INSTALLATION/OWNER'S MANUAL
DVD Multimedia Receiver with 2.5" TFT Display
Safety Note:
The DVD video display of the in-dash unit will not operate while the vehicle
is moving. This is a safety feature to prevent driver distraction. In-dash DVD
video functions will only operate when vehicle is in Park and the parking
brake is engaged. It is illegal in most states for the driver to view video
while the vehicle is in motion.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dual XDVD8130
Summary of Contents for Dual XDVD8130
- Page 1 XDVD8130 INSTALLATION/OWNER'S MANUAL DVD Multimedia Receiver with 2.5” TFT Display Safety Note: The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is a safety feature to prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in Park and the parking brake is engaged.
-
Page 2: Table Of Contents
Some DVD discs can be played only in certain playback modes according to the intentions of the software. As the XDVD8130 plays discs according to their intentions, some functions may not work as intended. Please be sure to read the instructions provided with each disc. -
Page 3: Safety Information/Precautions
Please read all instructions carefully before attempting to install or operate. Due to its technical nature, it is highly recommended that your DUAL XDVD8130 is installed by a professional installer or an authorized dealer. This product is only for use in vehicles with 12VDC negative ground only. -
Page 4: Mounting/Wiring
XDVD8130 Preparation Please read entire manual before installation. Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration. - Page 5 Wiring Diagram - Inputs/Outputs FUSE When replacing the fuse, make sure new fuse is the correct type and amperage. Using an incorrect fuse could damage the radio. The XDVD8130 uses one 10 amp ATM fuse located beside the wiring connector.
- Page 6 XDVD8130 Wiring Diagram - Power/Speakers INSTALLATION Wiring Notes: Connecting the parking brake lead (Yellow/Blue - ) The Yellow/Blue lead MUST be connected for the in-dash monitor to operate properly. The DVD video display of the in-dash unit will not operate while the vehicle is moving.
- Page 7 INSTALLATION Wiring Diagram - Optional A/V Connections The diagram above illustrates the connection capabilities of the XDVD8130. Two separate Audio/Video inputs allow the connection of a DVD player or game console. The video output provides signal to external monitors - such as an overhead or headrest type. A rear view camera can be connected to provide assistance when backing up your vehicle.
-
Page 9: Control Locations - Remote
XDVD8130 Power DVD Menu Band/Play/Pause 4-Way Up 4-Way Left 4-Way Down Mute Volume Down Stop Tune/Track/Chapter Down Setup Audio Zoom XNAV9525 Power* Preset #2/System* Preset #1/Escape* Preset #4/Volume Down* Key #8/Function 2* Key #7/Function 1* Slow/Function 4* Mode Tilt Control/Video Mode... -
Page 10: General Operation
XDVD8130 General Operation Power On/Off Reset Mode Video (AUX) Notes Tilt Control (monitor angle) Volume OPERATION Press PWR or any other button (except EJECT or OPEN) to turn the unit on. Inserting a disc will turn the unit on automatically. Press PWR to turn the unit off. - Page 11 Set the Clock 12/24-hour Clock Programmable Display Priority XDVD8130 Press and hold PWR for 3 seconds to program currently selected volume level. "ON VOL" and the current volume level will momentarily appear in the display. The unit will return to this volume level anytime the unit turned on.
-
Page 12: General Operation
XDVD8130 General Operation - Audio Settings Audio Adjustments Bass Treble Balance Fader Subwoofer Output Level (When activated) Source Audio Memory Mute OPERATION Press AUD to select between Volume (default), Bass, Treble, Balance, Fader & Subwoofer (if activated). Press AUD until BAS appears Rotate encoder left/right or use the VOL ... -
Page 13: General Setup
Q-Factor Treble Control Center Frequency Tuner Frequency OSD XDVD8130 Press MENU/AUD for more than 3 seconds to access the Audio/Video setup menu and adjust the following settings: Press MENU/AUD until Beep appears. Rotate encoder to turn the confirmation beep on or off. -
Page 14: Am/Fm Tuner Operation
XDVD8130 AM/FM Tuner Operation Seek Tuning Manual Tuning Band Frequency Spacing Storing and Recalling Station Presets Automatically Store Stations Preset Scan OPERATION Press TUNE or TUNE next strong station. Press TUNE or TUNE then release. "MANU" will momentarily appear in the display. -
Page 15: Dvd Setup Menu
Some DVD discs can be played only in certain playback modes according to the intentions of the software. As the XDVD8130 plays discs according to their intentions, some functions may not work as intended. Please be sure to read the instructions provided with each disc. - Page 16 XDVD8130 General Operation - DVD Setup Menu Display Setup Page TV Aspect Display Mode Display Setup Page OPERATION Press or to select DISPLAY setup page and to select options. Press or to select 4:3 or 16:9. This option also affects the composite video output signal.
