PREFACE
1.This master price list of GT650 was newly prepared and the prices herein will
be effective on orders received by us and after October 24, 2003.
Any price list of GT650 issued previously is no longer valid.
2.This master price list is based on US$ and EUR, and the prices are per a piece,
not per sales unit.
3.Prices and sales unit in this master price list may be changed without prior
notice.
HYOSUNG MOTORS & MACHINERY INC.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT650 - PARTS CATALOGUE and is the answer not in the manual?

Questions and answers

Related Manuals for HYOSUNG GT650 - PARTS CATALOGUE

Summary of Contents for HYOSUNG GT650 - PARTS CATALOGUE

  • Page 1 2.This master price list is based on US$ and EUR, and the prices are per a piece, not per sales unit. 3.Prices and sales unit in this master price list may be changed without prior notice. HYOSUNG MOTORS & MACHINERY INC.
  • Page 2 When you order plastic covers including Fuel tank, please add color code to the end of parts number and it will be helpful to register your parts order. Color code : CMB(Midnight Black),CMO(Mango Orange),CDB(Deep Blue), CTR (Red) HYOSUNG MOTORS & MACHINERY INC.
  • Page 4 FIG 1-1. CYLINDER HEAD/(FRONT) REC.Q'TY / REF. PART NUMBER. Q`TY REMARKS PART NAME 100 Motorcycles DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 11110SN9100HPA 11110SN9100HPA 11110SN9100HPA 11110SN9100HPA 11110SN9100HPA 11110SN9100HPA 11110SN9100HPA 11110SN9100HPA HEAD ASS’Y, cylinder front HEAD COMP, cylinder 1-1 11110HN9100HPA 11110HN9100HPA 11110HN9100HPA 11110HN9100HPA 11110HN9100HPA 11110HN9100HPA 11110HN9100HPA 11110HN9100HPA COVER, cylinder head front...
  • Page 6 FIG 1-2. CYLINDER HEAD/(REAR) REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 11120SN9100HPA 11120SN9100HPA 11120SN9100HPA 11120SN9100HPA 11120SN9100HPA 11120SN9100HPA 11120SN9100HPA 11120SN9100HPA HEAD ASS’Y, cylinder rear HEAD COMP, rear 1-1 11120HN9100HPA 11120HN9100HPA 11120HN9100HPA 11120HN9100HPA 11120HN9100HPA 11120HN9100HPA 11120HN9100HPA 11120HN9100HPA COVER, cylinder head rear 11171HN91000S1...
  • Page 8 FIG 2. CYLINDER /FRONT, REAR REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 11210HN9100HPA 11210HN9100HPA 11210HN9100HPA 11210HN9100HPA 11210HN9100HPA 11210HN9100HPA 11210HN9100HPA 11210HN9100HPA CYLINDER COMP, front 11220HN9100HPA 11220HN9100HPA 11220HN9100HPA 11220HN9120HPA 11220HN9120HPA 11220HN9120HPA 11220HN9120HPA 11220HN9100PCY CYLINDER COMP, rear GASKET, cylinder...
  • Page 10 FIG 3. RADIATOR REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 17700HN9102121 17700HN9102121 17700HN9102121 17700HN9102121 17700HN9102121 17700HN9102121 17700HN9102121 RADIATOR ASS’Y, water NOT SALE RADIATOR COMP, water 17710HN9102121 17710HN9102121 17710HN9102121 17710HN9102121 17710HN9102121 17710HN9102121 17710HN9102121...
  • Page 12 FIG 4. CRANK CASE REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 11300HN9100HPA 11300HN9100HPA 11300HN9100HPA 11300HN9100HPA 11300HN9100HPA 11300HN9100HPA 11300HN9100HPA 11300HN9100HPA CRANKCASE ASS’Y CRANKCASE COMP, L 11320HN9104PCC 11320HN9104PCC 11320HN9104PCC 11320HN9104PCC 11320HN9104PCC 11320HN9104PCC 11320HN9104PCC 11320HN9104PCC CRANKCASE COMP, R 11310HN9104PCC 11310HN9104PCC 11310HN9104PCC 11310HN9104PCC 11310HN9104PCC 11310HN9104PCC 11310HN9104PCC...
