CONCOURSE C4
ARCHITECTURAL SERIES
DIFFUSE (DUAL) TWO WAY ENCLOSURE
KEY FEATURES:
✓
Two way ported round ceiling loudspeaker with 4" LF, 1" soft dome
tweeter and passive crossover
✓
50watts program, 100watts peak
✓
Selectable 4ohm or 16ohm low impedance setting. Switch accessible
from below.
✓
Integral 30/15/7.5/3.75watt tap line transformer
✓
Integral three point mounts swivel out from the loudspeaker to allow
simple installation from below the ceiling.
✓
Back box, 'C' clamp included
✓
Optional mud ring and mounting plate with integral electrical back box
and conduit knockouts
APPLICATIONS:
✓
Corporate Meeting Rooms
✓
Classrooms
✓
Training Rooms
✓
Restaurants
✓
Retail Outlets
✓
Hotels
✓
Health Clubs
DESCRIPTION:
The QUAD Industrial CONCOURSE C4 is a two way round ceiling speaker with a
4" LF, 1" soft dome tweeter and passive crossover. The Concourse C4 is intended
for small room applications requiring high quality speech reinforcement and/or
background music.
The CONCOURSE C4 has switch settings for 4 and 16 ohm low impedance,
allowing efficient use of amplifier power and parallel looping connections with no
transformer losses or signal degradation.
For distributed applications, the CONCOURSE C4 has an integral transformer
rated at 30-15-7.5-3.75 watt taps @ 70volts and 30-15-7.5 watt taps @100volts.
The CONCOURSE C4 includes a back box and 'C' ring for weight distribution on
ceiling finishes. In addition, the C4 has an optional mud ring and ceiling tile
mounting (with integral terminal box containing conduit knockouts).
All components (including grill) are attached to a steel tether, which in
turn is attached to an external anchor point.
11:01 am Page 1
SPECIFICATIONS:
SYSTEM:
POWER HANDLING: 25 watts continuous, 50watts program,
100watts peak
Recommended amplifier: 5-50 watts
Impedance: Selectable 4 or 16 ohms nominal
Frequency response (-10dB): 55Hz-20kHz
Frequency response (+/-3dB): 70Hz-20kHz
Sensitivity: 84dB/1watt/1meter
Max SPL: 104dB
Coverage: 110*90
Directivity (Q): 5.34
Transformer: 30-15-7.5-3.75 watt taps @ 70volt and 30-15-
7.5watts @ 100volt.
TRANSDUCERS:
LF Driver: 4" Cone
HF Driver: 1" Dome tweeter
Crossover Frequency: 2.2kHz
PHYSICAL:
Type: Two way passive ported design
Material: ABS baffle, powder coated aluminium grill, steel
backcan
Connector: Terminal strip
Dimensions (WxD): 252mm (dia) x 219mm
Nett Weight: 2.75kg
