FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee
that interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the
contents here and specially disclaims any implied warranties of merchantability
or fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make changes to the contents here without obligation to
notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be changed without notice and
we will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.
TA75M Setup Manual
Dichiarazione di conformità
sintetica
Ai sensi dell'art. 2 comma 3 del D.M.
275 del 30/10/2002
Si dichiara che questo prodotto è
conforme alle normative vigenti e
soddisfa i requisiti essenziali richiesti
dalle direttive
2004/108/CE, 2006/95/CE e
1999/05/CE
quando ad esso applicabili
Short Declaration of conformity
We declare this product is complying
with the laws in force and meeting all
the essential requirements as specified
by the directives
2004/108/CE, 2006/95/CE and
1999/05/CE
whenever these laws may be applied

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TA75M and is the answer not in the manual?

Questions and answers

Summary of Contents for Biostar TA75M

  • Page 1 TA75M Setup Manual FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    Table of Contents Chapter 1: Introduction ........1 Before You Start ................1 Package Checklist ................1 Motherboard Features..............2 Rear Panel Connectors ..............3 Motherboard Layout................. 4 Chapter 2: Hardware Installation ......5 Installing Central Processing Unit (CPU)........5 FAN Headers..................
  • Page 3: Chapter 1: Introduction

    TA75M CHAPTER 1: INTRODUCTION EFORE TART Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: Prepare a dry and stable working environment with sufficient lighting. Always disconnect the computer from power outlet before operation.
  • Page 4: Motherboard Features

    Motherboard Manual OTHERBOARD EATURES SPEC Socket FM1 AMD 64 Architecture enables 32 and 64 bit AMD A-Series / E2-Series processors computing AMD A75 Chipset ITE 8728 Environment Control initiatives Provides the most commonly used legacy H/W Monitor Super I/O Super I/O functionality Fan Speed Controller Low Pin Count Interface ITE's "Smart Guardian"...
  • Page 5: Rear Panel Connectors

    Provide Audio-In/Out and Mic. connection Board Size 225 mm (W) x 244 mm (L) uATX Biostar reserves the right to add or remove support OS Support Windows XP / Vista / 7 for any OS With or without notice. ANEL...
  • Page 6: Motherboard Layout

    Motherboard Manual OTHERBOARD AYOUT USB_KBMS1 CP U_FAN 1 ATXPWR2 ATX PW R 1 R J45U SB1 AUDIO1 SYS_FAN2 JSPDIFOUT1 PEX16_1 Super BAT1 PEX1_1 S ATA 2 PEX16_2 S ATA 1 PCI1 S ATA4 C odec JC MOS 1 LED_D1 LED_D2 SW_PWR1 J_C OM1 JFR ON T_U SB 3_1...
  • Page 7: Chapter 2: Hardware Installation

    TA75M CHAPTER 2: HARDWARE INSTALLATION (CPU) NSTALLING ENTRAL ROCESSING Step 1: Pull the lever toward direction A from the socket and then raise the lever up to a 90-degree angle. Step 2: Look for the white triangle on socket, and the gold triangle on CPU should point towards this white triangle.
  • Page 8 Motherboard Manual Step 3: Hold the CPU down firmly, and then close the lever toward direct B to complete the installation. Step 4: Put the CPU Fan on the CPU and buckle it. Connect the CPU FAN power cable to the CPU_FAN1. This completes the installation.
  • Page 9: Fan Headers

    TA75M FAN H EADERS These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1.
  • Page 10: Installing System Memory

    Motherboard Manual NSTALLING YSTEM EMORY A. DDR3 Modules Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot. Insert the DIMM vertically and firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated.
  • Page 11 TA75M B. Memory Capacity DIMM Socket Total Memory DDR3 Module Location Size DDR3_A1 512MB/1GB/2GB/4GB/8GB DDR3_A2 512MB/1GB/2GB/4GB/8GB Max is 32GB. DDR3_B1 512MB/1GB/2GB/4GB/8GB DDR3_B2 512MB/1GB/2GB/4GB/8GB C. Dual Channel Memory Installation Please refer to the following requirements to activate Dual Channel function: Install memory module of the same density in pairs, shown in the table.
  • Page 12: Connectors And Slots

