Summary of Contents for Dual NavAtlas XNAV9525
-
Page 1: Installation Manual
XNAV9525 INSTALLATION MANUAL & QUICK START GUIDE Vehicle GPS Navigation System with MP3 Player... - Page 2 Except as permitted by such license, the contents of this document may not be disclosed to third parties, copied, or duplicated in any form, in whole or in part, without the prior written permission of Dual Electronics Corporation.
-
Page 3: Safety Information And Precautions
XNAV9525 GPS NAVIGATION SYSTEM Safety Information and Precautions WARNING! PLEASE READ AND FOLLOW THE SAFETY PRECAUTIONS BELOW. FAILURE TO FOLLOW THE INSTRUCTIONS BELOW MAY INCREASE YOUR RISK OF COLLISION AND PERSONAL INJURY. The Please Drive Safely screen is displayed each time the navigation system is turned on as a reminder to make use of the system’s navigational aids in a safe manner. -
Page 4: Introduction To Your Navigation System
XNAV9525 GPS NAVIGATION SYSTEM Introduction to Your Navigation System As you travel, your navigation system functions as your copilot, providing turn-by-turn visual and voice guidance to direct you to your selected destination. Because the system knows where you are and where you want to go, it can quickly calculate step-by-step directions that provide a route to any destination available on the included navigation map. - Page 5 • If the unit malfunctions, press the power button on the remote control to reset the unit first. Refer to page 11 for details. If the problem still persists, consult your nearest Dual dealer or call Dual tech assistance @ 1-866-429-1628.
- Page 6 XNAV9525 Installation - Main Unit Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the main unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
-
Page 7: Installation - Antenna
• Once the antenna is mounted, carefully plan the cable route to the XNAV9525. Be careful not to pinch or twist the antenna cable. Use a grommet when running wires through any metal openings. - Page 8 Wiring Diagram - Stand Alone Operation Wiring Notes When using the XNAV9525 in stand alone mode, the 13 pin Interface Cable is NOT used. The following connections are required: • 4 pin power/speaker connector - *confirmation speaker not required when using the audio outputs (RCA connections).
- Page 9 Wiring Diagram - Using with Dual XDV8125 XDV8125 Wiring Notes When using the XNAV9525 with the Dual XDV8125, please note the only connection required between the XDV8125 and the XNAV9525 is the 13 pin Interface Cable. The following connections are not required: •...
-
Page 10: Main Unit Connections
XNAV9525 Main Unit Connections USB 1.1 Host Interface 10/100Mb LAN Connection GPS Antenna Input Stereo Audio Outputs GPS NAVIGATION SYSTEM Composite Video Output Remote Sensor Input Power/Speaker Connections Head Unit Interface... -
Page 11: Control Locations - Remote
XNAV9525 GPS NAVIGATION SYSTEM Control Locations - Remote F6 Function Key Volume Up Volume Down F5 Function Key F4 Function Key F1 Function Key Escape/Previous Screen 4-Way - Left Navigation Menu... - Page 12 XDV8125 owner’s manual included with the XDV8125. The voice guidance and MP3 audio is routed to the left front channel of the XDV8125 by default. When an XNAV9525 voice command is executed, the XDV8125 audio is muted to allow the voice command to be heard by the driver.
- Page 13 XNAV9525 GPS NAVIGATION SYSTEM Start Up Power On/Off Press PWR on the XNAV9525 remote control to power up the XNAV9525 and display the loading screen. Loading Screen After the system boots, the following warning is displayed. Warning Screen Press ENTER to accept the warning and to display the map.
-
Page 14: Entering A Destination
XNAV9525 Entering a Destination Address/Intersection Step 1 Step 2 Step 3 GPS NAVIGATION SYSTEM From the map screen, you can select a destination by several ways. For this example, let’s select a street address. Access the navigation menu by pressing the F3 button or MENU from the remote control. - Page 15 XNAV9525 Address/Intersection In the example below, California has been selected. (continued) Step 4 After the State/Province has been selected, the destination can be input by City Name or Street Name. Let’s use City Name for this example. Highlight City Name and press ENTER. Use the ▲▼ buttons to choose the desired city and press ENTER.
- Page 16 XNAV9525 Entering a Destination Step 6 Step 7 Step 8 GPS NAVIGATION SYSTEM After the street selected, the final destination can be input by street address or nearby intersection. Let’s use address for this example. Highlight Address and press ENTER.
-
Page 17: Gps Navigation System
Next Turn Symbol GPS Signal Status Compass Heading Map Scale Destination XNAV9525 GPS NAVIGATION SYSTEM When route calculations are complete, the navigation system will tell you to “Please proceed to the highlighted route” unless you are already on the route. The highlighted route is indicated in magenta (purple). - Page 18 XNAV9525 Arriving at the Destination Step 10 Off-Route and Route Interruptions Using Your System GPS NAVIGATION SYSTEM When you are approaching your destination, the destination is shown on the map screen with a yellow circle outlined in magenta (purple). A voice message announces that you are approaching your destination.
