DolbyRemote
Installation and Operation
P/N 91659
Issue 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P/N 91659 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dolby Laboratories P/N 91659

  • Page 1 DolbyRemote Installation and Operation P/N 91659 Issue 1...
  • Page 2 (including but not limited to damage to software or recorded audio or visual material), or loss of use, revenue or profit even if Dolby Laboratories or its agents have been advised, orally or in writing, of the possibility of such damages.
  • Page 3: Table Of Contents

    List of Figures ...v Chapter 1 Introduction ... 1-1 DolbyRemote Overview... 1-1 DolbyLoad... 1-1 Requirements... 1-1 1.3.1 PC System Requirements... 1-1 1.3.2 DP Firmware... 1-2 Software Installation... 1-2 Cable Installation... 1-3 Chapter 2 Establishing Communication ... 2-1 Starting DolbyRemote ... 2-1 2.1.1 Device Type ...
  • Page 4 Dual Mono... 4-9 4.4.1 Audio Service Configuration ... 4-10 4.4.2 Dynamic Range Compression... 4-10 4.4.3 Audio Production Information... 4-10 Input and Output Settings... 4-11 4.5.1 Input ... 4-11 4.5.2 Output ... 4-12 4.5.3 Input Subcode Status Bits ... 4-13 4.5.4 Test Tone Generation...
  • Page 5: List Of Figures

    DolbyRemote Open Device Window... 2-1 Device Off Line... 2-2 DolbyRemote Window... 2-3 Two Encoders Controlled... 2-3 Audio Service Parameters ... 4-1 Preprocessing Tab ... 4-6 Bitstream Info Tab... 4-8 Dual Mono Tab... 4-10 Input/Output Tab ... 4-11 Reference Input ... 4-14 Presets Tab...
  • Page 7: Chapter 1 Introduction

    DolbyRemote Overview The DolbyRemote application is used to remotely control the entire range of Dolby Laboratories Inc. Dolby Digital encoders. Key features of the software include: Control of several Dolby professional audio products from a single instance of the DolbyRemote application, hardware permitting. Off-line mode, without the presence of a unit, to create and edit parameter files.
  • Page 8: Software Installation

    Laboratories. Click Next to accept the default or click Browse to select an alternative location. 7. Use the program folder default Dolby Laboratories or enter an alternate folder name and click Next. 8. Insert the DolbyRemote Software Install Disk 2 when prompted to do so and click 9.
  • Page 9: Cable Installation

    D-9 end of the cable. The other end of the cable connects to the Remote port on the front panel of the encoder. Additional cables may be purchased from Dolby Laboratories. RS-485 connection for the DP567/DP569 requires a separate cable, not provided.
  • Page 11: Chapter 2 Establishing Communication

    Starting DolbyRemote From the Windows Start button, select DolbyRemote from the folder in which you installed the DolbyRemote application. The Open Device window is displayed, Figure 2-1. Figure 2-1 DolbyRemote Open Device Window 2.1.1 Device Type Selects the Dolby encoder model to be controlled. Choices are DP561, DP567 or DP569. 2.1.2 Communications These settings control the communication parameters for the DolbyRemote application.
  • Page 12: Off-Line

    DolbyRemote Installation and Operation through the front panel of the encoder. The rate you select in DolbyRemote must match the rate selected in the unit. Address The default address setting for the DP567 and DP569 is 0x8280. If the address has been changed from the front panel of the encoder, set the remote address accordingly.
  • Page 13: Additional Devices

    DolbyRemote Installation and Operation Additional Devices The DolbyRemote application can control several Dolby professional audio products. If you have more than one device you may control them all from a single instance of the DolbyRemote application, hardware permitting. To add additional encoders, click the New button or select File, New Device. The Open Device window is again displayed.
  • Page 14: Removing Devices

    DolbyRemote Installation and Operation Removing Devices To remove, or discontinue the remote control of a device, click Close or select File, Close Device. Establishing Communication...
  • Page 15: Chapter 3 Disk Files

    Saving and Restoring Configurations DolbyRemote can save the configuration of the active device so that it can easily be recalled later. The file extension for these configurations is .dby and can only be read with DolbyRemote. Configurations can be transferred between different devices of the same type, without complication, using this function.
  • Page 16 DolbyRemote Installation and Operation...
  • Page 17: Chapter 4 Dolby Digital Parameters

    This chapter briefly describes each of the parameters available in the windows of DolbyRemote. It is designed as a quick reminder for experienced users or as an introduction for new users rather than the full explanation that will be required. Detailed information about each encoder setting can be found in the relevant encoder user’s manual or in the pages of the Dolby Digital Professional Encoding Manual.
  • Page 18: Data Rate

    DolbyRemote Installation and Operation 4.1.2 Data Rate Data Rate determines the bit rate of the encoded Dolby Digital bitstream. All data rate options are allowed, however, selection of the data rate is dependent on the settings of the Audio Coding Mode, Sample Rate and Auxiliary Data parameters. Certain low data rates may not be supported in all channel modes.
  • Page 19: Lfe Enable

    DolbyRemote Installation and Operation designated as two numbers, A/B, with A indicating the number of front channels, and B indicating the number of rear (surround) channels. The following table lists all eight modes and defines which input channels are used for encoding based on the selected mode.
  • Page 20: Audio Bandwidth

    DolbyRemote Installation and Operation many different program types, with different reference levels, can be encoded with full dynamic range and then be decoded to give a uniform loudness level. 4.1.8 Audio Bandwidth Audio Bandwidth displays the current audio bandwidth of the main channels. This is dependent on the number of channels being encoded and the data rate.
  • Page 21: Coding Delay