  • Page 14 FIG 5. CRANK CASE COVER REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 11331HN91010S1 11331HN91010S1 11331HN91010S1 11331HN91010S1 11331HN91010S1 11331HN91010S1 11331HN91010S1 11331HN91010S1 COVER COMP, clutch (Without oil le 11331SN9101HPA 11331SN9101HPA 11331SN9101HPA 11331SN9101HPA 11331SN9101HPA 11331SN9101HPA...
  • Page 16 FIG 6. CRANK SHAFT REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 12200HN9100HPA 12200HN9100HPA 12200HN9100HPA 12200HN9100HPA 12200HN9100HPA 12200HN9100HPA 12200HN9100HPA 12200HN9100HPA CRANK SHAFT ASS’Y 12161HN9101 12161HN9101 12161HN9101 12161HN9101 12161HN9101 12161HN9101 12161HN9101 12161HN9101 ROD, connecting 09263H37001...
  • Page 18 FIG 7. STARTER CLUTCH REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 12611HN9100 12611HN9100 12611HN9100 12611HN9100 12611HN9100 12611HN9100 12611HN9100 12611HN9100 GEAR, starter idle PIN,starter idle gear 12612HN9100 12612HN9100 12612HN9100 12612HN9100 12612HN9100 12612HN9100 12612HN9100...
  • Page 20 FIG 8. CAMSHAFT / VALVE REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 12710HN9100HPA 12710HN9100HPA 12710HN9100HPA 12710HN9100HPA 12710HN9100HPA 12710HN9100HPA 12710HN9100HPA 12710HN9100HPA CAMSHAFT ASS’Y, front intake CAMSHAFT ASS’Y, front exhaust 12730HN9100HPA 12730HN9100HPA 12730HN9100HPA 12730HN9100HPA 12730HN9100HPA 12730HN9100HPA 12730HN9100HPA 12730HN9100HPA CAMSHAFT ASS’Y, rear intake 12720HN9100HPA 12720HN9100HPA 12720HN9100HPA 12720HN9100HPA 12720HN9100HPA 12720HN9100HPA 12720HN9100HPA...
  • Page 22 FIG 8. CAMSHAFT / VALVE REF. PART NUMBER PART NAME NEU01 (WVTA) 12892-05C00152 PASTILLE REGLAGE SOUP.152 12892-05C00155 PASTILLE REGLAGE SOUP.155 12892-05C00158 PASTILLE REGLAGE SOUP.158 12892-05C00160 PASTILLE REGLAGE SOUP.160 12892-05C00162 PASTILLE REGLAGE SOUP.162 12892-05C00165 PASTILLE REGLAGE SOUP.165 12892-05C00168 PASTILLE REGLAGE SOUP.168 12892-05C00170 PASTILLE REGLAGE SOUP.170 12892-05C00172...
  • Page 24 FIG 9. CAM CHAIN REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 12760HN9100 12760HN9100 12760HN9100 12760HN9100 12760HN9100 12760HN9100 12760HN9100 12760HN9100 CHAIN COMP, camshaft drive GUIDE, camchain NO.1 12771HN9100 12771HN9100 12771HN9100 12771HN9100 12771HN9100 12771HN9100...
  • Page 26 FIG 10. CARBURETOR ASSY REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) NA/PAT01 PEU01/03 PG/PF/PS01 PUS01 NA/PAT02 NEU02 PEU02/04 13200HN9100 13200HN9100 13200HN9170 13200HN9100 13200HN9100 13200HN9170 13200HN9100 13200HN9100 CARBURATOR ASS’Y 13301HN9100 13301HN9100 13301HN9100 13301HN9100...
  • Page 28 FIG 10. CARBURETOR ASSY REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) NA/PAT01 PEU01/03 PG/PF/PS01 PUS01 NA/PAT02 NEU02 PEU02/04 13200HN9100 13200HN9100 13200HN9170 13200HN9100 13200HN9100 13200HN9170 13200HN9100 13200HN9100 CARBURATOR ASS’Y 41 13368HN9100 13368HN9100 13368HN9100 13368HN9100...
  • Page 30 FIG 11. CARBURETOR FITTINGS REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 13325HN9100 13325HN9100 13325HN9100 13325HN9100 13325HN9100 13325HN9100 13325HN9100 13325HN9100 HOSE 44199HM7900 44199HM7900 44199HM7900 44199HM7900 44199HM7900 44199HM7900 44199HM7900 44199HM7900 HOSE FUEL 13330HN9100 13330HN9100 13330HN9100...
