Internal Connectors - Gigabyte GA-78LMT-S2 User Manual

1-7

Internal Connectors

1
10
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN
5) SATA2 0/1/2/3/4/5
6) F_PANEL
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
3
7 4 8 9 6
7) F_AUDIO
8) F_USB1/F_USB2
9) CLR_CMOS
10) BAT
- 13 -
2
5
5
5