- Page 19 (shown when a route is not active) GPS Signal Status Green Yellow Current Location Screen XNAV9525 GPS NAVIGATION SYSTEM Map Display - Overview The Map Display shows roads, road names, and cartographic features like lakes and rivers. You can adjust...
- Page 20 XNAV9525 Navigation Menus - Overview Enter Destination Edit Address Book Setup List Mode Spell Mode Most Recently Used GPS NAVIGATION SYSTEM All navigation operations begin with the navigation system’s navigation menu screen. From this menu, you have three different options.
-
Page 21: Remote Control Functions - Overview
MP3 Player Display Setup Data Manager The XNAV9525 includes advanced MP3 playback software to enable you to play MP3 files stored on the hard drive or from most standard USB storage devices. See page 23 for more information on playing MP3 files. - Page 22 XNAV9525 Remote Control Functions - Overview Function Buttons Navigation - Remote Control Operation Cancel current action Zoom in the map to show a smaller area Zoom out the map to show a larger area Center map on current vehicle location...
-
Page 23: Mp3 Player
Playback Position XNAV9525 GPS NAVIGATION SYSTEM The XNAV9525 includes advanced MP3 playback software to enable you to play MP3 files stored on the hard drive or from most standard USB storage devices. Press SYSTEM on the remote control to access the System Menu. - Page 24 XNAV9525 MP3 Player Remote Control Functions MP3 Player - Remote Control Operation Selection moves to the previous file and begins playback. ◀ Selection moves to the next file and begins playback. ▶ Starts MP3 playback of currently selected file. Stops MP3 playback.
-
Page 25: Display Setup
Display Setup From the System Menu, select “Display Setup” to adjust the display screen position. If the XNAV9525 is used in combination with external monitor, the display screen may not be centered. This symptom is not abnormal and it varies with individual monitor characteristics. - Page 26 XNAV9525 Data Manager - Overview System Menu Data Manager Data Manager Menu Windows Notes GPS NAVIGATION SYSTEM The default Data Manager allows you to transfer MP3 files to your system without the possibility of deleting any system files. In the default Data Manager mode, Hard Disk and Hard Disk2 partitions are protected - preventing files from being...
- Page 27 Data Manager Multiple File Select Data Manager Folder/File Copy Progress XNAV9525 GPS NAVIGATION SYSTEM Browse folders/files by moving the yellow cursor using the ▲▼◀▶buttons. Highlight desired folder or file and press ENTER to select. Folders with sub folders are displayed in the same window.
- Page 28 XNAV9525 Data Manager - Delete Folders/Files Delete Folder/Files Notes Data Manager Multiple Files Selected for Deletion Data Manager Deletion Confirmation Box Note GPS NAVIGATION SYSTEM The Delete function allows any folders/files on the Hard Disk3 partition to be deleted. Folders/files located on the Hard Disk or Hard Disk2 partitions can not be deleted using the default Data Manager.
- Page 29 XNAV9525 Data Manager - Create Folders Create New Folders New folders can be created to manage and organize MP3 files. For optimum performance, it is only recommended to add new folders to the Hard Disk3 partition of the hard drive.
-
Page 30: System Setup Menu
XNAV9525 System Setup Menu Setup Menu Navigation Preferences Menu GPS NAVIGATION SYSTEM You can customize the navigation system appearance and functions to your own preferences. From the map screen press MENU, then select Setup to adjust navigation preferences, display options, and units (km or mi) settings. - Page 31 XNAV9525 GPS NAVIGATION SYSTEM System Setup - Preferences Menu Simulation On/Off When selected, the GPS icon will be replaced with a DEMO icon and allow the system to “drive” the selected route even though the vehicle is not moving. This can be used to preview a route without leaving your driveway.
- Page 32 XNAV9525 System Setup - Display Options Display Options Menu North Up/Heading Up Note GPS Icon Display On/Off GPS NAVIGATION SYSTEM Display options allow you to set the map orientation and the information displayed on the map. Determines if the map is always displayed with North direction at the top of the screen or if map is always adjusted so that vehicle symbol points toward the top of the screen.
- Page 33 (plus decimal miles, e.g. zero point three miles), kilometers/meters, or miles/yards based on personal preferences. The XNAV9525 includes other system preferences not covered in this Quick Start Guide. Refer to the owner’s manual included on the DVD for more information.
-
Page 34: Limited One Year Warranty
Dual Electronics Corp. agrees, at our option, during the warranty period, to repair any defect in material or workmanship or to furnish an equal... -
Page 35: Troubleshooting
If the problem still appears after resetting the unit, please contact technical support for further assistance. USB Storage Device Compatibility Due to ongoing technological advancement of USB storage devices, some USB storage devices may not be compatible with the XNAV9525. XNAV9525 GPS NAVIGATION SYSTEM Cause... -
Page 36: Specifications
For best results, use the following settings: 128kbps or higher constant bit rate 44.1kHz or higher sampling frequency 13 Pin data cable (for use with select Dual head units) Stereo audio outputs (RCA) Composite video output (RCA) Voice guidance speaker output...
