Biostar M7 VIT Test Report

Biostar M7 VIT Test Report

Engineering validation test report
Hide thumbs Also See for M7 VIT:
Table of Contents

Advertisement

Quick Links

E
NGINEERING
CHANGE CONTROL
Description of Change
Initial Release
M7VIT
Project:
Date:
2002/8/15
Owner:
Biostar Group
Contact:
TEL: 886-2-2218-0150 FAX: 886-2-2218-1552
Home Page:
1
M7 VIT
V
ALIDATION
COVER SHEET
Revision
0.9
0.91
3.0
http://www.biostar.com.tw
T
R
EST
EPORT
Sections/Pages Affected
Date
2002/8/15
2002/9/20
2002/10/22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M7 VIT and is the answer not in the manual?

Questions and answers

Related Manuals for Biostar M7 VIT

Summary of Contents for Biostar M7 VIT

  • Page 1 M7 VIT NGINEERING ALIDATION EPORT COVER SHEET CHANGE CONTROL Description of Change Revision Sections/Pages Affected Date Initial Release 2002/8/15 0.91 2002/9/20 2002/10/22 M7VIT Project: Date: 2002/8/15 Owner: Biostar Group Contact: TEL: 886-2-2218-0150 FAX: 886-2-2218-1552 Home Page: http://www.biostar.com.tw...

  • Page 2: Table Of Contents

    CONTENTS PRODUCT INFORMATION ..............4 Motherboard General Information ..............4 Chipset Details ......................4 BIOS Details ......................4 CPU Supports ......................4 Memory Supports ....................4 On-board Features and Devices ................4 Mechanical ....................... 5 DESIGN REVIEW Ver3.0 ................7 Mainboard Voltage Measurement ..............
  • Page 3 Camera Device ...................... 39 DVD-ROM ......................39 Display Card ......................40 ......................... 40 ........................41 Joystick ........................42 Keyboard ........................ 42 LAN Card ....................... 43 LAN HUB ......................43 Memory ........................43 Modem Card ......................44 Mouse ........................44 Monitor ........................

  • Page 4: Product Information

    PRODUCT INFORMATION Motherboard General Information Vendor Biostar Model Number M7VIT Version Number V0.90/V0.91/V3.0 Platform Micro ATX Flex ATX Chipset Details System Chipset Vendor North Bridge Revision KT400 South Bridge Revision VT8235 Super I/O Chip Vendor Winbond Super I/O Revision Number...

  • Page 5: Mechanical

    Number of Shared Slots None 66/100/133 MHz Front Side Bus Supports PC 133 Support DDR 400 Support PCI v2.2 Compliance ATA-3 Compliance ATAPI Compliance Ultra DMA 33 Support Ultra DMA 66 Support ATA-133 Support USB 1.1 Connector Support USB 2.0 Connector Support AGP (4X/8X) Slot Support Support AGP SideBand Addressing Mode Power on by Keyboard Support...
  • Page 6 Printer Port Connectors Line Up in Case None Excellent Fair Poor VGA Port Connectors Line Up in Case None Excellent Fair Poor Audio Port Connectors Line Up in Case None Excellent Fair Poor Game Port Connectors Line Up in Case None Excellent Fair...

  • Page 7: Design Review Ver3.0

    DESIGN REVIEW Ver3.0 Mainboard Voltage Measurement Voltage List Voltage SPEC Voltage Measured Result Battery Voltage 3.0V 2.93V Pass Battery Current 1.82uA Pass 5.0V+-5% 4.98V Pass +12V 12.0V+-5% 12.35V Pass -5.0V+-5% -5.13V Pass -12V -12.0V+-10% -11.91V Pass +3.3V +3.3V+-5% 3.27V Pass Bus Clock Clock Frequency Spec Value...
  • Page 8 PCI Clock High Time Min.11ns 14.4 Pass PCI Clock Low Time Min.11ns Pass PCI Clock Rising Time ~4ns Pass PCI Clock Falling Time ~4ns Pass...

