Installation Instructions
Part Number:
10. 1 99.022K
Description:
HD Polyurethane Front Mount, A3 Chassis
Notes:
Our A3 front engine mount bushing reduces engine 'rock' under accelera
tion, resulting in better power transfer.
Procedure:
1) Remove the original lower bushing from the car's front engine mount.
First, if your car has one, remove the lower bushing retaining cover as shown (below left)
by removing the three nuts with a 13mm wrench.
Next, using an 8mm hex (Allen®) wrench, remove the bottom center bolt as shown (above
right) and take out the lower bushing.
2) Install the Autotech HD bushing.
Now, put the HD bushing in place and retain with the original bolt.
(bolt oiled). If car is equipped with it, re-install the retaining cover
32240-E Paseo Adelanto, San Juan Capistrano, CA 92675
T
O
T
E
Phone 949.240.4000 Fax 949.240.0450
C
H
www.autotech.com
bolt: 41ftlb/55Nm
nuts: 15ftlb/20Nm
1/1
