Dynasty Spas 2006 Owner's Manual

Dynasty spas generic hot tub owners manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

OWNER'S MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Dynasty Spas 2006

Summary of Contents for Dynasty Spas 2006

  • Page 1 OWNER’S MANUAL...

  • Page 2: Owner's Information

    Dynasty Spa. Please call your local Dynasty Spa Dealer if you have any questions or problems. If they are unavailable, please feel free to call the Dynasty Spas - 2 - Customer Service Group at: 800-951-6224.

  • Page 3: Table Of Contents

    Table Of Contents Owner’s Information ...2 Safety Instructions ...5 Basic Introductory Information...7 Set-Up & Delivery Guidelines ...8 Wiring Diagram ...10 Pre-Operation Instructions ...11 General Controls & Valves ...12 Filter Location ...14 Filter Maintenance ...15 Water Care ...16 Draining Your Spa...20 Winterizing Your Spa ...21 Cover Maintenance ...22 Trouble Shooting Guide...23...
  • Page 4 Thank you for your business and your confidence in our company. We look forward to serving you! Sincerely, Mike Deans President, Dynasty Spas Dynasty Spas 101 Dynasty Way Athens, Tennessee 37303 www.dynastyspas.com...

  • Page 5: Safety Instructions

    Important Safety Instructions When installing and using this electrical equipment, basic safety precautions should be followed, including the following: 1) READ AND FOLLOW ALL INSTRUCTIONS. 2) WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times. Keep spa cover locked when not in use.
  • Page 6 • Unawareness of impending hazards • Fetal injury in pregnant women • Physical inability to exit the spa or hot tub • Unconsciousness resulting in the potential of drowning. 9) Never touch or come in contact with any electrical accessory when in your spa or when your body is wet.

  • Page 7: Basic Introductory Information

    Basic Introductory Information Congratulations on the purchase of your new spa. Our goal is to provide you with a warm and relaxing spa which incorporates a soothing water massage. In order to maximize the pleasure of your spa, you will need to understand how it works.

  • Page 8: Set-Up & Delivery Guidelines

    Set-up And Delivery Guidelines Getting Ready For Delivery & Set-up Of Your New Spa Surface And Pad Requirements • Your new portable spa must be placed on a uniformly firm, flat, and level surface. A concrete pad 4 inches thick is best. •...
  • Page 9 Set-up And Delivery Guidelines (cont.) Getting Ready For Delivery & Set-up Of Your New Spa Electrical Requirements • Your 220 Volt spa pack will require a 50 amp dedicated GFCI, load neutral, circuit breaker. • Extension cords are not to be used in conjunction with operation of the spa.

  • Page 10: Wiring Diagram

    Wiring Requirements • 2-Hots, 1-Neutral, 1-Isolated Ground • (under 40 ft wire length) 4 Wire #8 AWG solid copper conductor • (over 40 ft wire length) 4 Wire #6 AWG solid copper conductor Factory Recommended G.F.C.I. Load Center Wiring - 10 - Wiring Diagram Note: The white neutral wire from the back of the GFCI MUST be...

  • Page 11: Pre-Operation Instructions

    General Pre-Operation Instructions Priming Pump For Electric Packs The Power pack system is located under the skirting. The equipment can be serviced by simply removing the door. The door is located on the side of the spa where three panels are located, usually on the side of the spa with the lounger, or the side where the topside control panel is located.

  • Page 12: General Controls & Valves

    Air Controls & Diverter Valve Controls Air Control Each spa is equipped with air controls (venturies). The purpose of these controls is to regulate the mixture of air and water that flows through the jets. If an optional blower is installed, air is also pushed through the air controls (venturies) for maximum output.

  • Page 13: Waterfall Control

    Other General Controls Individual Jet Operation Individual jets can be turned on and off. This is done by simply turning the outer jet housing. Turning clockwise will turn the jet on, and turning counterclockwise will turn the jet off. Individual jet control can be done independently from normal diverter valve settings.

  • Page 14: Filter Location

    Filter Location Single and Dual Filter Location Single Filter Location (Baron Only) - 14 -...