- Page 17 XDVD8130 OPERATION General Operation - DVD Setup Menu Audio Setup Page Press or to select AUDIO setup page and to select options. Press or to select Bitstream or PCM. This option is Dolby Digital only available when the Digital Output is turned on.
- Page 18 XDVD8130 DVD Setup Menu Lock Setup Page Rating (Parental Control) Password (Initial Setup) Password (Change Password) Country Code Lock Setup Page OPERATION Press or to select LOCK setup page and to select options. Press or to select desired parental control level (default setting is Unlock).
-
Page 19: Dvd Setup Menu
XDVD8130 OPERATION DVD Setup Menu Others Setup Page Press or to select OTHERS setup page and to select options. Press to load default factory settings. The DVD must be Load Default fully stopped before loading the default factory settings. -
Page 20: Dvd Operation
XDVD8130 DVD Operation Insert Disc Eject Disc Playback Start Playback Stop Playback Full Stop Pause Chapter Select Fast Forward and Reverse OPERATION Press EJECT to allow the rear panel to slide down. With the label facing up, insert a disc at least half way into the disc slot. - Page 21 Selecting DVD Subtitle Language Selecting DVD View Angles XDVD8130 Press SLOW to activate slow playback. Slow playback speed includes I 1/32, 1/16, 1/8, 1/4, and 1/2. Press / II to resume normal playback. There is no audio output during slow playback mode.
- Page 22 XDVD8130 DVD Operation DVD Display Console Direct Title Access Direct Chapter Access Optional Direct Title/ Chapter Select Method Direct Time Access DVD Audio Language DVD Subtitle Language DVD View Angle Sound Direct Title Access Direct Chapter Access Direct Time Access...
-
Page 23: Cd Operation
Fast Forward and Reverse Track Repeat Track Random Note XDVD8130 Insert a standard size CD into the disc slot. The CD will automatically begin playback when inserted. The currently playing track is shown in blue and highlighted in black. Press momentarily; the unit will stop and display II . -
Page 24: Cd Operation
XDVD8130 CD Operation Program Play Start Program Play Normal Playlist OPERATION Press or to select desired track; press to highlight the additions/deletions column. Press to add a single track to the Program playlist. Press ENTER to confirm. -
Page 25: Mp3/Wma Operation
XDVD8130 OPERATION MP3/WMA Operation Playing an MP3/WMA disc When an MP3/WMA encoded disc is first inserted, playback will automatically begin with the first file in the root folder or first folder (if there are no files in the root folder). -
Page 26: Dvd/Mp3/Wma Information
XDVD8130 DVD/MP3/WMA Information Media Compatibility Playback Order Compatible Recording Formats OPERATION The following types of discs/files are compatible: • CD-ROM (ISO), CD-R, CD-RW, DVD+R/RW, DVD-R/RW • CD-DA , DVD Video • MP3 data • WMA data The following types of discs/files are not compatible: •... - Page 27 Sampling Frequency Rates Transfer Bit rates Notes MP3/WMA Tag Display Recommended Settings XDVD8130 DVD/MP3/WMA Information An internal buffer provides ESP (Electronic Skip Protection) to virtually eliminate skipping. When playing a disc recorded with regular audio files (CD-DA or .WAV) and MP3/WMA files, the unit will play the MP3/WMA files only.
-
Page 28: Navigation/Auxiliary Modes
(sold separately). When reverse gear is selected (and the White/Brown lead is connected to the reverse lamp circuit), the XDVD8130 will automatically select V3 mode to allow the driver to monitor a video camera (sold separately) connected to the V3 input. -
Page 29: Warranty
XDVD8130 Limited One Year Warranty What to do? 1. Before you call for service, check the troubleshooting guide in your owner’s manual. -
Page 30: Troubleshooting
Activate subwoofer mode - see page 11 Increase subwoofer output level Check connections at reverse lamp Select reverse gear Replace batteries Select XDVD8130 - see page 9 Check mounting sleeve and backstrap support Check media for scratches Press eject or RESET Press eject or RESET Use only DVDs labeled “Region 1”... -
Page 31: Specifications
CEA-2006 Power Standard Specifications (reference: 14.4VDC +/- 0.2V, 20Hz~20kHz) Power Output: 17 Watts RMS x 4 channels at 4 ohms and < 1% THD+N Signal to Noise Ratio: 80dBA (reference: 1 watt into 4 ohms) XDVD8130 OPERATION Specifications 10Hz-20kHz >65dB 24 Bit 87.5MHz-107.9MHz... - Page 32 Dual Electronics Corp. Toll Free: 1-866-382-5476 www.dualav.com ©2006 Dual Electronics Corp. All rights reserved. NSA0206-V01...
