LG R580-U.ARC3BA9 Service Manual

R580, rb580, r560, rb560 series
Hide thumbs Also See for R580-U.ARC3BA9:
Table of Contents

Advertisement

Quick Links

P/N :MFL62539202
REV.18

Service Manual

Model : R580, RB580, R560, RB560 Series
2011. 05. 12
Copy Rightⓒ2011 LG Electronic inc, DigitalMate Co,.Ltd.
(LGE Internal use only)
1

Advertisement

Table of Contents
loading

Related Manuals for LG R580-U.ARC3BA9

Summary of Contents for LG R580-U.ARC3BA9

  • Page 1: Service Manual

    P/N :MFL62539202 REV.18 Service Manual Model : R580, RB580, R560, RB560 Series 2011. 05. 12 Copy Rightⓒ2011 LG Electronic inc, DigitalMate Co,.Ltd. (LGE Internal use only)

  • Page 2: Table Of Contents

    Contents Ch 1. Service information Ch 2. Locations Ch 3. System information · Specification · Model configuration System Block Diagram · Fn key combinations · Status indicators · BIOS Flash · BIOS Setup · Ch 4. Symptom-to-part index Power system checkout ·...

  • Page 3: Ch1. Service Information

    Ch1. Service information Chapter 1. Service information 1-1. Important service information Strategy for replacing parts (FRU-Field Replaceable Units) Before replacing parts Make sure that latest BIOS and drivers are installed before replacing any parts (FRUs) listed in this Use the following strategy to prevent unnecessary expense for replacing and servicing parts 1.
  • Page 4 Ch1. Service information 1-2. Safety notices Warning Before the computer is powered-on after part (FRU) replacement, make sure all screws, springs, and other small parts are in place and are not left loose inside the computer. Verify this by shaking the computer and listening for rattling sounds. Metallic parts or metal flakes can cause electrical shorts.

  • Page 5: Safety Information

    Ch1. Service information 1-3. Safety information General safety Follow these rules to ensure general safety · Observe good housekeeping in the area of the machines during and after maintenance. · When lifting any heavy object 1. Ensure you can stand safely without slipping. 2.

  • Page 6: Electrical Safety

    Ch1. Service information Electrical safety Observe the following rules when working on electrical equipment. Important Use only approved tools and test equipment. Some hand tools have handles covered with a soft material that does not insulate you when working with live electrical currents. Many customers have, near their equipment, rubber floor mats that contain small conductive fibers to decrease electrostatic discharges.
  • Page 7 Ch1. Service information · Stand on suitable rubber mats (obtained locally, if necessary) to insulate you from grounds such as metal floor strips and machine frames. · Observe the special safety precautions when you work with very high voltages. These instructions are in the safety sections of maintenance information.
  • Page 8 Insulation must not be frayed or worn. 4. Remove the cover. 5. Check for any obvious non-LG alterations. Use good judgment as to the safety of any non-LG alterations. 6. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or other liquids, or signs of fire or smoke damage.
  • Page 9 Ch1. Service information Handling devices that are sensitive to electrostatic discharge Any computer part containing transistors or integrated circuits (ICs) should be considered sensitive to electrostatic discharge (ESD). ESD damage can occur when there is a difference in charge between objects.
  • Page 10 Ch1. Service information 1-4. Laser compliance statement When a CD-ROM drive, DVD drive or the other laser product is installed, note the following : Caution Use of controls or adjustments or performance of procedures other than those specified here in might result in hazardous radiation exposure.
  • Page 11 1-6. Read this first Before you go to the checkout guide, be sure to read this section. Important Notes Only trained personnel certified by LG should service the computer. · Read the entire FRU removal and replacement page before replacing any FRU.
  • Page 12 Ch1. Service information The followings are not covered under warranty : CD panel cracked from the application of excessive force or from being dropped · Scratched (cosmetic) parts · Distortion, deformation, or discoloration of the cosmetic parts · Cracked or broken plastic parts, broken latches, broken pins, or broken connectors caused by excessive ·...

  • Page 13: Ch2. Locations

    Ch2. Locations Chapter 2. Locations ■ Left View 1. Fan louvers 2. VGA Port 3. LAN Port 4. Modem Port 5. HDMI Port 6. e-SATA Port(USB-combo) 7. Multi Card Slot(xD/SD/MS/MS Pro) 8. Express Card Slot ■ Right View 9. Microphone Port 10.

  • Page 14: Front View

    Ch2. Locations ■ Front Back ④ ② ① ③ 15. Fan louvers ■ Front View 16. Built-in Microphone(May vary depending on model.) 17. Smart Cam(May vary depending on model.) 18. Power Button 19. Mute Button 20. Volume Down Button 21. Volume Up Button 22.

