  • Page 1 Warranty Assistance For reference, also attach your receipt or a copy of your receipt to the manual. Owner’s Guide and Installation Manual __________________________________________ Model Name __________________________________________ Model No. __________________________________________ Date Purchased __________________________________________ Where Purchased Form# 42507-01 20090908 ©2009 Hunter Fan Co.
  • Page 2: Table Of Contents

    9 • Troubleshooting....16 • To reduce the risk of fire, electrical shock, or motor damage, do not use a solid-state speed control with this fan. Use only Hunter speed controls.
  • Page 3 Support Brace Hunter’s patented 3-position mounting system provides you maximum installation flexibility and ease. You can install your Hunter fan in one of three ways, depending on ceiling height and your preference: Low Profile, Standard, or Angled mounting. The steps in this manual include Ceiling instructions for all three Installer’s Choice mounting methods.
  • Page 4: Getting Ready

    • Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: •...
  • Page 5: Installing The Ceiling Plate

    Do not over tighten. Flat Washer 3” Wood For Angled Ceilings: Be sure to Screw orient the ceiling plate so that the arrows printed on the ceiling plate are pointing toward the ceiling peak. 42507-01 • 09/08/09 • Hunter Fan Company...
  • Page 6: Assembling And Hanging The Fan

    The arrows on the downrod and on the Downrod ceiling plate should both be pointing toward the tab hole on the with Hook Step 3-4 canopy. Go to 4 • Wiring the Fan. 42507-01 • 09/08/09 • Hunter Fan Company...
  • Page 7 3-10. Align the holes in the washer with the holes in the adapter. Assemble securely with three low profile screws. 3-11. Raise the fan and place the hook on the adapter through the loop on the ceiling plate. Low Profile Screw Loop Step 3-11 42507-01 • 09/08/09 • Hunter Fan Company...
  • Page 8: Wiring The Fan

    • The black wire from the ceiling to the black and the black/ white wire from the fan 4-2. Push all wires and wire connectors back through the ceiling plate hole into the outlet box. 42507-01 • 09/08/09 • Hunter Fan Company...
  • Page 9: Ring

    2. Press firmly on opposite sides of the ring toward the canopy. The tabs will flex out releasing the trim ring from the canopy. Canopy Screw Step 5-4 42507-01 • 09/08/09 • Hunter Fan Company...
  • Page 10: Assembling The Blades

    6 • Assembling the Blades Hunter fans use several styles of fan blade irons (brackets that hold the blade to the fan). 6-1. Your fan may include blade grommets. If your fan has grommets, Step 6-1 (Detail) insert them by hand into the holes on the blades.
  • Page 11: Completing Your Installation With Or Without A Bowl Light Fixture

    7 • Completing Your Installation With or Without a Bowl Light Fixture Your Hunter fan comes with an integrated light fixture assembly and an optional switch housing cap and plug button. This feature gives you the option of installing the fan with OR without the included light fixture.
  • Page 12 Plug maximum of 190 Watts. Exceeding that limit or the marked Connector Detail limit on this product may result in fire hazard or improper operation. Housing Assembly Screw 42507-01 • 09/08/09 • Hunter Fan Company...
  • Page 13 (You may find the Light Bulbs plastic breakaway connector on the (B10 Candelabra end of the extra chain.) Base 60 Watt Maximum) Metal Rod Metal Disk Glass Bowl Cover Plate Breakaway Finial Connector 42507-01 • 09/08/09 • Hunter Fan Company...
  • Page 14 7-20. Install the switch housing cap and plug button to the lower switch housing. 7-21. Once you have uninstalled the light fixture, continue Step 7-18 with step 7-6. Male Dummy Terminal Female Dummy Terminal Plug Button Step 7-20 42507-01 • 09/08/09 • Hunter Fan Company...
  • Page 15: Fan

    To Change Airflow Direction Turn the fan off and let it come to a complete stop. Slide the reversing switch on the fan to the opposite position. Restart fan. Reversing Switch 42507-01 • 09/08/09 • Hunter Fan Company...
  • Page 16: Troubleshooting

    888-830-1326 (In Canada, call 1-866-268-1936) or Wait 30 seconds, then resume power to the fan. visit us at our Web site at http://www.hunterfan.com. Hunter Fan Company 7130 Goodlett Farms Pkwy. #400 Memphis, Tennessee 38016 42507-01 • 09/08/09 • Hunter Fan Company...