    Motherboard Manual ONNECTORS AND LOTS SATA1~SATA6: Serial ATA Connectors The motherboard has a PCI to SATA Controller with 6 channels SATA interface, it satisfies the SATA 3.0 spec and with transfer rate of 6.0Gb/s. SATA1 SATA2 Assignment Ground Ground Ground SATA4 SATA3 ATXPWR2: ATX Power Source Connector...
  • Page 13 TA75M ATXPWR1: ATX Power Source Connector This connector allows user to connect 24-pin power connector on the ATX power supply. Assignment Assignment +3.3V +3.3V -12V +3.3V Ground Ground PS_ON Ground Ground Ground Ground Ground PW_OK Standby Voltage+5V +12V +12V Ground +3.3V...
  • Page 14 Motherboard Manual PEX16_1: PCI-Express Gen2 x16 Slot PCI-Express 2.0 compliant. Maximum theoretical realized bandwidth of 8GB/s simultaneously per direction, for an aggregate of 16GB/s totally. PCI-Express Gen2 supports a raw bit-rate of 5.0Gb/s on the data pins. 2X bandwidth over the PCI-Express 1.1 architecture. PEX1_1: PCI-Express Gen2 x1 Slot PCI-Express 2.0 compliant.
  • Page 15: Chapter 3: Headers & Jumpers Setup

    TA75M CHAPTER 3: HEADERS & JUMPERS SETUP OW TO ETUP UMPERS The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”. Pin opened...
  • Page 16: Clear Cmos Procedures

    Motherboard Manual JCMOS1: Clear CMOS Header Placing the jumper on pin2-3 allows user to restore the BIOS safe setting and the CMOS data. Please carefully follow the procedures to avoid damaging the motherboard. Pin 1-2 Close: Normal Operation (default). Pin 2-3 Close: Clear CMOS data.
  • Page 17 TA75M F_AUDIO1: Front Panel Audio Header This header allows user to connect the front audio output cable with the PC front panel. This header supports HD and AC’97 audio front panel connector. Assignment Mic Left in Ground Mic Right in...
  • Page 18 Motherboard Manual CIR1: Consumer IR Connector This header is for infrared remote control and communication. Assignment IrDA serial input Ground Ground IrDA serial output IR Power JFRONT_USB3_1: Header for USB 3.0 Ports at Front Panel This header allows user to connect additional USB cable on the PC front panel, and also can be connected with internal USB devices, like USB card reader.
  • Page 19 TA75M F_USB1/F_USB2: Headers for USB 2.0 Ports at Front Panel These headers allow user to connect additional USB cable on the PC front panel, and also can be connected with internal USB devices, like USB card reader. Assignment +5V (fused)
  • Page 20 Motherboard Manual On-Board LED Indicators There are 6 LED indicators showing system status. LED_D1 LED_D2 LED_D1 & LED_D2: Debug Indicators PH1_D1 ~ PH3_D3 / NB_PH1_D1: Power Status Indicators Please refer to the tables below for specific messages: LED_D1 LED_D2 Message Normal Memory Error VGA Error...
  • Page 21: Chapter 4: Amd Dual Graphics Technology

    TA75M CHAPTER 4: AMD DUAL GRAPHICS TECHNOLOGY AMD D RAPHICS ECHNOLOGY NTRODUCTION When user adds a PCIE display adapter, it can be integrated with IGD to show better performance. To make the two video devices work simultaneously and normally, please refer to the following setting.
  • Page 22: Amd Dual Graphics Setup

    Motherboard Manual AMD D RAPHICS ETUP Step 1: Insert Dual Graphics-Ready graphics card into PEX16_1 slot. Step 2: Set the BIOS setting as follows: [Chipset]→[North Bridge]→[Surround View]→[Enabled] Step 3: Install Driver CD Chipset Driver, and reboot the system. Activate AMD VISION Engine Control Center to make sure CrossFire has been enabled.
  • Page 23: Chapter 5: Raid Functions

