Before Getting Started
Kit Contents
NetCenter
network hard drive
™
!
5 ft. (1.8m) Ethernet cable
!
AC adapter with power cord
!
Installation CD with EasyLink
!
additional product documentation
Quick Install Guide
!
Vertical Stands
!
Power button
Installing the Stands
1. Place the NetCenter upside down on a
clean and steady surface.
2. Press a stand onto the bottom panel of
the unit until it snaps firmly into place.
Repeat this step for the other stand.
software utilities and
™
Power button light
1
Quick Install Guide
NetCenter Network Hard Drive
Stands
AC adapter
with power cord
Ethernet cable
Vertical stands
– 1 –
NetCenter
Quick Install Guide
Installation CD
USB 2.0 ports
Ethernet port
DC power supply socket
Reset button
Kensington security slot
2
Advertisement
Related Manuals for Western Digital WDXE1600JBN - NetCenter NAS Server
Summary of Contents for Western Digital WDXE1600JBN - NetCenter NAS Server
- Page 1 Quick Install Guide NetCenter Network Hard Drive Before Getting Started Kit Contents NetCenter NetCenter network hard drive ™ 5 ft. (1.8m) Ethernet cable Stands AC adapter Quick Install Guide AC adapter with power cord with power cord Installation CD with EasyLink software utilities and ™...
- Page 2 Connecting the NetCenter Connecting the Cables 1. Connect the AC adapter into the DC power supply socket located on the back of the NetCenter and the power cord connector into an electrical outlet. Router Power cord 2. Connect one end of the Ethernet cable into the Ethernet AC adapter port on the NetCenter and the other end directly into a router or network switch port.
- Page 3 Using NetCenter Manager NetCenter Manager allows you to set up, create, and manage shared folders, assign security settings, and edit advanced settings. To access NetCenter Manager, click Settings from the EasyLink screen and select from the following menu options for the field(s) that you wish to edit. For detailed information on NetCenter Manager, refer to the user manual in the installation CD or download it from our Web site at support.wdc.com and click Downloads.
- Page 4 20511 Lake Forest Drive Lake Forest, California 92630 U.S.A. Western Digital is a registered trademark; and WD, the WD logo, WD Essential, NetCenter, and EasyLink are trademarks of Western Digital Technologies, Inc. Other marks may be mentioned herein that belong to other companies.
