30" Free-Standing Electric Range with Warming Drawer
™
Dimensions and Installation Information (in inches)
KW Rating
240V
13.8
208V
10.4
Breaker Size
40 Amps
†
Note: Check local codes for required breaker size.
†
Effective January 1, 1996, the National Electrical Code requires that new
construction (not existing) utilize a 4-conductor connection to an electric range.
Receptacle Locations
Locally approved flexible service cord or conduit must be used because terminals
are not accessible after range installation. See shaded area in drawing for location
of electrical outlet box. Recommended outlet locations allow range to be installed
directly against wall.
Note: 30" ranges conform to U.L. requirements for 0" spacing from adjacent
walls below countertops. To reduce possibility of scorching walls, engineering
recommends a minimum of 1-1/2" spacing to allow for possible extended, high-
heat, no-load heating element operation.
Installation Information: Before installing, consult installation instructions
packed with product for current dimensional data.
For answers to your Monogram,
GE Profile
®
GE
appliance questions, visit our website at
®
geappliances.com or call GE Answer Center
service, 800.626.2000.
or
™
®
All GE ranges are equipped with
Listed by
an Anti-Tip device. The installation
Underwriters
of this device is an important,
required step in the installation
Laboratories
of the range.
Specification Revised 7/11
221031