  • Page 32 FIG 12. AIR CLEANER&CHAMBER REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 13700HN9103 13700HN9103 13700HN9103 13700HN9103 13700HN9103 13700HN9103 13700HN9103 CLEANER ASS’Y, air 1-1 13700HN9104 13700HN9104 13700HN9104 13700HN9104 13700HN9104 13700HN9104 13700HN9104 CLEANER ASS’Y, air CLEANER ASS’Y, air 13700HN9160...
  • Page 34 FIG 13. MUFFLER REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 14305HN9130PLH 14305HN9105PLH 14305HN9105PLH 14305HN9105PLH 14305HN9105PLH 14305HN9105PLH 14305HN9105PLH 14305HN9130PLH MUFFLER, ASS’Y BODY COMP, muffler 14310HN9131 14310HN9103 14310HN9103 14310HN9103 14310HN9103 14310HN9103 14310HN9103 14310HN9131 PIPE COMP, exhaust front...
  • Page 36 FIG 14. OIL PUMP REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 16400HN9101 16400HN9101 16400HN9101 16400HN9101 16400HN9101 16400HN9101 16400HN9101 16400HN9101 PUMP ASS’Y, oil GEAR, oil pump driven 16331HN9101 16331HN9101 16331HN9101 16331HN9101 16331HN9101 16331HN9101...
  • Page 38 FIG 15. WATER PUMP REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 17400HN9101 17400HN9101 17400HN9101 17400HN9101 17400HN9101 17400HN9101 17400HN9101 17400HN9101 PUMP ASS’Y, water CASE COMP,WATER PUMP 1-1 17410HN9100 17410HN9100 17410HN9100 17410HN9100 17410HN9100 17410HN9100...
  • Page 40 FIG 16. RADIATOR HOSE REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 17610HN9100HPA 17610HN9100HPA 17610HN9100HPA 17610HN9100HPA 17610HN9100HPA 17610HN9100HPA 17610HN9100HPA 17610HN9100HPA THERMOSTAT COMP CONNECTOR COMP, thermostat inlet 17621HN91020S1 17621HN91020S1 17621HN91020S1 17621HN91020S1 17621HN91020S1 17621HN91020S1 17621HN91020S1...
  • Page 42 FIG 17. 2ND AIR REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 18500HN9100 18500HN9100 18500HN9100 18500HN9100 18500HN9100 18500HN9100 18500HN9100 18500HN9100 VALVE ASS’Y, 2ND air HOSE, 2ND air pipe 18631HN9101 18631HN9101 18631HN9101 18631HN9101 18631HN9101...
  • Page 44 FIG 18. CLUTCH ASSY REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 21210HN9101HPA 21210HN9101HPA 21210HN9101HPA 21210HN9101HPA 21210HN9101HPA 21210HN9101HPA 21210HN9101HPA 21210HN9101HPA GEAR COMP, primary driven 09167H20001 09167H20001 09167H20001 09167H20001 09167H20001 09167H20001 09167H20001 09167H20001 WASHER, clutch sleeve hub thrust...
  • Page 46 FIG 19. TRANSMISSION REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 24131HN9100 24131HN9100 24131HN9100 24131HN9100 24131HN9100 24131HN9100 24131HN9100 24131HN9100 SHAFT COMP, drive SHAFT COMP, counter 24121HN9103 24121HN9103 24121HN9103 24121HN9103 24121HN9103 24121HN9103 24121HN9103 24121HN9103...
  • Page 48 FIG 19. TRANSMISSION REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 43 24252HN9100 24252HN9100 24252HN9100 24252HN9100 24252HN9100 24252HN9100 24252HN9100 24252HN9100 BUSH, 5th drive gear SHIM, 5th drive gear 44 09181H25001 09181H25001 09181H25001 09181H25001...
  • Page 50 FIG 20. GEAR SHIFTING REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 25231HN9100 25231HN9100 25231HN9100 25231HN9100 25231HN9100 25231HN9100 25231HN9100 25231HN9100 FORK, gear shift No.3 FORK, gear shift No.1 25211HN9100 25211HN9100 25211HN9100 25211HN9100 25211HN9100...
