Summary of Contents for TRENDnet TU3-H2PIE
- Page 1 Quick Installation Guide TU3-H2PIE 1.02...
-
Page 2: Table Of Contents
Table of Contents English 1. Before You Start 2. How to Install Technical Specifications Troubleshooting Version 01.01.2011... -
Page 3: English
1. Before You Start Package Contents Ÿ TU3-H2PIE Ÿ CD-ROM (Driver) Ÿ Multi-Language Quick Installation Guide System Requirements PCI Express slot Ÿ 1.0a/2.0 Ÿ USB 3.0 Cable Ÿ CD-ROM Drive Supported Operating Systems CPU Memory Windows 7 (32/64-bit) 1GHz or above... -
Page 4: How To Install
2. How to Install Important! Do not insert the TU3-H2PIE in the computer until instructed to do so. 1. Insert the Driver CD-ROM into your CD-ROM drive. 2. Click Run Autorun.exe (Windows 7/ Vista only). 3. Click Install Driver. 4. Click Next. Then follow the InstallShield Wizard instructions. - Page 5 6. Click Continue Anyway (Windows XP only). 7. Click Finish. Note: Please refer to your computer's user manual regarding hardware installation. 8. Shutdown your computer. 9. Open your computer case.
- Page 6 10. Insert the TU3-H2PIE card firmly into an available PCIe slot. 11. Connect an available 4-pin Molex power cable from the computer's power supply to the TU3-H2PIE card. 12. Turn ON the computer and wait until the Windows desktop appears.
- Page 7 15. Click Continue Anyway. 16. Click Finish. 17. Repeat steps 13-16. 18. Connect your USB device to one of the USB ports on the TU3-H2PIE. Your Installation is now complete...
-
Page 8: Technical Specifications
Technical Specifications Hardware Interface USB 3.0 Ÿ PCI Express Interface Revision 2.0 backwards Ÿ Electromechanical Specification Revision 2.0 Ÿ Bus Power Management Interface Specification Revision 1.2 Ÿ Port 2 x USB 3.0 Port Ÿ 1 x 4-pin internal power port (cable not included) Ÿ... -
Page 9: Troubleshooting
4. Try connecting the external USB device to the other USB port on the TU3-H2PIE. 5. Try using a different USB cable. If you still encounter problems or have any questions regarding the TU3-H2PIE, please contact TRENDnet's Technical Support Department. - Page 10 RMA number is required in order to initiate warranty service support for all TRENDnet products. Products that are sent to TRENDnet for RMA service must have the RMA number marked on the outside of return packages and sent to TRENDnet prepaid, insured and packaged appropriately for safe shipment.
- Page 11 Download section and look for the desired TRENDnet product to access to the GPL Code or LGPL Code. These codes are distributed WITHOUT WARRANTY and are subject to the copyrights of the developers. TRENDnet does not provide technical support for these codes. Please go to http://www.gnu.org/licenses/gpl.txt...
- Page 14 Copyright ©2011. All Rights Reserved. TRENDnet.
