K8N-E Deluxe specifications summary

CPU
Chipset
System Bus
Memory
Expansion slots
Storage
LAN
AI Audio
AI BIOS
AI Overclocking
IEEE 1394
USB
Special features
Socket 754 for AMD Athlon™ 64 processor
Supports AMD 64 architecture that enables simultaneous
32-bit and 64-bit computing
Supports AMD Cool 'n' Quiet!™ Technology
®
NVIDIA nForce™ 3 250Gb
800 MHz
3 x 184-pin DDR DIMM sockets for up to 3GB unbuffered
ECC and non-ECC PC3200/PC2700/PC2100/PC1600
SDRAM memory
1 x AGP 8X/4X
5 x PCI
®
NVIDIA nForce™ 3 250Gb supports
- 2 x Ultra ATA 133 connector
- 2 x Serial ATA connectors
- RAID 0, RAID 1, RAID 0+1 and JBOD sets
®
Silicon Image Sil 3114 RAID controller supports
- 4 x Serial ATA connectors
- RAID 0, RAID 1, RAID 10, RAID 5, and JBOD sets
Marvell ® 88E1111 Gigabit LAN PHY
Realtek ® ALC850 8-channel CODEC
Audio Sensing and Enumeration Technology
Coaxial and Optical S/PDIF out support
ASUS CrashFree BIOS 2
ASUS Q-Fan Technology 2
ASUS Post Reporter™
CPU, Memory and AGP voltage adjustable
SFS (Stepless Frequency Selection) from 200 MHz up to
300 MHz at 1 MHz increment
Adjustable FSB/DDR ratio. Fixed AGP/PCI frequencies
ASUS JumperFree
ASUS C.P.R. (CPU Parameter Recall)
VIA VT6307 controller supports
- 2 x IEEE 1394 ports
Maximum of eight USB 2.0 ports
ASUS MyLogo2™
ASUS Multi-Language BIOS
ASUS Instant Music
ASUS EZ Flash
(continued on the next page)
