Summary of Contents for Dukane 28A7250 ImagePro
- Page 1 28A7250 ImagePro Projector User's Manual...
-
Page 3: Table Of Contents
Table of Contents Usage Notice Precautions ... 2 Introduction About the Product ... 3 Package Overview ... 4 Installation Product Overview ... 5 Start Your Installation ... 7 Powering On/Off the Projection Display... 9 Adjusting the Image Size ... 10 User Controls User Control Overview ... -
Page 4: Usage Notice
English Usage Notice Warning- Warning- Warning- Warning- all changing instruction. Warning- Warning- Warning- Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. Turn off the product before cleaning. Use a soft cloth moistened with mild detergent to clean the display housing. Disconnect the power plug from AC outlet if the product is not being used for a long period of time. -
Page 5: Introduction About The Product
Introduction About the Product This product, designed with a high-powered metal halide lamp, is an SVGA data/ video portable projection display. The outstanding feature of it are listed as follows: 10.34lbs (4.7 kg) lightweight compact design 330-watt user replaceable metal-halide lamp Single panel 6.4”... -
Page 6: Package Overview
English Package Overview This projection display comes with all the items shown below. Check to make sure your unit is complete. Contact your dealer immediately if anything is missing. -
Page 7: Installation Product Overview
Installation Product Overview Main Unit Panel Control Buttons Keystone Correction Lens Latch Lamp Door Carrying Handle Elevator Foot Lamp Latch Power Switch Power Connector Fuse Rear Connection Ports Audio Outputs S-Video Connector Composite Video Connector Audio Inputs for Video English Lens Monitor Loop- through Connector... -
Page 8: Remote Control
English Remote Control Power on/Standby Source Selection Directional Select Keys On-Screen Menus Mouse Left Button Down Left Mouse Button Joystick (Mouse Cursor Function) * For more detailed information, please refer to “Function Descriptions” on page 13. Curtain Freeze CURTAIN FREEZE STANDBY SOURCE ZOOM OUT... -
Page 9: Start Your Installation
English Start Your Installation Connecting the Projection Display Power Cord Monitor Cable Audio Cable VGA Signal Cable Remote Receiver Cable Audio Cable Computer Mouse Port S-Video Cable RCA Audio/ Video Cable... -
Page 10: Remote Control Connections
English Remote Control Connections Follow regular setup procedures. Make sure you have a 100% compatible Microsoft Mouse and a Microsoft Mouse driver installed. Setting Up Procedure: 1. Turn off your computer. 2. Unplug the mouse from your computer.* 3. Connect the remote receiver cable to the computer and the projection display. 4. -
Page 11: Powering On/Off The Projection Display
Powering On/Off the Projection Display Powering On the Projection Display. Switch on the power; then turn on the lamp by pressing “STANDBY” button. Press the “ I ” sign of the power switch to turn on the projection display. After a few seconds, press the “Power on/Standby”... -
Page 12: Adjusting The Image Size
English Adjusting the Image Size Positioning the projection display Projection Distance Image Size (diagonal) Slide the lens latch and pop up the projection lens. Switch on the power and press the “Power on/Standby” button. See “Powering On/Off the Projection Display” on page 9 for more information. Lens Latch Adjusting the screen image. -
Page 13: User Controls
User Controls User Control Overview There are two ways for you to control the functions: panel control and remote control. Panel Control POWER ON STANDBY MENU 4 Directional Keys Remote Control Power on/Standby Source Selection Directional Select Keys On-Screen Menus Mouse Left Button Down Left Mouse Button The Joystick... -
Page 14: Osd Menus
English OSD Menus The OSD (On-Screen Display) menus will allow you to easily adjust the display functions. Press the “MENU” button for the OSD menu options. When in computer sources, the OSD will be: Language Contrast Tracking Frequency Custom Memory Audio Source Rear Projection... -
Page 15: Function Descriptions
Function Descriptions Basic Functions: Press the “Power On/Standby” button to turn on the Power On/Standby projection lamp. Menu Press “Menu” button to pop up the OSD menu. Reset Press “Reset” to return the display parameters of the current mode to its factory default settings. Enter “Enter”... - Page 16 English Ceiling Projection Lamp Reset Lamp Warning Exit Presentation Functions - computer source Pointer Freeze Curtain Zoom In/Zoom Out Contrast Choose this funtion from OSD menu for a ceiling mounted projection. After changing a new lamp, reset the lamp life timer from OSD menus.
