluetooth device cannot be
ERROR : Unpredictable situations or an unknown device
heard on this system.
is connected.
Turn up the volume on your Bluetooth device first,
FULL : You tried to program more than 25 tracks or files
and then adjust the volume using VOLUME +/ .
(steps).
LOCKED : The disc slot does not work. Contact your
Severe hum or noise
nearest Sony dealer.
If there are obstacles between the system and your
NO DISC : There is no disc in the player, or you have
Bluetooth device, remove or avoid the obstacles.
loaded a disc that cannot be played.
If there is equipment that generates electromagnetic
NO PRESET (DAB/DAB+ only) : There is no stored
radiation, such as a wireless LAN, other Bluetooth
preset station.
device, or a microwave oven nearby, move them away.
NO SERV (DAB/DAB+ only) : There is no supported
Turn down the volume of the connected Bluetooth
DAB/DAB+ broadcast in your country or region.
device.
NO STEP : All of the programmed tracks have been
Tuner
erased.
NO SUPPORT : An unsupported iPod/iPhone/iPad is
Severe hum or noise, or stations cannot be
connected or the iPod/iPhone/iPad whose battery is
empty is connected.
received. ("TUNED" or "STEREO" flashes on the
display.)
NO TEXT (DAB/DAB+ only) : There is no text
information in the received service.
Connect the antenna properly.
NO TRACK : There are not playable files on the CD disc.
Find a location and an orientation that provide good
NOT USED : You tried to perform a specific operation
reception, and then set up the antenna again.
under conditions where that operation is prohibited.
Keep the antennas away from the power cord to avoid
PUSH STOP : You pressed PLAY MODE
during
picking up noise.
playback in the CD function.
Turn off nearby electrical equipment.
TIME NG : The Play Timer start and end times are set to
Several radio stations can be heard at the
the same time.
same time.
Find a location and an orientation that provide good
reception, and then set up the antenna again.
Precautions
Bundle the antenna cables using commercially
available cord clips, for example, and adjust the cable
lengths.
Discs that this system CAN play
DAB/DAB+ radio station is not received
Audio CD
properly.
CD-R/CD-RW (audio data/MP3 files)
Check all antenna connections, then perform the DAB
Discs that this system CANNOT play
Automatic Scan procedure (see "Reception of DAB/
DAB+ radio station").
CD-ROM
CD-R/CD-RW other than those recorded in music CD
The current DAB/DAB+ service may not be available.
Press +/
to select a different service.
format or MP3 format conforming to ISO9660 Level
1/Level 2, Joliet
If you have moved to another area, some services/
frequencies may have changed and you may not be
CD-R/CD-RW of poor recording quality,
able to tune into your usual broadcast. Perform the
CD-R/CD-RW that have scratches or are dirty,
or CD-R/CD-RW recorded with an incompatible
DAB Automatic Scan procedure to re-register the
recording device
contents of broadcasts. (Performing this procedure
clears all previously stored presets.)
CD-R/CD-RW which is finalized incorrectly
Discs containing files other than MPEG 1 Audio
The DAB/DAB+ broadcast of has been
Layer-3 (MP3) files
interrupted.
Discs of non-standard shape (for example, heart,
Check the location of the system or adjust the
square, star)
orientation of the antenna to increase the indicated
Discs that have adhesive tape, paper, or sticker
value of the signal quality. Refer to "Changing the
attached to them
display" for further details on the signal quality.
Rental or used discs with attached seals where the glue
extends beyond the seal
To reset the system to factory settings
Discs that have labels printed using ink that feels tacky
If the system still does not operate properly, reset the
when touched
system to factory settings.
Notes on discs
Use buttons on the unit to reset the system to its factory
default settings.
Before playing, wipe the disc with a cleaning cloth
1
from the center out to the edge.
Disconnect and reconnect the power cord, and
Do not clean discs with solvents, such as benzine,
then turn on the system.
thinner, or commercially available cleaners or anti-
2
Press and hold and
/
on the unit until
static spray intended for vinyl LPs.
"RESET" appears in the display.
Do not expose discs to direct sunlight or heat sources
All user-configured settings, such as preset radio
such as hot air ducts, nor leave it in a car parked in
stations, timer, and the clock, are deleted.
direct sunlight.
To turn off the Automatic Standby
On safety
function
Completely disconnect the power cord (mains lead)
from the wall outlet (mains) if it is not going to be used
This system is equipped with an Automatic Standby
for an extended period of time. When unplugging the
function. With this function, the system enters Standby
system, always grip the plug. Never pull the cord itself.
mode automatically in about 30 minutes when there is
Should any solid object or liquid get into the system,
no operation or audio signal output.
unplug the system, and have it checked by qualified
By default, the Automatic Standby function is turned on.
personnel before operating it again.
Use buttons on the unit to turn off the Automatic
The AC power cord can be changed only by a qualified
Standby function.
service facility.
Hold down
while the system is on, until
"AUTO. STBY OFF" appears.
