Installing And Verifying Sql Xml 3.0 Sp3; Installing And Configuring Sql Server - VMware VCENTER CONFIGURATION MANAGER 5.3 - SOFTWARE REQUIEREMENTS GUIDE Configuration

"%windir%\Microsoft.NET\Framework\v3.0\Windows Communication
Foundation\ServiceModelReg.exe" /k:W3SVC /y
"%windir%\Microsoft.NET\Framework\v3.0\Windows Communication
Foundation\ServiceModelReg.exe" /k:W3SVC/1/root /y
"%windir%\Microsoft.NET\Framework\v2.0.50727\aspnet_regiis.exe" /i
"%windir%\Microsoft.NET\Framework\v3.0\Windows Communication
Foundation\ServiceModelReg.exe" /s:W3SVC /y
"%windir%\Microsoft.NET\Framework\v3.0\Windows Communication
Foundation\ServiceModelReg.exe" /s:W3SVC/1/root /y
IISRESET
3. Return to the previous procedure for instructions on how to verify that the *.svc extension now
appears.
For more information, refer to the following documents:
Troubleshooting Setup Issues:
n
Service Model Registration Tool (ServiceModelReg.exe):
n
us/library/ms732012.aspx
IIS stops handling *.svc requests after installing .NET 3.0 RC1:
n
http://blogs.msdn.com/martinv/archive/2006/09/11/749388.aspx

Installing and Verifying SQL XML 3.0 SP3

SQL Server 2005, which you are instructed to install in the next section, installs SQLXML4; however,
SQLXML 3.0 SP3 is also required.
1. Download and install SQLXML 3.0 Service Pack 3. The application is available as a download from
Microsoft.
2. To verify the version, select Start | Control Panel | Add or Remove Programs. The Add or Remove
Programs window appears.
3. In the Currently installed programs list, verify that SQLXML 3.0 SP3 is displayed.
4. To verify the exact version number, select the application name in the list, and then click Click here for
support information. In the Support Info dialog box, the version value should be at least 3.30.3457.0.
5. If the list displays only SQLXML 3.0, or the version number is not at least 3.30.3457.0, the correct
version is not installed. Download and install SQL XML 3.0 SP3.

Installing and Configuring SQL Server

Use the following procedures to install SQL Server 2005 (English (United States) version) and Service Pack
3 or later on your designated Collector, and to verify that the settings are configured correctly for a VCM
installation. VCM works with a Standard or Enterprise edition of SQL Server.
If you are planning to change the communication port used by SQL from the default port (1433) to a non-
standard port number, make the changes during the installation of SQL Server and the SQL Server
Reporting Services (SSRS). Changing the port after installing SSRS will disable SSRS communication with
SQL Server and you will encounter an SSRS validation error during the VCM installation process. If you
do change the port after installation, additional configuration changes will need to be made to SSRS to
repair the configuration. Contact VMware Customer Support if you need assistance.
SQL Server 2005 SP3 is the version documented in this guide.
VMware, Inc.
Software and Operating System Requirements -- Collector Machines
http://msdn2.microsoft.com/en-us/library/aa751852.aspx
http://msdn2.microscopy.com/en-
29