    DolbyRemote Installation and Operation Encoder State Encoder State displays the status of encoding for the current device. There are three options for the encoder state: • Not Encoding—the user has requested that the unit start encoding, but the encoder is unable to encode because it is missing a required input signal. •...
  • Page 22: Preprocessing

    DolbyRemote Installation and Operation Preprocessing 4.2.1 Input Filtering Deemphasis The Deemphasis parameter controls whether or not 50/15 µs digital deemphasis may be applied to the main input channels before the Dolby Digital encoding process is performed. If Deemphasis is set to Disabled, deemphasis will never be applied and the emphasis channel status bit of input signals will be ignored.
  • Page 23: Surround Channel Processing

    DolbyRemote Installation and Operation 4.2.2 Surround Channel Processing 90 Degree Phase Shift 90 Degree Phase Shift controls whether or not a 90-degree phase shift is applied to the surround channel(s) before the Dolby Digital encoding process. Its use enables decoders to create a Dolby Surround compatible two-channel downmix. This parameter is disabled if the encoding mode does not include any surround channels.
  • Page 24: Bitstream Info

    DolbyRemote Installation and Operation custom compression modes. The default setting for RF Overmodulation Protection is disabled. This parameter is not available on the DP567. Input Level Meter Input Level Meter shows the input signal that the compressor is using to determine the amount of boost or cut.
  • Page 25: Audio Production Information

    DolbyRemote Installation and Operation Surround Mix Level Surround Mix Level is a parameter that indicates to the decoder the nominal downmix level of the surround channel(s) with respect to the left and right channels when listening in stereo. This is only active when in 2/1, 2/2, 3/1, or 3/2 coding modes.
  • Page 26: Audio Service Configuration

    DolbyRemote Installation and Operation 4.4.1 Audio Service Configuration Dialog Normalization Dialog Normalization sets the dialnorm value for channel two when in 1+1 Coding Mode only. 4.4.2 Dynamic Range Compression Input Level, Line Mode and RF Mode Input Level, Line Mode and RF Mode meters for channel two when in 1+1 Coding Mode only.
  • Page 27: Input And Output Settings

    DolbyRemote Installation and Operation Input and Output Settings 4.5.1 Input Lock Status Lock Status shows whether the input channels for the current coding mode have been detected and locked by the encoder. Sample Rate Sample Rate shows the sample rate of the digital input channels. Integrity Integrity shows the data integrity of the digital input channels.
  • Page 28: Channel Assignment

    DolbyRemote Installation and Operation • Autodetect: Automatically detects and processes PCM and pre-encoded bitstreams. Invalid bitstreams will be assumed to be PCM data, and encoding will be enabled. Aux Data Aux Data allows you to indicate whether the auxiliary data field is present in the encoded Dolby Digital bitstream.
  • Page 29: Input Subcode Status Bits

    DolbyRemote Installation and Operation Audio Bit Audio Bit allows you to set the audio bit in the output bitstream as either audio or non-audio, data. Certain AES/EBU inputs may require this to be set to audio before they will record the encoded bitstream. Multiplex Mode Multiplex Mode allows multiple encoded bitstreams to be combined into the main digital output bitstream.
  • Page 30: Stream Number

    DolbyRemote Installation and Operation does not guarantee that a valid test tone will be produced at the output of the DP567 or DP569. Dolby Digital encoding must also be active, which requires that the selected clock source be valid. The selection of a Test Tone mode automatically overrides the input format settings.
  • Page 31: Reference Input Subcode Status Bits

    DolbyRemote Installation and Operation Stream Number Stream Number shows the stream number for a pre-encoded bitstream present at the reference input. 4.6.2 Reference Input Subcode Status Bits These show the format, sample rate and audio bit as indicated in the subcode of the reference input signal.
  • Page 32: Configure

    DolbyRemote Installation and Operation 4.7.2 Configure Number Select the number of the present you wish to configure, 1 through 28. Presets 29 through 32 are factory defaults and cannot be overwritten. Name Enter a name, if desired, for the preset. Save Current Configuration Click this button to save the current configuration in the selected preset.
  • Page 33: Current Time Code

    DolbyRemote Installation and Operation Status Status shows whether there is a valid time code signal present on the selected input. 4.8.2 Current Time Code Current Time Code shows both the current time code value and frame rate in HH:MM:SS:FF format. If no time code input is present this box will be grayed out. 4.8.3 Start Time Code and Stop Time Code Values When the Encoder State parameter is set to Time Code Ctrl, the encoder is placed...
  • Page 34: Resume

    DolbyRemote Installation and Operation For instance, you might want the Stereo Music preset to take effect at time code 00:12:22:12. To do this, you follow the following procedure: 1. Select the Time Code tab page 2. Enter 00:12:22:12 in the Start Time Code field 3.
  • Page 35: Chapter 5 Troubleshooting

    Opening a Device If the DolbyRemote application is unable to communicate with the unit, check the following: DP569/DP567 Make sure the unit is in remote mode (press shift-left arrow). The remote LED should be lit. Make sure that you are either using a RS-232 connection through the front panel or a RS-485 (RS422 for DP567) connection through the rear panel.
  • Page 36: Further Information

    Further Information If you purchased this software through a dealer or systems integrator, please contact them for technical support. Information is also available at our web site . Dolby Laboratories can be contacted at the following addresses: www.dolby.com Dolby Laboratories Inc...

This manual is also suitable for:

Dolbyremote dp561Dolbyremote dp567Dolbyremote dp569
