PCI Clock Synchronization Mode [To PCI Express]
Sets the PCI Express clock synchronization mode.
Configuration options: [To PCI Express] [33.33MHz] [37.5MHz] [40.0MHz]
DDR Reference Voltage [Auto]
Allows you to automatically detect or select from a list the DDR operating voltage.
Configuration options: [2.6V] [2.7V] [2.8V] [2.9V] [Auto]
FID/VID Change [Auto]
Sets the frequency ID and voltage ID.
Configuration options: [Auto] [Manual]
Processor Frequency Multiplier [x8 1600 MHz]
Sets the processor frequency multiplier. The default value varies depending on the
processor installed. This item appears only when the FID/VID Change item is set
to Manual. Configuration options: [x8 1600 MHz] [x9 1800 MHz] [x10 2000 MHz]
[x11 2200 MHz]
Processor Voltage [1.350 V]
Sets the processor voltage. The configuration options vary depending on the
processor installed. This item appears only when the FID/VID Change item is set
to Manual.
2.4.2 USB Configuration
The items in this menu allows you to change the USB-related features. Select an
item then press <Enter> to display the configuration options.
OnBoard SiS USB1.1 DEVICE
OnBoard SiS USB2.0 DEVICE
USB Configuration
Module Version - 2.23.2-9.4
USB Devices Enabled: None
Legacy USB Support
USB 2.0 Controller Mode
Stop EHCI Hand-Off
OnBoard SiS USB1.1 DEVICE [Enabled]
Allows you to enable or disable the onboard SiS USB 1.1 port.
Configuration options: [Disabled] [Enabled]
OnBoard SiS USB2.0 DEVICE [Enabled]
Allows you to enable or disable the onboard SiS USB 2.0 port.
Configuration options: [Disabled] [Enabled]
ASUS A8S-X
[Enabled]
[Enabled]
[Auto]
[HiSpeed]
[Enabled]
2-15