    TA75M CHAPTER 5: RAID FUNCTIONS PERATING YSTEM Supports Windows Vista and Windows 7. RRAYS RAID supports the following types of RAID arrays: RAID 0: RAID 0 defines a disk striping scheme that improves disk read and write times for many applications.
  • Page 24 Motherboard Manual RAID 1: Every read and write is actually carried out in parallel across 2 disk drives in a RAID 1 array system. The mirrored (backup) copy of the data can reside on the same disk or on a second redundant drive in the array.
  • Page 25 TA75M RAID 10: RAID 1 drives can be stripped using RAID 0 techniques. Resulting in a RAID 10 solution for improved resiliency, performance and rebuild performance. Features and Benefits Drives: Minimum 4, and maximum is 6 or 8, depending on the platform.
  • Page 26: Chapter 6: T-Series Uefi Bios & Software

    Motherboard Manual CHAPTER 6: T-SERIES UEFI BIOS & SOFTWARE UEFI BIOS ERIES T-Series UEFI BIOS Features Overclocking Navigator Engine (O.N.E.) Self Recovery System (S.R.S) Smart Fan Function BIO-Flasher: Update UEFI BIOS file from USB Flash Drive !! WARNING !! For better system performance, the UEFI BIOS firmware is being continuously updated.
  • Page 27 TA75M NOTE Overclock is an optional process, but not a “must-do” process; it is not recommended for inexperienced users. Therefore, we will not be responsible for any hardware damage which may be caused by overclocking. We also would not guarantee any overclocking performance.
  • Page 28 Motherboard Manual CPU Smart FAN This item allows you to control the CPU Smart Fan function. CPU FAN Calibrate Press [ENTER] to calibrate CPU FAN. Control Mode This item provides several operation modes of the fan. Fan Ctrl OFF(℃) When CPU temperature is lower than this value, the CPU fan will keep lowest RPM.
  • Page 29: T-Series Software

    TA75M ERIES OFTWARE Installing T-Series Software 1. Insert the Setup CD to the optical drive. The drivers installation program would appear if the Auto-run function has been enabled. 2. Select Software Installation, and then click on the respective software title.
  • Page 30 Motherboard Manual The CPU tab provides information on the CPU and motherboard. The Memory tab provides information on the memory module(s). You can select memory module on a specific slot to see its information. The OC Tweaker tab allows you to change system clock settings and voltages settings.
  • Page 31 TA75M Six Pre-set Modes: V3, V6, V9, V12, V15, AUTO for different overclocking experience. (The screenshot below is for reference only) The HW Monitor tab allows you to monitor hardware voltage, fan speed, and temperature. Besides, you also can set related values for CPU Smart Fan.
  • Page 32 “Live Update.” Green Power II Utility BIOSTAR G.P.U II (Green Power Utility) is a new function. The utility enhances energy efficiency by disabling extra phases while CPU is on light loading; it features 4+1 power phases, current power saving, and toal power saving. This tool integrates a friendly GUI to monitor your CPU Usage, CPU Watt, and CPU Temperature.
  • Page 33 TA75M G.P.U Mode Setting This utility provides five modes, upon your requirements, to improve system performance or to save power consumption. Note: Even if the modes saving more power consumption are chosen, the system still can keep excellent performance. Auto Phase Mode System switches the mode automatically according to current system loading condition.
  • Page 34 Motherboard Manual eHot-Line (Optional) eHot-Line is a convenient utility that helps you to contact with our Tech-Support system. This utility will collect the system information which is useful for analyzing the problem you may have encountered, and then send these information to our tech-support department to help you fix the problem. Before you use this utility, please set Outlook Express as your default e-mail client application program.
  • Page 35 TA75M Enter the file name and then click “Save”. Your system information will be saved to a .txt file. Open the saved .txt file, you will see your system information including motherboard/BIOS/CPU/video/ device/OS information. This information is also concluded in the sent mail.
  • Page 36: Bios Update