- Page 17 Tracking Choose “Tracking” item to synchronize the signal timing of the display to that of the graphic card. When you experience an unstable or flickering image, use this function to correct it. “Frequency” is for changing the display data frequency Frequency to match the frequency of your computer’s graphic card.
- Page 18 English Presentation Functions -- video source Contrast/Brightness Color/Tint Freeze To adjust the contrast or brightness of the image, select “Contrast/Brightness” from OSD menus. To adjust the color or tint of the image, select “Color/ Tint” from OSD menus. Press the “Freeze” button to still the screen image.
-
Page 19: Appendices Troubleshooting
Appendices Troubleshooting If you are experiencing trouble with the projection display, refer to the follows. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. Press “Power on/Standby” button. Ensure all the cables and power connections are correctly and securely connected as described in the “Installation”... - Page 20 English 6. Under “Manufacturers”, select “Standard monitor types” 7. Verify that the resolution setting of the monitor display is less than or equal to 800x600. If you are using a Notebook PC: 1. You are required to implement above steps of resolution setting of computer first. 2.
-
Page 21: Maintenance
Maintenance w Changing the Lamp The projection display will detect the lamp life itself. It will show you a warning message when the lamp is used over working hours. When you see this message, change the lamp as soon as possible. Make sure the projection display has cooled for at least 30 minutes before change the lamp. - Page 22 English 3. Unscrew the two screws on the bottom of the lamp module. Then release the head screw of the lamp module. Head Screw 4. Take out the used lamp from the usage position. Take out the head of the lamp first and then the bottom.
-
Page 23: Changing The Fuse
English w Changing the Fuse Fuse Holder the Blown Fuse Fuse Changing Procedure: 1. Switch off the power and unplug the power cord. 2. Pull out the fuse holder. 3. Remove the blown fuse and then insert a new fuse. 4. -
Page 24: Specifications
English Specifications LCD Panel Lamp Display Resolution Displayable Color Image Size Projection Distance Computer Compatibility Video Compatibility H. Frequency V. Frequency Multimedia Audio Power Supply I/O Connectors Weight Dimensions (W x H x D) Environmental Safety Regulation - active matrix TFT color LCD - 6.4”... -
Page 25: Compatibility Modes
Compatibility Modes Mode IBM & VESA VGA IBM & VESA VGA IBM & VESA VGA IBM & VESA VGA IBM & VESA VGA IBM & VESA VGA IBM & VESA VGA IBM & VESA VGA IBM & VESA VGA IBM & VESA VGA VESA SVGA VESA SVGA VESA SVGA... -
Page 26: Legal Information
LEGAL INFORMATION FIVE-YEAR LIMITED WARRANTY This Dukane LCD projector is warranted to the original purchaser for a period of five (5) years from the original purchase date - in normal use and service - against defects in material and workmanship. DUKANE CORPORATION EXPRESSLY DISCLAIMS ALL OTHER WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. - Page 27 Dukane Corporation Audio Visual Products Division 2900 Dukane Drive St. Charles, IL 60174-3395 E-mail: avsales@dukane.com Phone: (630) 584-2300 Orders: (800) 676-2485 Information: (800) 676-2486 Fax: (630) 584-5156 Parts & Service: (800) 676-2487 Fax: (630) 584-0984 Audio Visual Products Part # 401-564-00...