On placement
To turn on the function, repeat the procedure until
Do not place the system in an inclined position or in
locations that are extremely hot, cold, dusty, dirty, or
"AUTO. STBY ON" appears.
humid or lacking adequate ventilation, or subject to
Notes
vibration, direct sunlight or a bright light.
"AUTO. STBY" appears in the display for 2 minutes before the
Be careful when placing the system on surfaces that
system enters Standby mode.
have been specially treated (for example, with wax, oil,
The Automatic Standby function is invalid for the tuner function
polish) as staining or discoloration of the surface may
(DAB/FM), even when you have enabled it.
The system may not enter Standby mode automatically in the
result.
following cases:
If the system is brought directly from a cold to a warm
while an audio signal is being detected.
location or is placed in a very damp room, moisture
during playback of audio tracks or files.
may condense on the lens inside the CD player, and
while the preset Sleep Timer or Play Timer is in process.
cause the system to malfunction. In this situation,
The system counts down the time again until it enters Standby
remove the disc, and leave the system turned on for
mode, even when Automatic Standby function is enabled in the
about an hour until the moisture evaporates.
following cases:
On heat buildup
Specifications
Heat buildup on the unit during operation is normal
and is not cause for alarm.
Do not touch the cabinet if it has been used
Amplifier section
continuously at a high volume because the cabinet may
Power output (rated): 16 watts + 16 watts (8 ohms at 1 kHz, 1% THD)
have become hot.
Continuous RMS power output (reference): 20 watts + 20 watts (8 ohms at
1 kHz, 10% THD)
Do not obstruct the ventilation holes.
Input
AUDIO IN (stereo mini jack): Sensitivity 700 mV, impedance 47 kilohms
On the speaker system
Outputs
This speaker system is not magnetically shielded, and
PHONES (stereo mini jack): Accepts headphones of 8 ohms or more
the picture on nearby TV sets may become magnetically
CD player section
distorted. In this situation, turn off the TV, wait 15 to
System: Compact disc and digital audio system
30 minutes, and turn it back on.
Laser Diode Properties
Emission Duration: Continuous
Laser Output*: Less than 44.6 µW
Cleaning the cabinet
* This output is the value measurement at a distance of 200 mm from the
Clean this system with a soft cloth slightly moistened
objective lens surface on the Optical Pick-up Block with 7 mm aperture.
Frequency response: 20 Hz 20 kHz
with a mild detergent solution. Do not use any type of
Signal-to-noise ratio: More than 90 dB
abrasive pads, scouring powder, or solvents, such as
Dynamic range: More than 90 dB
thinner, benzine, or alcohol.
Tuner section
FM stereo, FM superheterodyne tuner
Antenna: FM lead antenna
Tuning range:
87.5 MHz 108.0 MHz (50 kHz step)
Bluetooth wireless technology
DAB/DAB+ tuner section:
FM stereo, DAB/FM superheterodyne tuner
Frequency range*
Bluetooth wireless technology is a short-range wireless
Band-III: 174.928 (5A) MHz 239.200 (13F) MHz
technology linking digital devices, such as personal
* For details, see "DAB/DAB+ frequency table" below.
Antenna: DAB/FM lead antenna
computers and digital still cameras. Using the Bluetooth
The DAB/DAB+ services are available only in countries/regions that
wireless technology, you can operate the units involved
support DAB/DAB+ services.
within a range of about 10 meters.
DAB/DAB+ frequency table (Band-III)
The Bluetooth wireless technology is commonly
Frequency
Label
Frequency
Label
used between two devices, but a single device can be
174.928 MHz
5A
209.936 MHz
10A
connected to multiple devices.
176.640 MHz
5B
211.648 MHz
10B
You do not need wires to get connected as you do with
a USB connection, and you do not need to place the
178.352 MHz
5C
213.360 MHz
10C
devices face to face as you do with wireless infrared
180.064 MHz
5D
215.072 MHz
10D
technology. You can use the technology with one
181.936 MHz
6A
216.928 MHz
11A
Bluetooth device in your bag or pocket.
183.648 MHz
6B
218.640 MHz
11B
Bluetooth wireless technology is a global standard
185.360 MHz
6C
220.352 MHz
11C
supported by thousands of companies. These companies
187.072 MHz
6D
222.064 MHz
11D
produce products that meet the global standard.
188.928 MHz
7A
223.936 MHz
12A
190.640 MHz
7B
225.648 MHz
12B
Supported Bluetooth version and profiles
192.352 MHz
7C
227.360 MHz
12C
Profile refers to a standard set of capabilities for various
194.064 MHz
7D
229.072 MHz
12D
195.936 MHz
8A
230.784 MHz
13A
Bluetooth product capabilities. This system supports the
following Bluetooth version and profiles.
