Dell™ Inspiron™ 1764
Comprehensive Specifications
This document provides information that you may need when setting up,
updating drivers for, and upgrading your computer.
NOTE:
Offerings may vary by region. For more information regarding the configuration
of your computer, click Start
information about your computer.
Processor
Type
L1 cache
L2 cache
L3 cache
Computer Information
System chipset
Data bus width
DRAM bus width
Flash EPROM
December 2009
→ Help and Support and select the option to view
®
Intel
Core™ i5
Intel Core i3
32-KB instruction and 32-KB data
first-level cache for each core
256-KB shared instruction/data
second-level cache for each core
Up to 4-MB shared instruction/data
third-level cache shared among all cores
Intel HM55
64 bits
64 bits
4 MB

Advertisement

   Also See for Dell Inspiron 1764

   Summary of Contents for Dell Inspiron 1764

  • Page 1

    Dell™ Inspiron™ 1764 Comprehensive Specifications This document provides information that you may need when setting up, updating drivers for, and upgrading your computer. NOTE: Offerings may vary by region. For more information regarding the configuration → Help and Support and select the option to view of your computer, click Start information about your computer.

  • Page 2

    Memory type DDR3 1066 MHz Memory configurations 2 GB, 3 GB, 4 GB, 6 GB, and 8 GB NOTE: For instructions on upgrading memory, see the Service Manual at support.dell.com/manuals. Connectors Audio one microphone-in connector one stereo headphone/speaker connector Mini-Card...

  • Page 3

    Communications Modem interface (optional) External V.92 56K USB modem Network adapter 10/100 Ethernet LAN on system board Wireless internal WLAN Mini-Card with WiFi ® 802.11a/b/g/n, and Bluetooth wireless technology Video Discrete video type integrated on system board Discrete video controller and memory ATI M92-LP 512 MB DDR3 ATI Park 1 GB DDR3 UMA video type...

  • Page 4

    Vertical viewing angle 15/30 (H/L) Pixel pitch 0.252 x 0.252 mm Controls brightness can be controlled through keyboard shortcuts (see the Dell Technology Guide for more information) Keyboard Number of keys 102 (U.S. and Canada): 103 (Europe); 106 (Japan); 105 (Brazil)

  • Page 5

    Battery 6-cell “smart” lithium ion Depth 53.12 mm (2.09 inches) Height 22.3 mm (0.88 inches) Width 274.5 mm (10.8 inches) Weight 0.35 kg (0.77 lb) 9-cell “smart” lithium ion Depth 53.12 mm (2.09 inches) Height 42.9 mm (1.69 inches) Width 314.45 mm (12.38 inches) Weight 0.52 kg (1.15 lb)

  • Page 6

    (continued) AC Adapter Rated output voltage 19.5 1 VDC ± Temperature range Operating 0° to 35°C (32° to 95°F) Storage –40° to 65°C (–40° to 149°F) Physical Height 20.8 mm to 33.3 mm (0.8 inches to 1.3 inches) Width 420.0 mm (16.53 inches) Depth 276.0 mm (10.86 inches) Weight (with 6-cell battery)

  • Page 7

    Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden. Trademarks used in this text: Dell, the DELL logo, and Inspiron are trademarks of Dell Inc.; Intel is a registered trademark and Core is a trademark of Intel Corporation in the U.S. and other countries; Microsoft, Windows, and the Windows Vista start button logo are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries;...