  • Page 9: Required Bios Default Settings

    REQUIRED BIOS DEFAULT SETTINGS Lists Specification Result BIOS FEATURES SETUP Boot Seq/Floppy Setup Press Enter Pass First Boot Device Floppy Pass Second Boot Device HDD-0 Pass Third Boot Device LS120 Pass Boot Other Device Enable Pass Swap Floppy Drive Disable Pass Boot Up Floppy Seek Enabled...

  • Page 10: Power Management Setup

    Write Recovery Time Pass tWTR for DDR400 ONLY Pass AGP & P2P Bridge Control Press Enter Pass AGP Aperture Size 128M Pass AGP Mode Pass AGP Driving Control Auto Pass X AGP Driving Value Pass AGP Fast Write Disabled Pass AGP Master 1 WS Write Disabled Pass...

  • Page 11: Pnp / Pci Configuration

    Primery INTR Pass IRQ 3 (COM 2) Enabled Pass IRQ 4 (COM1 ) Enabled Pass IRQ5 (LPT 2 ) Enabled Pass IRQ6 (Floppy Disk) Enabled Pass IRQ7 (LPT1) Enabled Pass IRQ8 (RTC Alarm) Disabled Pass IRQ9 (IRQ2 Redir) Disabled Pass IRQ10 (Reserved) Disabled Pass...

  • Page 12: Pc Health Statues

    UART Mode Select Normal Pass RxD , TxD Active Hi,Lo Pass IR Transmission Delay Enable Pass UR2 Duplex Mode Half Pass Use IR Pins IR-RX2TX2 Pass Onboard Parallel Port 378/IRQ7 Pass Parallel Port Mode Pass EPP Mode Select EPP1.7 Pass ECP Mode Use DAM Pass Game Port Address...

  • Page 13: Functionality

    FUNCTIONALITY Setup Installation Test Of Operating System Pass/Fail Windows ME Pass Windows 2000 Professional Pass Windows XP Home Edition Pass Windows XP Professional Pass Linux (Red Hat 7.3) Pass Basic On-board Function Test Test Platform MS-DOS Operating Comment Athlon(tm) 2000 GHz Memory KINGMAX 256M * 2 QUANTUM EX3200AT 3.2G...
  • Page 14 Time Out Function Test Pass Power LED Flash Check Pass Power On Control Power On By RTC Test Pass Power On By LAN Test Pass Power On By Modem Test Pass Boot Management Boot Form CD-ROM Pass Boot From SCSI HDD Pass Boot From ATAPI ZIP/LS120 Drive Pass...
  • Page 15 Pattern Test Pass Extended Pattern Test Pass Walking 1’s Test Pass Walking 0’s Test Pass Random Memory Test Pass Address Test Pass Refresh Test Pass Data Bus Test Pass Cache Memory Test Pass Quick Memory Test Pass IDE HDD Test Pass IDE CD Test Pass...

  • Page 16: Windows Me Operating

    ACPI Test Pass I82557 Ethernet chip Pass Comments: Test Platform Windows ME Operating Comment Athlon 2600 Memory Samsung 128M X3 IBM DTLA-307030 CDROM LITEON 52X Sound Card On board Video Card ASUS V7700 LAN Card INTEL 82558 RAID On board Test Item Pass/Fail System Comparability Test...
  • Page 17 Print Port Test Add Printer PnP Test Pass FDD Connector Test Create Windows ME Startup Disk Pass Format 1.44 Floppy Driver Pass IDE Connectors Test CD-ROM Data Read Test Pass DVD-ROM Data Read Test Pass Ultra DMA 100/133 Hard Disk Test Pass USB Ports Test Add Keyboard PnP Test...
  • Page 18 √ √ √ √ 800x600 32 bit Pass √ √ √ √ 1024x768 16 bit Pass √ √ √ √ 1024x768 32 bit Pass √ √ √ 1152x864 16 bit None Pass √ √ √ 1152x864 32 bit None Pass Check Screen Have No Any Shadow Or Garbage Pass Audio Function Test...