  • Page 52 FIG 21. STARTING MOTOR REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 31100HN9100 31100HN9100 31100HN9100 31100HN9100 31100HN9100 31100HN9100 31100HN9100 31100HN9100 MOTOR ASS’Y, starting NUT, starter motor terminal 08316-16068 08316-16068 08316-16068 08316-16068 08316-16068 08316-16068...
  • Page 54 FIG 22. MAGNETO ASSY REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 32100HN9101 32100HN9101 32100HN9101 32100HN9101 32100HN9101 32100HN9101 32100HN9101 32100HN9101 MAGNETO ASS’Y STATOR ASS’Y 32101HN9101 32101HN9101 32101HN9101 32101HN9101 32101HN9101 32101HN9101 32101HN9101 32101HN9101 ROTOR, fly wheel...
  • Page 56 FIG 23. BATTERY REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 33610HM8100 33610HM8100 33610HM8100 33610HM8100 33610HM8100 33610HM8100 33610HM8100 33610HM8100 BATTERY ASS’Y(12V 12Ah. STX14-BS) LEAD WIRE, battery minus(-) 33860HN9100 33860HN9100 33860HN9100 33860HN9100 33860HN9100 33860HN9100...
  • Page 58 FIG 24. ELECTRICAL REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 31800HG5100 31800HG5100 31800HG5100 31800HG5100 31800HG5100 31800HG5100 31800HG5100 31800HG5100 RELAY ASS’Y, starting motor NUT, starter motor relay terminal 08316-26066 08316-26066 08316-26066 08316-26066 08316-26066...
  • Page 60 FIG 25. SPEEDOMETER ASSY REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 34100HN9101 34100HN9150 34100HN9150 34100HN9101 34100HN9101 34100HN9101 34100HN9101 34100HN9101 SPEEDOMETER ASS’Y BRACKET 34950HM8100 34950HM8100 34950HM8100 34950HM8100 34950HM8100 34950HM8100 34950HM8100 34950HM8100 LOWER CASE, speedometer 34105HM8100...
  • Page 62 FIG 26. HEAD LAMP REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 35100HM8162 35100HM8152 35100HM8152 35100HM8152 35100HM8102 35100HM8162 35100HM8162 35100HM8171 HEAD LAMP ASS’Y 35120HM8160 35120HM8160 35120HM8160 35120HM8150 35120HM8150 35120HM8150 REFLECTOR, headlamp 35120HM8100 35120HM8150 RIM, headlamp...
  • Page 64 FIG 27. FRONT TURN SIGNAL LAMP REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 35601HM8151 35601HM8151 35601HM8151 35601HM8151 35601HM8151 35601HM8151 35601HM8101 35601HM8151 LAMP ASS’Y, FT turnsignal R 35602HM8151 35602HM8151 35602HM8151 35602HM8151 35602HM8151 35602HM8151...
  • Page 66 FIG 28. WIRING HARNESS REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 36610HN9151 36610HN9151 36610HN9151 36610HN9151 36610HN9151 36610HN9151 36610HN9101 36610HN9103 HARNESS, wiring HORN ASS’Y 38500HM8101 38500HM8101 38500HM8101 38500HM8101 38500HM8101 38500HM8101 38500HM8101 38500HM8101 LOCK ASS’Y, steering...
  • Page 68 FIG 29. REAR COMBINATION REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 35710HM8152 35710HM8152 35710HM8152 35710HM8152 35710HM8152 35710HM8152 35710HM8152 35710HM8152 LAMP ASS`Y, tail & stop BULB, tail & stop(12V P21/5W) 09471-12047 09471-12047 09471-12047...
  • Page 70 FIG 30. FRAME REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 41100HN910103P 41100HN910103P 41100HN910103P 41100HN910103P 41100HN910103P 41100HN910103P 41100HN910103P 41100HN916103P FRAME COMP SHAFT, engine mounting link 41165HN9101 41165HN9101 41165HN9101 41165HN9101 41165HN9101 41165HN9101 41165HN9101 41165HN9101...
  • Page 72 FIG 31. PROP STAND REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 42310HN910003P 42310HN910003P 42310HN910003P 42310HN910003P 42310HN910003P 42310HN910003P 42310HN910003P 42310HN910003P STAND COMP, prop BOLT, prop stand 09100-10031 09100-10031 09100-10031 09100-10031 09100-10031 09100-10031 09100-10031...
