1.3 M
OTHERBOARD
Socket AM2 / AM2+
AMD Athlon 64 / Athlon 64 FX / Athlon 64 X2 /
Sempron / AM2+ processors
CPU
AMD 64 Architecture enables 32 and 64 bit
computing
Supports Hyper Transport 3.0 and Cool=n=Quiet
Support HyperTransport 3.0
FSB
Supports up to 5.2 GT/s Bandwidth
AMD 770
Chipset
AMD SB600
ITE 8718F
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Super I/O
Environment Control initiatives,
H/W Monitor
Fan Speed Controller
ITE's "Smart Guardian" function
DIMM Slots x 4
Each DIMM supports 512/1024/2048MB DDR2
Max Memory Capicity 8GB
Dual Channel Mode DDR2 memory module
Main
Supports DDR2 533 / 667 / 800
Memory
Supports DDR2 1066 (by AM2+ CPU)
Registered DIMM and ECC DIMM is not
supported
Integrated IDE Controller
IDE Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
AMD SB600 (Onboard)
Jmicro JMB362 (eSATA) (optional)
Data transfer rates up to 3 Gb/s.
SATA II SATA Version 2.0 specification compliant.
RAID 0,1,1+0 support (Onboard)
NCQ/Port-Multiplier/RAID 0,1,5,0+1 support
(eSATA) (optional)
2
F
EATURES
Ver 5.x
Socket AM2 / AM2+
AMD Athlon 64 / Athlon 64 FX / Athlon 64 X2 /
Sempron / AM2+ processors
AMD 64 Architecture enables 32 and 64 bit
computing
Supports Hyper Transport 3.0 and Cool=n=Quiet
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
AMD 770
AMD SB600
ITE 8718F
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control initiatives,
H/W Monitor
Fan Speed Controller
ITE's "Smart Guardian" function
DIMM Slots x 4
Each DIMM supports 512/1024/2048MB DDR2
Max Memory Capicity 8GB
Dual Channel Mode DDR2 memory module
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (by AM2+ CPU)
Registered DIMM and ECC DIMM is not
supported
Integrated IDE Controller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
AMD SB600 (Onboard)
Jmicro JMB362 (eSATA) (optional)
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 specification compliant.
RAID 0,1,1+0 support (Onboard)
NCQ/Port-Multiplier/RAID 0,1,5,0+1 support
(eSATA) (optional)
Ver 6.x