  • Page 15: Ch3. System Information

    Ch3. System information Chapter 3. System information Specification - Available Processors · Intel® Core™2 Duo / Pentium® Dual‐Core / Celeron® Dual‐Core / Celeron® Processors (L2 Cache Size: 1MB/2MB/3MB/6MB, FSB:667/800/1066MHZ ) are supported. The user must not replace or expand the CPU capacity arbitrarily. The CPU capacity differs depends on model type.
  • Page 16 Chapter 3. System information - Web Camera · 1.3 Mega pixels USB camera module · UVC (USB Video Class) driver supported ※ Web Camera is optional, and so it may not be installed in some models - External I/O Interface ·...

  • Page 17: System Block Diagram

    Chapter 3. System information ■ System Block Diagram...

  • Page 18: Fn Key Combinations

    Chapter 3. System information Fn key combinations The following table shows the function of each combination of Fn with a function key. Function of Fn keys has nothing to do with Operating System. Fn + F1 Customizable hot keys. (Configurable through OSD settings) Fn + F2 Customizable hot keys.

  • Page 19: Status Indicators

    Ch3. System information Status indicators The system status indicators show the status of the computer 1 . Power Lamp: • Blinking: System Standby • On: The system is running on the AC power or battery. • Off: The system is turned off or in Hibernates. 2.

  • Page 20: Wireless Lan/Bluetooth Lamp

    Ch3. System information 6 . Wireless LAN/Bluetooth lamp • Off: Wireless LAN/Bluetooth is not in use. • Blinking (short interval): Wireless LAN/Bluetooth is connected and data are being transmitted. • Blinking (every 2 ~ 3 seconds): Wireless LAN/Bluetooth is not connected but Wireless Radio is on. •...

  • Page 21: Bios Flash

    2. Copy BIOS Flash software to the flash update USB Device (FDD/USB Memory). 3. Connect the USB Device for USB Port. 4. Press F12 Key while the "LG LOGO" appears. 5. A while later, the system setup home screen appears.
  • Page 22 Ch3. System information 10. Press [F2] Key, then you can see the BIOS SETUP UTILITY screen as below. 11. It selects the :” Load Optimal Dafault” and it summons a BIOS settings at initial value.
  • Page 23 Ch3. System information 12. It selects the “Exit & Saving Change” and it stores system a settings and the reboot...
  • Page 24 Ch3. System information BIOS Release Process and Making Bootable CD 1. LGE(Korea) will upload BIOS Image(*.iso) to GCSC(Global Cyber Service Center:http://biz.lgservice.com) when BIOS should be updated. 2. BIOS will include both System BIOS and EC(Embedded Controller) BIOS. 3. Service center can download BIOS file from GCSC and update BIOS according to below procedure. 4.
  • Page 25 Ch3. System information c. Select “Disc Image or Saved Project” d. Select File Format as "Image Files(*.iso)".
  • Page 26 Ch3. System information e. Open Image File(*.iso) which is sent from LGE f. Tab Burn then burning will be started...
  • Page 27 Ch3. System information g. Burn process completed as below, and tab “OK...
  • Page 28 Ch3. System information BIOS/EC Flash Process 1. Insert Bootable CD in PC, and Turn it on, then PC will boot by DOS mode as below (If the EC is not correct or old version, then automatically update EC first and reboot again) 2.
  • Page 29 Ch3. System information 4. Type in Mode Name at the “WIP ID :” then press Enter key (You must use Capital Letter) (You can see the Model Name in ID Label at the bottom Case of PC: “M/N: LMXX-XXXX”) 5. Type in Serial No at the “WIP ID :” then press Enter key (You must use Capital Letter) (You can see the Serial No in ID Label at the bottom Case of PC: “S/N: 412KIXXXXXXXX”(13digits)) 6.
  • Page 30 Ch3. System information 5. After flashing is completed, you can see the “PASS” on your screen, and reboot your PC...

  • Page 31: Bios Setup

    2. to replace the backup battery 3. system configuration error occurs 4. to change the boot order 5. to set/change a password Press the power button. When the LG logo appears on the screen, press and enter the BIOS Setup Utility.

  • Page 32: Using The Keys

    Ch3. System information Using the keys The keys used in the BIOS Setup Utility and their functions are described at the bottom. · : General Help Display the descriptions of the keys used in the setup utility. · : Select Item Navigate and select items in the setup utility.

  • Page 33: Main Menu

    Ch3. System information Main menu · System Time Current time. To change the value, press <+> or <−> key. · System Date Current date. To change the value, press <+> or <−> key. · SATA Hard Drive This shows the description of the drive connected to the SATA port. To change the settings of the connected drive, click <Enter>...