197.648 MHz
8B
232.496 MHz
13B
Supported Bluetooth version:
199.360 MHz
8C
234.208 MHz
13C
Bluetooth Standard version 2.0
201.072 MHz
8D
235.776 MHz
13D
202.928 MHz
9A
237.488 MHz
13E
Supported Bluetooth profiles:
204.640 MHz
9B
239.200 MHz
13F
A2DP (Advanced Audio Distribution Profile)
206.352 MHz
9C
AVRCP (Audio Video Remote Control Profile)
208.064 MHz
9D
Effective communication range
* Frequencies are displayed to two decimal places on this system.
iPod/iPhone/iPad section
Bluetooth devices should be used within approximately
Compatible iPod/iPhone/iPad models:
10 meters (unobstructed distance) of each other. The
iPod touch 4th generation
iPod touch 3rd generation
effective communication range may become shorter
iPod touch 2nd generation
under the following conditions.
iPod nano 6th generation
When a person, metal object, wall or other
iPod nano 5th generation (video camera)
iPod nano 4th generation (video)
obstruction is between the devices with a Bluetooth
iPod nano 3rd generation (video)
connection
iPod classic 160 GB (2009)
Locations where a wireless LAN is installed
iPhone 4S
Around microwave ovens that are in use
iPhone 4
iPhone 3GS
Locations where other electromagnetic waves occur
iPhone 3G
iPad2
Effects of other devices
iPad
"Made for iPod, " "Made for iPhone, " and "Made for iPad" mean that an
Bluetooth devices and wireless LAN (IEEE 802.11b/g)
electronic accessory has been designed to connect specifically to iPod, iPhone,
use the same frequency band (2.4 GHz). When using
or iPad, respectively, and has been certified by the developer to meet Apple
your Bluetooth device near a device with wireless LAN
performance standards. Apple is not responsible for the operation of this
device or its compliance with safety and regulatory standards. Please note
capability, electromagnetic interference may occur.
that the use of this accessory with iPod, iPhone, or iPad may affect wireless
This could result in lower data transfer rates, noise, or
performance.
inability to connect. If this happens, try the following
Bluetooth section
remedies:
Communication system:
Bluetooth Standard version 2.1+EDR (Enhanced Data Rate)
Try connecting this system and Bluetooth mobile
Output:
phone or Bluetooth device when you are at least 10
Bluetooth Standard Power Class 2
meters away from the wireless LAN equipment.
Maximum communication range:
Line of sight approx. 10 m
*1
Turn off the power to the wireless LAN equipment
Frequency band:
when using your Bluetooth device within 10 meters
2.4 GHz band (2.4000 GHz - 2.4835 GHz)
Modulation method:
FHSS
Effects on other devices
Compatible Bluetooth profiles
*2
:
A2DP (Advanced Audio Distribution Profile)
The radio waves broadcast by this system may interfere
AVRCP 1.3 (Audio Video Remote Control Profile)
with the operation of some medical devices. Since this
Supported codecs:
Receive: SBC (Sub Band Codec)
interference may result in malfunction, always turn off
Transmit: SBC (Sub Band Codec)
the power on this system, Bluetooth mobile phone and
1)
The actual range will vary depending on factors such as obstacles between
Bluetooth device in the following locations:
devices, magnetic fields around a microwave oven, static electricity,
reception sensitivity, antenna's performance, operating system, software
In hospitals, on trains, in airplanes, at gas stations,
application, etc.
and any place where flammable gasses may be
2)
Bluetooth standard profiles indicate the purpose of Bluetooth
present
communication between devices.
Near automatic doors or fire alarms
Speaker section
Full-range speaker: 65 mm, cone type
Notes
Passive radiator: 67 mm × 108 mm
Rated impedance: 8 ohms
This system supports security functions that comply with the
Bluetooth specification as a means of ensuring security during
General
communication using Bluetooth technology. However, this security
Power requirements:
may be insufficient depending on the setting contents and other
AC adapter
Input: 100 V 240 V AC, 50/60 Hz
factors, so always be careful when performing communication
Output: DC 19.5 V 3.9A
using Bluetooth technology.
Power consumption: 32 watts
Sony cannot be held liable in any way for damages or other loss
Dimensions (W/H/D):
resulting from information leaks during communication using
Approx. 449 mm × 212 mm × 137 (95) mm (incl. protruding parts)
Bluetooth technology.
Mass: Approx. 2.8 kg
Bluetooth communication is not necessarily guaranteed with all
Quantity of the main unit: 1 piece
Bluetooth devices that have the same profile as this system.
Supplied accessories: Remote Commander (1), AC adapter (1),
Bluetooth devices connected with this system must comply with
Power cord (1), DAB/FM lead antenna (1), Protective cushion (2),
the Bluetooth specification prescribed by the Bluetooth SIG, Inc.,
R6 (Size AA) batteries (2)
and must be certified to comply. However, even when a device
Design and specifications are subject to change without notice.
complies with the Bluetooth specification, there may be cases where
the characteristics or specifications of the Bluetooth device make it
impossible to connect, or may result in different control methods,
Standby power consumption: 0.5 W
display or operation.
Noise may occur or the audio may cut off depending on the
Bluetooth device connected with this system, the communications
environment, or surrounding conditions.
Advertisement