  • Page 19: Windows2000 Operating

    Winbench 99 V1.2 Business Disk WinMark 99 Pass Business Graphics WinMark 99 Pass DirectDraw Tests Pass Disk Inspection Tests Pass Disk WinMark Pass GDI/USER Inspection Tests Pass High-End Disk WinMark 99 Pass High-End Graphics WinMark 99 Pass Video Tests Pass 3D Mark 2001 SE 3D Marks Pass...
  • Page 20 Restart Test Pass Scandisk Test Pass Setup installation Microsoft Office 2000 Test Pass Hibernate(S4) Test Standby Button for S4 (Enter) Pass Power Button for S4 (Enter and Wake up) Pass Windows Set RTC Time out for S4 (Enter and Wake up) Pass Enter S4 mode For 1/5/10/30/60/120 Minutes Then To Do Wake Up Test.
  • Page 21 Add Modem Card Test Pass Wake On Modem Test (Standby Mode) Pass VGA Function Test VGA Drivers Setup Installation Test Pass Display Properties Information Review Pass VGA Resolution All Test Pass Screen Saver Test Pass Check Screen Have No Any Shadow Or Garbage Pass Playing MPEG Files Test Pass...
  • Page 22 Stress Test –Loop 100 Pass MS Mouse Pass MS Joystick Pass MS ScanDisk Pass BurnIn Test CPU-Maths Pass CPU-MMX/SSE Pass Memory (RAM) Pass 2D Graphics Pass 3D Graphics Pass Hard Disk Test Pass Floppy Disk Pass Network Test Pass CD-ROM Pass Winbench 99 (1.2) Business Disk WinMark 99...

  • Page 23: Windows Xp (Home Edition ) Operating

    Comments: Test Platform Windows XP (Home Edition ) Operating Comment AMD AthlonXP 2000 GHz Memory KINGMAX 256M * 2 MAXTOR 4W100H6 100G CDROM PIONEER DVD-117 Sound Card Onboard Video Card ELSA / GLADIAC 525 / GerForce4 Ti4200 LAN Card INTEL 82559 RAID Onboard Test Item...
  • Page 24 Onboard Audio For S3 Function Supports Test (Play CD/VCD/DVD/AVI) Pass Hibernate(S4) Test Standby Button for S4 (Enter) Pass Power Button for S4 (Enter and Wake up) Pass Windows Set RTC Time out for S4 (Enter and Wake up) Pass Wake Up By LAN Test Pass Wake Up By Ring Test Pass...
  • Page 25 Boot ROM Function Test Login Server Test Peer to Peer 10Mbps or 100Mbps Data Transfer Test Setup Installation Winstone By The LAN Setup Installation 3D Mark2001 SE By The LAN ADSL Link Test PCI Slots Test Add LAN Cards Test Boot ROM Function Test Pass Login Server Test...
  • Page 26 Run 3D Mark2001 Pass Run XL-R8R Pass Check Screen Have No Any Shadow Or Garbage Pass Playing MPEG Files Test Pass Playing VCD Test Pass Playing DVD Test Pass 3D Winbench 2000 3D Performance Pass 3D Processing Pass 3D Quality Pass 3D WinMark Pass...
  • Page 27 Voice 32 DirectSound CPU Util , 22 kHz , 8 bits Static Hardware Voice Voice 8 0.573 Voice 16 0.85 Voice 32 1.19 DirectSound CPU Util , 22 kHz , 8 bits Steaming Hardware Voice Voice 8 0.574 Voice 16 0.845 Voice 32 1.38...

  • Page 28: Windows Xp (Professional ) Operating

    Stress Test –Loop 100 Pass MS Mouse Pass MS Joystick Pass MS ScanDisk Pass BurnIn Test CPU-Maths Pass CPU-MMX/SSE Pass Memory (RAM) Pass 2D Graphics Pass 3D Graphics Pass Hard Disk Test Pass Floppy Disk Pass Network Test Pass CD-ROM Pass Winstone 2001 Business Winstone 2001...
  • Page 29 CDROM YAMAHA KHS 5238E 52X Sound Card Onboard Video Card MSI G4TI4600 LAN Card Intel SB82558B RAID Onboard Test Item Pass/Fail System Comparability Test Windows XP Setup Installation Test Pass Supports Driver Installation Test Pass Standby Mode Test Pass Shut Down Test Pass Restart Test Pass...

