Making a SATA RAID/AHCI Driver Diskette
Before installing Windows XP, connect a USB floppy disk drive to your computer first because you need to
install the SATA RAID/AHCI driver from a floppy disk that contains the driver during the OS installation. To copy
the RAID/AHCI driver for Windows XP, copy all files in the \BootDrv\SBxxx folder in the motherboard driver
disk to your floppy disk.
Installing the SATA RAID/AHCI Driver and Operating System
A. Installing Windows XP
Restart your system to boot from the Windows XP setup disk and press <F6> as soon as you see the message
"Press F6 if you need to install a 3rd party SCSI or RAID driver." Insert the floppy disk containing the SATA
RAID/AHCI driver. Follow the on-screen instructions to install the driver that suits your operating system. When
completed, proceed with the Windows XP installation.
B. Installing Windows 7/Vista
(The following instructions use Windows 7 as the example operating system.)
Restart your system to boot from the Windows 7/Vista setup disk and perform standard OS installation steps.
Select Load Driver. Insert the motherboard driver disk and then browse to the location of the driver. Then follow
the on-screen instructions to load the driver.
RAID driver for Windows 32-bit: \BootDrv\SBxxxW7\RAID\W7
RAID driver for Windows 64-bit: \BootDrv\SBxxxW7\RAID\W764A
AHCI driver for Windows 32-bit: \BootDrv\SBxxxW7\AHCI\Win7x86
AHCI driver for Windows 64-bit: \BootDrv\SBxxxW7\AHCI\Win7x64
After loading the driver, continue the OS installation.
