Compaq ProSignia 500 Illustrated Parts Catalog

Compaq ProSignia 500 Illustrated Parts Catalog

Compaq prosignia 500 family of pc servers addendum to the maintenance and service guide
Hide thumbs Also See for ProSignia 500:

Advertisement

Quick Links

Download this manual See also: Maintenance and Service Manual, Reference Manual
Addendum
Publication Date: October 1994
Document Name:
Addendum to the Maintenance and Service Guide ProSignia
500 Family of PC Servers (Document Number: 144257-001)
Document Number:
188389-001
This addendum only provides specific information for the Compaq ProSignia
500 Family of Servers.
Compaq ProSignia PC Servers (144257-001) for general procedures not found
in this addendum.
o Illustrated Parts Catalog
- System Exploded View
- Spares Parts List
o Removal and Replacement Procedures
- Removing the Side Access Panel
- Removing the Air Baffle
- Memory
- Option Boards
- Mass Storage Devices
- Removable Media Storage
- Drive Installation Guidelines
- Mass Storage Devices in the Removable Media Area
- External Storage
- Cabling
- Miscellaneous Parts
- Battery Replacement
o Switch and Jumper Settings
- System Board
- SCSI Devices
o Physical and Operating Specifications
- CD-ROM Drive
Illustrated Parts Catalog
This section provides an illustrated parts breakdown and a spare parts list
for the Compaq ProSignia 500 Family of Servers.
Refer to the Maintenance and Service Guide for

Advertisement

loading
Need help?

Need help?

Do you have a question about the ProSignia 500 and is the answer not in the manual?

Questions and answers

Related Manuals for Compaq ProSignia 500

Summary of Contents for Compaq ProSignia 500

  • Page 1 500 Family of PC Servers (Document Number: 144257-001) Document Number: 188389-001 This addendum only provides specific information for the Compaq ProSignia 500 Family of Servers. Refer to the Maintenance and Service Guide for Compaq ProSignia PC Servers (144257-001) for general procedures not found in this addendum.
  • Page 2 Table 1. Spares Parts List =========================================================================== Item Description Part Number =========================================================================== CHASSIS ------- CPU Chassis 211412-001 System Unit Hood 144208-001 * Access Panel 144210-001 * Front Bezel 211414-001 * Fan Assembly 211410-001 * Speaker Assembly (includes board guide) 211411-001 Power/Drive LED Bracket 119853-001 Blank Bezel, 1/2 Height 116793-001 *...

  • Page 3: System Components

    120 MHz Processor Board without processor 169174-002 * 120 MHz Processor with heatsink 222906-001 * 32-Bit Fast-SCSI-2 Controller Board 142040-001 * Compaq SMART SCSI Array Controller Board 142130-001 * 32-Bit NetFlex Controller Board 142041-001 * DualSpeed Token Ring Module 142042-001 *...