  • Page 30: Linux (Red Hat 7.3) Operating

    Content Creation Winstone 2002 Pass PC Mark 2002 CPU Score Pass Memory Score Pass HDD Score Pass 3D Mark 2001 SE BenchMark Pass Demo Mode Pass Comments: Test Platform Linux (Red Hat 7.3) Operating Comment AMD ATHLON XP 1.9G HZ Memory TWINMOS / HYNIX 256M * 2 –DDR266 IBM 123.50G / IC35L120AVVA07-0...
  • Page 31 Add LAN Card Test Pass Add Sound Card Test Pass Comments:...

  • Page 32: Over Clock Test

    OVER CLOCK TEST Test Platform Windows XP Professtional (FSB:133 MHz) Athlon 2600 (133MHZ) Memory Samsung 256M X3 (DDR333) Seagate 40G ATA-100 CD-ROM SONY-DVD DDU-1621 Sound Card Onboard Video Card ELSA Geforce2 GTS CPU Front Side Bus Clock (WarpSpeeder Overclock) PC Mark 2002 CPU Score 6117 6210...

  • Page 33: Windows Xp Professtional (Fsb:166 Mhz)

    Test Platform Windows XP Professtional (FSB:166 MHz) Athlon 2700 (166MHZ) Memory Samsung 256M X3 (DDR333) Seagate 40G ATA-100 CD-ROM SONY-DVD DDU-1621 Sound Card Onboard Video Card ELSA Geforce 2 GTS CPU Front Side Bus Clock (WarpSpeeder Overclock) PC Mark 2002 CPU Score 6306 6534...

  • Page 34: Windows Me

    PERFORMANCE TEST Test Platform Windows ME Memory SAMSUNG 128M X3 (DDR-266) MAXTOR 80G ATA-133 CD-ROM LITEON 52X Sound Card On board Video Card ELSA GEFORCE 2 GTX DURON ATHLON ATHLON 1300 2600 2700 (100MHZ) (133MHZ) (166MHZ) PC Mark 2002 CPU Score 3586 5945 6199...

  • Page 35: Windows 2000 Professional

    Test Platform Windows 2000 Professional Memory WINBOND 512M X2 (DDR-400) MAXTOR 80G ATA-133 CD-ROM LITEON 52X Sound Card On board Video Card ELSA GEFORCE 2 GTX DURON ATHLON ATHLON 1300 2600 2700 (100MHZ) (133MHZ) (166MHZ) PC Mark 2002 CPU Score 3611 5986 6314...

  • Page 36: Windows Xp Professional

    Test Platform Windows XP Professional Memory HYNIX 256M X3 (DDR-333) MAXTOR 80G ATA-133 CD-ROM LITEON 52X Sound Card On board Video Card ELSA GEFORCE 2 GTX DURON ATHLON ATHLON 1300 2600 2700 (100MHZ) (133MHZ) (166MHZ) PC Mark 2002 CPU Score 3679 6132 5631...

  • Page 37: Display Card Performance

    Display Card Display Card Performance Vendor Model Chips Result ASUS AGP-V 3800M RIVA TNT2 M64 1747 ASUS AGP-V6800 DDR Geforce 256 3547 ALL-IN-WONDER 128 3655 1025-G4424 RADEON DDR 32M 2504 RADEON 8500 ATI RADEON 8500 8818 RADEON 9000 ATI RADEON 9000 7689 TRANSCEND RADEON 7500...

  • Page 38: Hardware Compatibility List

    HARDWARE COMPATIBILITY LIST Vendor Model Frequency Type Result Athlon 700 MHz Socket A Pass Athlon 750 MHz Socket A Pass Athlon 800 MHz Socket A Pass Athlon 850 MHz Socket A Pass Athlon 900 MHz Socket A Pass Athlon 950 MHz Socket A Pass Athlon...

