ACTpro mifare®
Product Overview
Smart Cards are cards with memory on board that
can be read or written to. A contactless smart card
does not need to be in direct contact with a reader.
Instead, it communicates using wireless technology.
mifare is a 13.56MHz contactless technology that
allows one card to be used for many applications.
ACT has developed a range of mifare readers,
compatible with the ACTpro family of access
control units. The ACTpro mifare readers are
configurable to read either a mifare card serial
number or from a sector on the mifare card.
Main Features
Choice of mifare proximity only
●
or pin and mifare proximity
Reader configurable as a Serial
●
or Sector Reader
Compatible with ACTpro
●
mifare ISO cards and Fobs
Sector reader operation configurable for
●
non-ACT cards and Fobs via programming card
Selectable Clock and Data
●
or 37-bit Wiegand Output
Built-in Buzzer
●
4 Colour LED
●
Surface or flush mount (mounting
●
directly on to standard electrical box)
Robust Polycarbonate housing
●
Indoor or outdoor installation (IP67)
●
Operates between -20ºC and +50ºC
●
+8V to +16V DC operation
●
Installation / Specification Guidelines
May be installed in exposed
●
outdoor conditions (IP67)
May be a maximum of 100m from the
●
controller when powered from +12V
Use 8 core screened cable
●
-Belden 9504 or equivalent
mifare Card Readers
ACTpro mifare 1040
3000
ACTpro mifare 1050
Door 1
Door 2
100
ACTpro mifare Schematic
1050
1040
1050