  • Page 4: Cable Kits

    MEMORY ------ 4-MB Memory Module (70 ns) 141754-001 4-MB Memory Module (60 ns) 139139-001 8-MB Memory Module (70 ns) 141755-001 8-MB Memory Module (60 ns) 139140-001 16-MB Memory Module (70 ns) 149947-001 16-MB Memory Module (60 ns) 139141-001 32-MB Memory Module (70 ns) 149948-001 32-MB Memory Module (60 ns) 139142-001...
  • Page 5 Item Description Part Number --------------------------------------------------------------------------- Spacesaver Keyboard, Arabic 160648-236 * Spacesaver Keyboard, Belgian 160648-218 * Spacesaver Keyboard, Japanese 160648-219 * Spacesaver Keyboard, BHCSY ** 160648-220 * Spacesaver Keyboard, Hungarian 160648-221 * Spacesaver Keyboard, Polish 160648-222 * Spacesaver Keyboard, Slovakian 160648-223 * Spacesaver Keyboard, Russian 160648-224 * Spacesaver Keyboard, Czech...
  • Page 6 1. Turn the computer and any peripheral devices off. 2. Disconnect the AC power cord from the AC outlet then from the system unit. 3. Disconnect all external peripheral devices from the computer. Removing the Side Access Panel To remove the Side Access Panel: 1.
  • Page 7 Removing the Air Baffle To remove the Air Baffle: 1. Remove the Side Access Panel. 2. Push in locking tab [A] and swing the right side of the Air Baffle out and away from the chassis [B]. 3. Using a flat-head screwdriver pry and lift the bottom hinge off. 4.
  • Page 8 >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>><<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<< Memory The Compaq ProSignia 500 Family of Servers comes standard with 16 MB of system memory. Memory can be expanded to a maximum of 144 MB by installing industry standard SIMMs (Single Inline Memory Modules) on the processor board.
  • Page 9 o Install SIMM pairs in slots J2 and J4 second. o SIMM modules must be 70 ns or faster. Do not install 80 ns SIMMs in the server. >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>> CAUTION <<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<< Use only JEDEC standard SIMMs. Non-JEDEC SIMMs may adversely affect data integrity.
  • Page 10 Option Boards The ProSignia 500 Server contains five expansion slots: o Three EISA expansion slots (slots 1, 2, and 3) o One shared EISA/PCI expansion slot (slot 4). o One dedicated PCI local bus expansion slot (slot 5) NOTE: Although there are two physical connectors (one EISA and one PCI), they are placed so that only one of the slots can have a board installed at a time.
  • Page 11 =========================================================================== Reference Component =========================================================================== Processor board slot PCI slot EISA / PCI shared slot EISA slots =========================================================================== The following illustration shows the differences between EISA, PCI, and ISA connectors:...
  • Page 12 =========================================================================== Reference Component =========================================================================== ISA board EISA board PCI board =========================================================================== Removing an Option Board Follow these instructions to remove an option board: 1. Remove any cables connected to the option board. 2. Remove retaining screw from the option board. 3.
  • Page 13 Mass Storage Devices There are a total of eight drive bays for internal mass storage devices. SCSI devices can be installed in the removable media drive bays (4, 5, or 6) [Item 1], in the side access drive bays (0, 1, 2, or 3) [Item 2], or attached to the External 32-Bit Fast-SCSI-2 port.
  • Page 14 (Bay 0 = SCSI ID 0). o If only one SCSI hard drive is used it should be installed in bay 0. o Compaq SCSI cables for the Compaq ProSignia 500 are terminated, be sure to remove all terminating jumpers from 3rd party SCSI devices.
  • Page 15 o Bays 0, 1, 2, and 3 are recommended for hard drives configured as an array. o A maximum of seven SCSI-2 devices may be added. o The SCSI ID for each device should be the same as the bay number (Bay 0 = SCSI ID 0).
  • Page 16 Hard Drives in the Side Access Drive Bays The side access drive bays provide room for four half-height 3.5 inch Fast SCSI-2 hard drives. To remove a hard drive: 1. Remove the Side Access Door. 2. Remove power and signal cables. 3.
  • Page 17 External Storage Optional mass storage devices can be connected to the Compaq ProSignia 500 by using the External Fast-SCSI-2 Port on the back of the unit, or the Fast-SCSI-2 Port on the optional Fast-SCSI-2 Controllers Cable Routing for SCSI Devices Cabling The ProSignia 500 server uses a terminated cable.
  • Page 18 Miscellaneous Parts Battery/Clock Module...
  • Page 19 >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>> CAUTION <<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<< Do NOT try to remove the battery/clock module located on the system board. The battery is permanently soldered to the board and cannot be replaced. >>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>>><<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<<< Follow these instructions to install the replacement battery: 1. Remove the Side Access Panel. 2.
  • Page 20 This chapter provides switch and jumper information for the Compaq ProSignia 500 Family of Servers. System Board Compaq ProSignia 500 switch locations on the system board are shown below. Switch SW1 is a six-position switch bank (S1-S6), which sets the security features and configuration of certain computer functions.
  • Page 21 Function Position Status =========================================================================== VIDEO DISABLE OFF * ENABLED This switch is ignored and the integrated DISABLED video is disabled if ROM detects an optional video board installed. --------------------------------------------------------------------------- CONFIGURATION LOCK OFF * DISABLED System configuration cannot be changed when ENABLED this switch is on (enabled).
  • Page 22 Below are the physical locations of jumpers ID2, ID1, and ID0 on supported SCSI options. Physical and Operating Specifications Table 4. Internal CD-ROM Specifications =========================================================================== Capacity 680 MB or greater, dependent on disc format --------------------------------------------------------------------------- Data Transfer Rate: Sustained 300 or 150 KB/sec Asynchronous 2.5 MB/sec Synchronous...
  • Page 23 All rights reserved. Printed in the U.S.A. Compaq Registered U.S. Patent and Trademark Office ProSignia 500 is a trademark of Compaq Computer Corporation. ADDENDUM TO THE MAINTENANCE AND SERVICE GUIDE PROSIGNIA FAMILY OF PC SERVERS (144257-001) First Edition (October 1994)
