AllerAir 9150 W Specification Sheet

Model 9150 W
Welding and Soldering
Filter Airborne Chemicals, Vapors Gases, Ordors as well as Smoke
Harmful toxins in the industrial workplace are recognized as a major cause
of occupational asthma, chronic absenteeism, headaches and respiratory
irritation.
The resulting fumes from welding and soldering can contain complex
gaseous compounds and particles capable of
causing a variety of serious ailments.
The AllerAir Fume Extractor efficiently removes
these airborne toxins, particles and odors,
providing serious, cost-efficient protection
for employees.
Image for One hose
illustration standard,
purposes second hose
only is optional.
5 Optional arms
to chose from
at different costs
Arm A
(6' or 8' Long)
(4" or 6" Diam.)

Features

Air volume draw calculated to capture the
welding fumes without affecting the gas shield.
Robust, galvanized steel housing ensures
no release of harmful vapors.
110 lbs, 16"x20"x24", 18 gauge steel.
Heavy duty ball bearing wheels for easy
manoeuverability.
1 standard 6" x 8" hoses flex aluminum hose
to locate the unit close to the work area in the best
position to capture the welding fumes.
Powerful, low energy consumption motors.
Variable speed up to
560 CFM free flow, model 9150 W
735 CFM free flow, model 9175 W
Allerair_Mk : Documents_on_PDF : Sale Sheets : 9000 Series : Flyer9150welding - March/02/2006
fume extractors
Arm B
(10' Long)
(6" Diam.)
Arm E
Industries Inc Toll free: 1-888-852-8247 / Fax: 1-877-688-2193 www.allerair.com
.
Welding, Arc, MIG, TIG,
Brazing and Soldering
Four stages of air filtration
Spark arrestor
1" Spark arrestor (metal frame) to capture
welding sparks and protect the other filters.
HEPA filter
HEPA filter, 2" deep, 99.97 % effective, to
capture respirable size particles, as small as
0.5 µ from welding fumes and dust.
Arm C

Activated carbon filter

(5' Long)
(3" Diam.)
Large 40 lbs. main carbon cannister filter for
adsorbing odors and chemicals contained in
welding or soldering fumes which may be
detrimental to your health.
Pre-filter
2" Pre-filter to capture large particles
Recommended filter replacement schedule
Filters life cycle can widely vary with
the environment the air purifiers are used in.
Available with two 4" flex
Plasma Cutting,
Arm D
(5' Long)
(4" Diam.)