  • Page 15: Filter Maintenance

    Filtration starts as soon as water flow is steady through the filter. The filter cartridge removes body oil and debris from the spa water, as they can cause flow resistance. A dirty cartridge will decrease flow and may prevent the spa from heating properly. Therefore, regular filter cleaning is essential.

  • Page 16: Water Care

    Keeping Your Spa Water Clean & Fresh Cleaning Your Spa Water You need to keep your spa clean and ready to use. When you enter your spa, you bring in as much contamination as 50 people would in a normal size swimming pool! Because your spa is such a small, enclosed environment, it needs to be a sanitary place.
  • Page 17 Take a one liter sample to the store and they will advise you on the products necessary to properly balance and care for your spa. Unbalanced spa water can quickly damage your equipment. Your Dynasty Spas Dealer will advise you on how to protect your investment. Balance Spa water must have the correct chemical balance.
  • Page 18 Keeping Your Spa Water Clean & Fresh Monthly - For Equipment Protection CALCIUM BOOSTER (If Needed) - Calcium booster treats the water if low calcium hardness is a problem in your area. It will help prevent equipment corrosion and foaming by raising the spa's water hardness level to an acceptable range of 120 ppm.
  • Page 19 Keeping Your Spa Water Clean & Fresh Mineral Protection STAIN & SCALE REMOVER - This prevents staining, rust and corrosion, caused by metals in the source water. One bottle will treat up to 500 gallons for up to 3 months. Foam Control To control foaming, use SPA FOAM DOWN.

  • Page 20: Draining Your Spa

    Draining Your Spa Because your spa holds a relatively small amount of water, contaminants such as body oil, perspiration, dirt, hair, etc., may become quite concentrated. For this reason, the water should be drained and replaced every three months depending on use. •...

  • Page 21: Winterizing Your Spa

    In areas of the country where the temperatures drop below 32° F, it is important to follow these directions: When winterizing the spa, we recommend putting RV Antifreeze in the spa and running it before draining the spa. 1) If the spa is not going to be used, drain completely. Be sure all water is removed.

  • Page 22: Cover Maintenance

    Maintaining Your Spa Cover Proper Maintenance For Your Dynasty Spa Cover 1) Use a soft broom to remove accumulation after every snowfall or ice storm. 2) Splash cool tap water on the hardware to free them if they become frozen shut. WD-40™ will keep the lock free, but apply carefully because it can damage the cabinet finish.

  • Page 23: Trouble Shooting Guide

    Trouble Shooting Guide No heat or heat too low Probable Cause #1 ...Dirty Filter. Action ...Remove filter cartridge and clean. Probable Cause #2 ...Breaker at house off. Action ...Reset breaker at house. Breaker can appear to be Probable Cause #3 ...Pump not primed. Action ...Refer to the section of this manual on pump Probable Cause #4 ...Improper line voltage.
  • Page 24 Trouble Shooting Guide (cont.) Probably Cause #4 ...Individual jet is closed. Action ...Turn the outer jet housing clockwise to turn jet on. Low water flow Probable Cause #1 ...Dirty Filter. Action ...Remove filter cartridge and clean. Probable Cause #2 ...Closed gate valves or blocked lines. Action ...Open all gate valves.

  • Page 25: Glossary Of Terms

    Air Blower...The air blower supplies air to the jets creating a Air Loop...A back up system for the check valve, prevents Air Control or Venturi...Mounted on the lip of the spa or at the equipment Cabinet ...The natural or synthetic wood panels that surround Check Valve ...Prevents back flow of water through system.
  • Page 26 Glossary of Terms (cont.) Hose Bib...Used in the draining of the spa, fits a standard Jets...The fittings on your spa that direct the flow of Ozone...A water purification supplement method using pH...Stands for "Potential for Hydrogen" This is the Skimmer ...The skimmer removes surface debris, allowing - 26 - garden hose.
  • Page 27 Notes - 27 -...
  • Page 28 Dynasty Spas 101 Dynasty Way Athens, TN 37303 www.dynastyspas.com ©2006 Dynasty Spas, Inc. All rights reserved. Dynasty Spas reserves the right to make product modifications and enhancements.