    Motherboard Manual BIOS Update BIOS Update is a convenient utility which allows you to update your motherboard BIOS under Windows system. Show current BIOS information AWARD BIOS AMI BIOS Online Update function Clear CMOS function (Only for AMI BIOS) (Only for AWARD BIOS) Save current BIOS to a .bin file Update BIOS...
  • Page 37 TA75M <Update BIOS> Before doing this, please download the proper BIOS file from the website. For AWARD BIOS, update BIOS procedure should be run with Clear CMOS function, so please check on Clear CMOS first. Then click Update BIOS button, a dialog will show for asking you backup current BIOS.
  • Page 38 Motherboard Manual <Online Update> (for AMI BIOS only) Automatically download and update the latest BIOS via internet; make sure that the computer is connected to the internet before using this function. After clicking on the Onlinr Update button, the utility will search for the latest BIOS from internet.
  • Page 39: Chapter 7: Useful Help

    TA75M CHAPTER 7: USEFUL HELP RIVER NSTALLATION After you installed your operating system, please insert the Fully Setup Driver CD into your optical drive and install the driver for better system performance. You will see the following window after you insert the CD The setup guide will auto detect your motherboard and operating system.
  • Page 40: Extra Information

    Motherboard Manual XTRA NFORMATION CPU Overheated If the system shutdown automatically after power on system for seconds, that means the CPU protection function has been activated. When the CPU is over heated, the motherboard will shutdown automatically to avoid a damage of the CPU, and the system may not power on again.
  • Page 41: Ami Bios Beep Code

    TA75M AMI BIOS B Boot Block Beep Codes Number of Beeps Description No media present. (Insert diskette in floppy drive A:) “AMIBOOT.ROM” file not found in root directory of diskette in Insert next diskette if multiple diskettes are used for recovery...
  • Page 42: Troubleshooting

    Motherboard Manual ROUBLESHOOTING Probable Solution There is no power in the system. Make sure power cable is Power LED does not shine; the securely plugged in. fan of the power supply does not Replace cable. work Contact technical support. Indicator light on keyboard does not shine.
  • Page 43 TA75M This page is intentionally left blank.
  • Page 44: Appendix: Spec In Other Languages

    Motherboard Manual APPENDIX: SPEC IN OTHER LANGUAGES ERMAN Spezifikationen Sockel FM1 Die AMD 64-Architektur unterstützt eine 32-Bit- und AMD A-Series / E2-Series Prozessoren 64-Bit-Datenverarbeitung Chipsatz AMD A75 ITE 8728 Umgebungskontrolle, Bietet die häufig verwendeten alten Super Hardware-Überwachung Super E/A E/A-Funktionen. Lüfterdrehzahl-Controller Low Pin Count-Schnittstelle "Smart Guardian"-Funktion von ITE...
  • Page 45 Rückseiten-E DVI-D-Anschluss LAN-Anschluss USB2.0-Anschluss USB3.0-Anschluss Audioanschluss Platinengröße 225 mm (B) X 244 mm (L) Biostar behält sich das Recht vor , ohne Ankündigung OS-Unterstüt Windows XP / Vista / 7 die Unterstützung für ein Betriebssystem zung hinzuzufügen oder zu entfernen.
  • Page 46: French

    Motherboard Manual RENCH SPEC Socket FM1 L'architecture AMD 64 permet le calcul 32 et 64 bits Processeurs AMD A-Series / E2-Series Chipset AMD A75 ITE 8728 Initiatives de contrôle environnementales, Fournit la fonctionnalité de Super E/S Moniteur de matériel Super E/S patrimoniales la plus utilisée.
  • Page 47 Port USB3.0 Fiche audio Dimensions 225 mm (l) X 244 mm (H) de la carte Biostar se réserve le droit d'ajouter ou de supprimer le Support SE Windows XP / Vista / 7 support de SE avec ou sans préavis.
  • Page 48: Italian