  • Page 74 FIG 32. REAR BRAKE REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 43110HM810003P 43110HM810003P 43110HM810003P 43110HM810003P 43110HM810003P 43110HM810003P 43110HM810003P 43110HM810003P PEDAL COMP, brake BRACKET COMP, front footrest R 43530HM810503P 43530HM810503P 43530HM810503P 43530HM810503P 43530HM810503P...
  • Page 76 FIG 33. FOOTREST REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 43570HM8100 43570HM8100 43570HM8100 43570HM8100 43570HM8100 43570HM8100 43570HM8100 43570HM8100 FOOTREST ASS’Y, front L FOOTREST BAR, front L 43571HM8100 43571HM8100 43571HM8100 43571HM8100 43571HM8100 43571HM8100...
  • Page 78 FIG 34. FUEL TANK REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 44110HN9100CMB TANK COMP, fuel NOIR 44110HN9100CMO TANK COMP fuel JAUNE 44110HN9100CDB TANK COMP fuel BLEU 44110HN9100CTR TANK COMP fuel ROUGE 44520HM8100 44520HM8100 44520HM8100...
  • Page 80 FIG 35. SEAT REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 45110HN9100 45110HN9100 45110HN9100 45110HN9100 45110HN9100 45110HN9100 45110HN9100 45110HN9100 SEAT SET, front KNOB COMP, seat front 45120HM8101 45120HM8101 45120HM8101 45120HM8101 45120HM8101 45120HM8101 45120HM8101...
  • Page 82 FIG 36. REAR FENDER REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 63112HM810212A 63112HM810212A 63112HM810212A 63112HM810212A 63112HM810212A 63112HM810212A 63112HM810212A FENDER, rear front FENDER, rear lower 63113HM810112A 63113HM810112A 63113HM810112A 63113HM810112A 63113HM810112A 63113HM810112A 63113HM810112A 63113HM810112A BAND, tool 09280-63003...
  • Page 84 FIG 37. SIDE COVER REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 47111HN9100 47111HN9100 47111HN9100 47111HN9100 47111HN9100CMB 47111HN9100 47111HN9160 47111HN9100 COVER, side R color NOIR 47111HN9100CMO COVER side R color JAUNE 47111HN9100CDB COVER side R color BLEU 47111HN9100CTR...
  • Page 86 FIG 38. FRONT FORK REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 51100HN9100HPA 51100HN9100HPA 51100HN9100HPA 51100HN9100HPA 51100HN9100HPA 51100HN9100HPA 51100HN9100HPA FORK ASS’Y, front ~ KM4MP51A341100140 51100HN9150HPA 51100HN9150HPA 51100HN9150HPA 51100HN9150HPA 51100HN9150HPA 51100HN9150HPA 51100HN9150HPA FORK ASS’Y, front KM4MP51A341100141~...
  • Page 88 FIG 39. STEERING HEAD REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 51311HM810403P 51311HM810403P 51311HM810403P 51311HM810403P 51311HM810403P 51311HM810403P 51311HM810403P 51311HM810403P BRACKET, front fork upper BOLT, front fork upper bracket 07110-08258 07110-08258 07110-08258 07110-08258...
  • Page 90 FIG 40. FRONT FENDER REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 53111HM8100 53111HM8100 53111HM8100 53111HM8100 53111HM81000MB 53111HM8100 53111HM8100 53110HN9180 FENDER, front NOIR 53111HM81000DB FENDER front BLEU 53111HM81000TR FENDER front ROUGE 53111HM81000MO FENDER front JAUNE 51811HM8101PAM 51811HM8101PAM 51811HM8101PAM 51811HM8101PAM 51811HM8101PAM 51811HM8101PAM 51811HM8101PAM...
  • Page 92 FIG 41. FRONT WHEEL REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 54141HM8102 54141HM8102 54141HM8102 54141HM8102 54141HM8102 54141HM8102 54141HM8102 54141HM8102 WHEEL, front (J17xMT3.0) TIRE COMP, front (120/60-17 55W) 55100HN9101 55100HN9101 55100HN9101 55100HN9101 55100HN9101...
  • Page 94 FIG 42. HANDLE BAR REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 56110HN9102 56110HN9102 56110HN9102 56110HN9102 56110HN9102 56110HN9102 56110HN9102 56110HN9102 HANDLE BAR COMP CABLE ASS’Y CLUTCH 58200HN9104 58200HN9104 58200HN9104 58200HN9104 58200HN9104 58200HN9104 58200HN9104...