  • Page 39: Cd-Rom

    Comments: CD-ROM Vendor Model Transfer Rate Type Result AFREEY CD-2052E ATA-33 Pass BCD F562 ATA-33 Pass TEAC CD-540E ATA-33 Pass TEAC CD-532E ATA-33 Pass YAMAHA BCD F563E ATA-33 Pass YAMAHA KHS 5238E ATA-33 Pass BEN –Q 652A674 ATA-33 Pass A-OPEN CD-952E ATA-33 Pass...

  • Page 40: Display Card

    Comments: Display Card Vendor Model Chips Drivers Result ASUS AGP-V 3800M RIVA TNT2 M64 28.32 Pass ASUS AGP-V6800 DDR Geforce 256 30.82 Pass ALL-IN-WONDER 128 6.13.10.6166 Pass 1025-G4424 RADEON DDR 32M 6.13.10.6166 Pass RADEON 8500 ATI RADEON 8500 6.13.10.6166 Pass RADEON 9000 ATI RADEON 9000 6.13.10.6166...

  • Page 41: Hdd

    MITSUMI D359T5 1.44 Pass MITSUMI D359T6 1.44 Pass MITSUMI D353T6 1.44 Pass MITSUMI D359M3 1.44 Pass MITSUMI D353M3 1.44 Pass FD1231H 1.44 Pass TEAC FD-235HF 1.44 Pass SONY MPF920-E 1.44 Pass Panasonic JU257A606P 1.44 Pass SUMSUNG SFD-321B 1.44 Pass Comments: Vendor Model Size...

  • Page 42: Joystick

    QUANTUM AT Fireball Plus AS 40 G ATA-100 Pass QUANTUM BIGFOOT 4.0G PIO-4 Pass QUANTUM EX3200AT 3.2G ATA-33 Pass QUANTUM E5100AT 5.1G ATA-33 Pass QUANTUM CR6400AT 6.4G ATA-33 Pass QUANTUM CX6400AT 6.4G ATA-33 Pass QUANTUM 6.4G SCSI 6.4G 6.4G Pass QUANTUM KA9100AT 9.1G...

  • Page 43: Lan Card

    SAMPO F-21YQ (SPK-2000) Pass 5126 Pass BUS LOGIC BA81C15 Pass K.A.CHEN KB-7000 PS/2 Pass SAMPO F-21BQ PS/2 Pass Logitech Y-SA2 PS/2 Pass ACER 6511-TA PS/2 Pass Logitech (IR) Y-RA1 Pass WIRELESS 5110 Pass Comments: LAN Card Vendor Model Drivers Type Result 3COM 3C905-TX...

  • Page 44: Modem Card

    HYNIX HY5DU28822BT-H 256M PC-266 Pass KINGMAX KDL684T4AA-60 256M PC-333 Pass KINGMAX KDL684T4AA-50 256M PC-400 Pass NANYA NT5DS16M8AT-7K 128M PC-266 Pass NANYA NT5DS16M8AT-7K 256M PC-266 Pass NANYA NT5DS32M8AT-7K 512M PC-266 Pass 46V16M8-75A 128M PC-266 Pass 46V32M8-75B 512M PC-266 Pass MOSEL V58C2128804SAT75 256M PC-266 Pass...

  • Page 45: Monitor

    Logitech M-BA47 Pass Logitech M-S34 PS/2 Pass Logitech M-M30 PS/2 Pass Logitech M-S43 PS/2 Pass Logitech M-CAA43 PS/2 Pass Logitech M-CAB48A PS/2 Pass Logitech M-MM35 Serial Pass Logitech M-MM43 Serial Pass Logitech M-RG45 Pass Microsoft IntelliMouse X04-91790 USB/PS2 Pass Microsoft IntelliMouse B75-00006 USB/PS2 Pass...

  • Page 46: Power Supply

    Power Supply Model Type Result ATX Power 250W Pass ATX Power 300W Pass ATX Power 350W Pass ATX Power 400W Pass Comments: Printer Vendor Model Drivers Type Result CANON BJ-80K Pass EPSON STYLUS PHOTO 750 USB /LPT Pass DeskJet 970Cxi Pass Deskjet 990 cxi IrDA/LPT/USB...