    Motherboard Manual TALIAN SPECIFICA Socket FM1 L’architettura AMD 64 abilita la co mputazione 32 Processori AMD A-Series / E2-Series e 64 bit Chipset AMD A75 ITE 8728 Funzioni di controllo dell’ambiente: Fornisce le funzionalità legacy Super Monitoraggio hardware Super I/O I/O usate più...
  • Page 49 Porta USB3.0 Connettore audio Dimension 225 mm (larghezza) x 244 mm i scheda (altezza) Biostar si riserva il diritto di aggiungere o Sistemi operativi Windows XP / Vista / 7 rimuovere il supporto di qualsiasi sistema supportati operativo senza preavviso.
  • Page 50: Spanish

    Motherboard Manual PANISH Especificación Conector FM1 La arquitectura AMD 64 permite el procesado de 32 y Procesadores AMD A-Series / E2-Series 64 bits Conjunto de AMD A75 chips ITE 8728 Iniciativas de control de entorno, Le ofrece las funcionalidades heredadas de Monitor hardware Súper E/S uso más común Súper E/S.
  • Page 51 Tamaño de 225 mm. (A) X 244 mm. (H) la placa Soporte de Biostar se reserva el derecho de añadir o retirar el sistema Windows XP / Vista / 7 soporte de cualquier SO con o sin aviso previo. operativo...
  • Page 52: Portuguese

    Motherboard Manual ORTUGUESE ESPECIFICAÇÕES Socket FM1 A arquitectura AMD 64 permite uma computação de 32 Processadores AMD A-Series / E2-Series e 64 bits Chipset AMD A75 ITE 8728 Iniciativas para controlo do ambiente Proporciona as funcionalidades mais Especificaçã Monitorização do hardware utilizadas em termos da especificação o Super I/O Controlador da velocidade da ventoinha...
  • Page 53 Porta USB3.0 Tomada de áudio Tamanho 225 mm (L) X 244 mm (A) da placa A Biostar reserva-se o direito de adicionar ou remover Sistemas operativos Windows XP / Vista / 7 suporte para qualquer sistema operativo com ou sem suportados aviso prévio.
  • Page 54: Polish

    Motherboard Manual OLISH SPEC Socket FM1 Architektura AMD 64 umożliwia przetwarzanie 32 i 64 Procesor AMD A-Series / E2-Series Procesory bitowe Chipset AMD A75 Gniazda DDR3 DIMM x 4 Moduł pamięci DDR3 z trybem podwójnego kanału Pamięć Maks. wielkość pamięci 32GB Obsługa DDR3 800/1066/1333/1600/1866 główna Każde gniazdo DIMM obsługuje moduły...
  • Page 55 Port DVI-D Port LAN Port USB2.0 Port USB3.0 Gniazdo audio Wymiary 225 mm (S) X 244 mm (W) płyty Obsluga Biostar zastrzega sobie prawo dodawania lub systemu Windows XP / Vista / 7 odwoływania obsługi dowolnego systemu operacyjne operacyjnego bez powiadomienia.
  • Page 56: Russian

    Motherboard Manual USSIAN СПЕЦ (центральн Гнездо FM1 Архитектура AMD 64 разрешать обработка ый Процессоры AMD A-Series / E2-Series данных на 32 и 64 бит процессор) Набор AMD A75 микросхем Слоты DDR3 DIMM x 4 Модуль памяти с двухканальным режимом DDR3 Основная...
  • Page 57 USB2.0-порт ода USB3.0-порт Гнездо для подключения наушников Размер 225 мм (Ш) X 244 мм (В) панели Biostar сохраняет за собой право добавлять или Поддержка Windows XP / Vista / 7 удалять средства обеспечения для OS с или без предварительного уведомления.
  • Page 58: Arabic