  • Page 96 FIG 43. HANDLE SWITCH REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 37200HN9100 37200HN9100 37200HN9100 37200HN9100 37200HN9100 37200HN9100 37200HN9100 37200HN9100 SWITCH ASS’Y, handle R GRIP COMP, throttle 57110HG5803 57110HG5803 57110HG5803 57110HG5803 57110HG5803 57110HG5803...
  • Page 98 FIG 44. CALIPER LH REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 59300HM8101 59300HM8101 59300HM8101 59300HM8101 59300HM8101 59300HM8101 59300HM8101 CALIPER ASS’Y, L CALIPER ASS’Y, L 0-1 59300HM8102 59300HM8102 59300HM8102 59300HM8102 59300HM8102 59300HM8102 59300HM8102...
  • Page 100 FIG 45. CALIPER RH REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 59400HM8160 59400HM8160 59400HM8160 59400HM8160 59400HM8160 59400HM8160 59400HM8160 CALIPER ASS’Y, R ~KM4MP51B451100322 CALIPER ASS’Y, R 0-1 59400HM8161 59400HM8161 59400HM8161 59400HM8161 59400HM8161 59400HM8161...
  • Page 102 FIG 46. MASTER CYLINDER REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 59600HN9100 59600HN9100 59600HN9100 59600HN9100 59600HN9100 59600HN9100 59600HN9100 CYLINDER ASS’Y, front master ~KM4MP52B451100044 CYLINDER ASS’Y, front master 0-1 59600HN9102 59600HN9102 59600HN9102 59600HN9102...
  • Page 104 FIG 47. FRONT BRAKE HOSE REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 59711H49002 59711H49002 59711H49002 59711H49002 59711H49002 59711H49002 59711H49002 59711H49002 BOOT, brake hose HOSE COMP, FT brake R 59460HN9100 59460HN9100 59460HN9100 59460HN9100...
  • Page 106 FIG 48. SWINGING ARM REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 61100HN9105HPA 61100HN9105HPA 61100HN9105HPA 61100HN9105HPA 61100HN9105HPA 61100HN9105HPA 61100HN9105HPA 61100HN9105HPA REAR SWINGARM ASS’Y SWINGARM COMP, rear 61100HN9105 61100HN9105 61100HN9105 61100HN9105 61100HN9105 61100HN9105 61100HN9105...
  • Page 108 FIG 49. REAR SHOCKABSOR BER REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 62100HN9100 62100HN9100 62100HN9100 62100HN9100 62100HN9100 62100HN9100 62100HN9100 62100HN9100 SHOCK ABSORBER ASS’Y rear ~KM4MP51A341100140 SHOCK ABSORBER ASS’Y rear 62100HN9150 62100HN9150 62100HN9150...
  • Page 110 FIG 50. REAR FENDER REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 63111HM810112A 63111HM810112A 63111HM810112A 63111HM810112A 63111HM810112A 63111HM810112A 63111HM810112A 63111HM810112A FENDER, rear BOLT, rr fender 01517-06206 01517-06206 01517-06206 01517-06206 01517-06206 01517-06206 01517-06206 01517-06206...
  • Page 112 FIG 51. REAR WHEEL REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 64150SN9100HPA 64150SN9100HPA 64150SN9100HPA 64150SN9100HPA 64150SN9100HPA 64150SN9100HPA 64150SN9100HPA 64150SN9100HPA WHEEL + TIRE REAR ASS’Y. WHEEL COMP, rear (J17xMT4.50) 1-1 64150HN9100 64150HN9100 64150HN9100 64150HN9100...
  • Page 114 FIG 52. REAR CALIPER REF. PART NUMBER. Q`TY REMARKS REC.Q'TY PART NAME DOMESTIC NAT01 NAT02(25KW) NEN01 NEU01(WVTA) NEU02(WVTA 25KW NG01 PUS01 (PCS) 69300HN9100 69300HN9100 69300HN9100 69300HN9100 69300HN9100 69300HN9100 69300HN9100 CALIPER ASS’Y, rear brake CALIPER ASS’Y, rear brake 1-1 69300HN9101 69300HN9101 69300HN9101 69300HN9101 69300HN9101...
