Audio configurations

The Realtek
audio CODEC provides 8-channel audio capability to deliver the ultimate audio
®
experience on your computer. The software provides Jack-Sensing function, S/PDIF Out
support, and interrupt capability. The CODEC also includes the Realtek
(Universal Audio Jack) technology for all audio ports, eliminating cable connection errors and
giving users plug and play convenience.
Follow the installation wizard to install the Realtek
that came with the motherboard package.
If the Realtek audio software is correctly installed, you will find
the Realtek HD Audio Manager icon on the taskbar. Double-
click on the icon to display the Realtek HD Audio Manager.
A.
Realtek HD Audio Manager for Windows
Configuration
option tabs
Control
settings
window
Information
Click the Information button (
information about the audio driver version,
DirectX version, audio controller, audio
codec, and language setting.
Audio Driver from the support CD/DVD
®
Set default device
button
Device advanced settings
) to display
Click Device advanced settings to show
further settings for the playback and
recording device.
proprietary UAJ
®
Realtek HD Audio Manager
Vista™
®
Minimize
Exit button
button
®
Device
advanced
settings
Connector
settings
Analog
and digital
connector
status
Information
button