    Motherboard Manual RABIC ‫اﻟﻤﻮاﺻﻔﺎت‬ ‫ﻡﻘﺒﺲ‬FM1 ‫وﺣﺪة اﻟﻤﻌﺎﻟﺠﺔ‬ ‫ﺗﻤﻜﻦ ﺗﻘﻨﻴﺔ‬AMD 64 ‫ﺏﺖ‬ ‫و‬ ‫إﺝﺮاء اﻟﻌﻤﻠﻴﺎت اﻟﺤﺎﺳﻮﺏﻴﺔ ﺏﺴﺮﻋﺔ‬ ‫اﻟﻤﺮآﺰﻳﺔ‬ ‫ﻡﻌﺎﻟﺠﺎت‬AMD A-Series / E2-Series ‫ﻋﺔ اﻟﺸﺮاﺋﺢ‬ ‫ﻡﺠﻤﻮ‬ AMD A75 ‫ﻋﺪد‬ DDR3 DIMM ‫ﻓﺘﺤﺔ‬ ‫وﺣﺪة ذاآﺮة‬DDR3 ‫ﻡﺰدوﺝﺔ اﻟﻘ‬ ‫ﻨﺎة‬ 1866 1600 1333 1066 ‫ﺗﺪﻋﻢ اﻟﺬاآﺮة ﻡﻦ ﻥﻮع‬DDR3 ‫ﺳﻌﺎت‬...
  • Page 59 TA75M ‫اﻟﻤﻮاﺻﻔﺎت‬ ‫ﻋﺪد‬ ‫اﻷﺣﻤﺮ ﺗﺤ ﺖ ﻡﺴ ﺘﻬﻠﻜﺔ‬ ‫ﻡﻨﻔﺬ‬ ‫ﻟﺘﻮﺹﻴﻞ اﻟﻄﺎﻗﺔ ﻟﻤﺮوﺣﺔ وﺣﺪة اﻟﻤﻌﺎﻟﺠﺔ ﻡﻊ وﻇﻴﻔﺔ‬Smart Fan ‫ﻋﺪد‬ ‫وﺹﻠﺔ ﻡﺮوﺣﺔ وﺣﺪة اﻟﻤﻌﺎﻟﺠﺔ اﻟﻤﺮآﺰﻳﺔ‬ ‫ﻋﺪ‬ ‫وﺹﻠﺔ ﻡﺮوﺣﺔ اﻟﻨﻈﺎم‬ ‫ﻟﺘﻮﺹﻴﻞ اﻟﻄﺎﻗﺔ ﻟﻤﺮوﺣﺔ اﻟﻨﻈﺎم‬ ‫ﻋﺪد‬ CMOS ‫وﺹﻠﺔ ﻡﺴﺢ‬ ‫ﺏﺎﻟﻠﻮﺣﺔ اﻷﻡﺎﻡﻴﺔ‬ USB2.0 ‫ﻳﺪﻋﻢ آﻞ ﻡﻨﻔﺬ ﻓﺘﺤﺘﻲ‬...
  • Page 60: Japanese

    Motherboard Manual APANESE 仕様 Socket FM1 AMD 64アーキテクチャでは、 32ビットと64ビット計算が AMD A-Series / E2-Series プロセッサ 可能です チップセット AMD A75 DDR3 DIMMスロット x 4 デュアル チャンネルモードDDR3メモリモジュール 最大メモリ容量32GB DDR3 800/1066/1333/1600/1866 をサポート メインメモリ 各DIMMは 512MB/1GB/2GB/4GB/8GB DDR3 DDR3 2000 (OC) をサポート をサポート ITE 8728 環境コントロールイニシアチブ、 もっとも一般に使用されるレガシーSuper I/O機...
  • Page 61 TA75M 仕様 CMOSクリアヘッダ 各コネクタは2つのフロントパネルUSB2.0ポートをサポ USB2.0コネクタ ートします 各コネクタは2つのフロントパネルUSB3.0ポートをサポ USB3.0コネクタ ートします プリンタポートコネクタ 各コネクタは1つのプリンタポートをサポートします シリアルポート 電源コネクタ(24ピン) 電源コネクタ(4ピン) PS/2キーボード / マウス HDMIポート VGAポート DVI-Dポート 背面パネル LANポート USB2.0ポート USB3.0ポート オーディオジャック ボードサイズ 225 mm (幅) X 244 mm (高さ) Biostarは事前のサポートなしにOSサポートを追加または OSサポート Windows XP / Vista / 7 削除する権利を留保します。...