  • Page 47: Sound Card

    Comments: Sound Card Vendor Model Drivers Type Result AVORTEX AU8820B2 4.05.0110 Pass CREATIVE Sound Blaster CT4670 Ver 2.0 Pass CREATIVE Sound Blaster SB0060 Ver 2.4 Pass CREATIVE CT4750 Ver 2.4 Pass CREATIVE ES1371 4.05.1119 Pass CREATIVE CT4750 5.12.01.2041 Pass Ensoniq ES1370 4.02.1033 Pass...

  • Page 48: Software Compatibility List

    SOFTWARE COMPATIBILITY LIST Version Result MS-DOS 6.22 Pass Windows Windows ME 4.90.3000 Pass Windows 2000 Profession Release Pass Windows XP Home Edition 2002 Pass Windows XP Professional 2002 Pass Linux Red hat Pass Comments:...

  • Page 49: Vcore Waveform Measurement-Ver3.0

    VCORE WAVEFORM MEASUREMENT-Ver3.0 Vcore Ripple Test(Dos Mode) Athlon_xp_2700+ VIT3.0 STP CLK Vcore Condition Just booting on DOS mode, not running any Program Vcore ripple waveform RESULT PASS...

  • Page 50: Vcore Transient Test(Dos Mode)

    Vcore Transient Test(Dos Mode) Athlon_xp_2700+ VIT3.0 CH 1 STPCLK pin waveform CH 2 Vcore waveform Condition 1.Boot the system to the Win98SE environment(Command Prompt Only) Dos mode and run the stpclk.bat 2.At the main menu ,type “U” to go to the “Utilities Submenu” 3.At the next menu , type “B”...

  • Page 51: Vcore Ripple Test(Open Up The Dos Editor)

    Vcore Ripple Test(Open up the DOS Editor) Athlon_xp_2700+ VIT3.0 CH 1 STPCLK pin waveform CH 2 Vcore waveform Condition 1.Boot the system to the Win98SE environment(Command Prompt Only) Dos mode and run the stpclk.bat 2.At the main menu ,type “U” to go to the “Utilities Submenu” 3.At the next menu , type “B”...

  • Page 52: Vcore Ripple Test(Standby/Resume Mode)

    Vcore Ripple Test(Standby/Resume Mode) Athlon_xp_2700+ VIT3.0 STP CLK Vcore Condition Riplle after Standby/Resume(into standby) Vcore ripple waveform RESULT PASS...

  • Page 53: Vcore Ripple Test(Standby/Resume Mode)

    Vcore Ripple Test(Standby/Resume Mode) Athlon_xp_2700+ VIT3.0 STP CLK Vcore Condition Riplle after Standby/Resume(resume) Vcore ripple waveform RESULT PASS...

  • Page 54: Four Corner Test-Ver 3.0

    FOUR CORNER TEST-Ver 3.0 Test Equipment & Environment M/B TYPE M7 VIT/3.0 CPU Level Althon_XP 2200+ RAM TYPE SYNNEX 256MB PC266 x3 VGA TYPE ASUS V8170DDR/64M Power Supply FSP-350-60BN Floppy PANASONIC JU-257 IDE1 Primary Maxtor 80G dma-133 IDE1 Secondary Maxtor 80G DMA-133 IDE2 Primary PIONEER DVD ROM IDE2 Secondary...

  • Page 55: Vcore Static Load Test3.0

    STATIC LOAD TEST3.0 CORE Test Environment VIK/1.0 Power Supply FSP350-60BN VID Setting 1.75V Engineer Signature Yi-hung Electronic Loading Chroma 63030 RT9241 O.C.P test Over 53A Pass/Fail pass O.V.P test 2.2V Pass/Fail Pass AGP Slot PCI Slot Temperature Vcore Vcore Momey 5V ATX Loading Voltage...

  • Page 56: Thermal Image Test

    THERMAL IMAGE TEST Motherboard General Information Vendor Biostar Model Number M7VIT Revision V3.0 Temperature ( ¢ J ) 35 ¢ J Humidity rate ( % ) 0 ~ 60 % Thermo Tracer NEC TH5104 Test Program 3Dmark2001 Comments: The component temperature measured value was based on 35¢ J check in the chamber...