  • Page 34: Advanced Menu

    Ch3. System information Advanced menu · USB BIOS Legacy Support This enables to use the USB devices in the MS-DOS environment. · HDC Configure as This configures the compatibility settings for the SATA controller. · VT Support Set whether or not to support the Intel virtualization technology. ·...
  • Page 35 Ch3. System information Security menu Supervisor Password · The password setting prevents not allowed users from using the notebook computer. The password is not set when starting the system for the first time. When the system is turned on, any other user cannot change the BIOS settings without entering the specified password.

  • Page 36: Boot Menu

    Ch3. System information Boot menu · Quick Boot Set whether or not to use Quiet Boot. · PXE Boot to LAN Set whether or not to use the HDD password. · Boot Device Priority Select the desired device drive by using the arrow buttons and change its booting sequence by using the [+] or [-] key.

  • Page 37: Info Menu

    · Serial Number This shows the serial number of the product. · SLP 2.0 The Vista OS protection device will be able to use from LG. · CPU Type This shows the type of the CPU installed in the system.

  • Page 38: Exit Menu

    Ch3. System information Exit menu Exit & Save Change · Save the changes you have made and exit the utility. Exit & Discard Changes · Exit the utility without saving the changes you have made. Load Optimal Defaults · This changes the parameters in the Setup menu to the factory default settings. When it is selected or [F9] key is pressed, the confirmation message appears.
  • Page 39 Ch3. System information ■ Backup and Restore Security Platform Data Security Platform Backup includes all data required in case of emergency. After a hardware or storage media failure or a Trusted Platform Module failure, Security Platform Restoration reestablishes access to Security Platform Features for all users.
  • Page 40 Ch3. System information Personal Secure Drive Backup Contents A copy of the PSD encrypted data and configuration settings. Purpose Restoration of PSD encrypted data and configuration settings after a hardware or storage media failure. Otherwise users could not decrypt their PSD data anymore. Notes: •...
  • Page 41 Ch3. System information ■ How to Backup and Restore How to configure automatic backups Software Component to use ("System Backup") Administrative Task: Configure automatic If Security Platform is not yet initialized: backups for all users (including Security Initialization Wizard Platform Credentials and Settings, If Security Platform is already initialized: Settings Emergency Recovery and PSD configuration Tool - Backup - Configure...
  • Page 42 Ch3. System information ■ Infineon Platform Security Backup With this page you can backup and restore Security Platform credentials, Security Platform settings and Personal Secure Drives. If Enhanced Authentication is enabled, you can also create backups of your authentication device. Availability of page: This page is only available on an initialized Security Platform, if one of the following conditions is fulfilled: •The current user has administrative rights.

  • Page 43: Ch4. Symptom-To-Part Index

    Ch4. Symptom-to-part index Chapter 4. Symptom-to-part index The symptom-to-part index in this section lists symptoms and errors and their possible causes. The most likely cause is listed first. Note If replacing a part (FRU) does not solve the problem, put the original part back in the computer. Do not replace a non-defective FRU.
  • Page 44 Ch4. Symptom-to-part index To check the AC adapter, do the following : 1. Unplug the AC adapter cable from the computer. Voltage (V dc) 2. Measure the output voltage at the plug of the +18.05 ~ +19.95 AC adapter cable. See the following figure : Ground 3.
  • Page 45 Ch4. Symptom-to-part index · If the voltage is not correct, replace the AC adapter. · If the voltage is acceptable, do the following : 1. Replace the system board. 2. If the problem persists, check the AC adapter whether it is correct product or not. Note Noise from the AC adapter does not always indicate a defect.
  • Page 46 Ch4. Symptom-to-part index · The Characteristics of the battery pack 1. Self-discharge The battery gradually loses its power over time without ever being used. 2. Periodic full discharge / charge Frequent recharge of the battery pack can reduce the capacity of the battery pack. When this happens, you can perform the full discharge / charge to improve the capacity.
  • Page 47 Ch4. Symptom-to-part index · To check the battery pack, do the following : 1. Power off the computer. 2. Remove the battery pack and measure the voltage between battery terminals 1(-) and 5(+). See the following figure : Terminal Voltage (V dc) Ground(-) +0V ~ +12.6V 5(+)

  • Page 48: Numeric Error Codes

    Ch4. Symptom-to-part index Numeric error codes Symptom / Error FRU or action, in sequence 0200 1.Reset the hard-disk drive. Fixed disk failure 2.Load Setup Defaults in BIOS Setup Utility. (The hard disk is not working) 3.Hard-disk drive. 4.System board. 0210 1.Check the keyboard if it is pressed.
  • Page 49 Ch4. Symptom-to-part index Symptom / Error FRU or action, in sequence 0251 Replace the backup battery and run BIOS Setup System CMOS checksum bad Utility – System CMOS checksum is not correct. to reset the time and date. – Default configuration used. 0252 Reset the password by running BIOS Setup Utility.
  • Page 50 Ch4. Symptom-to-part index Symptom / Error FRU or action, in sequence 02F7 1. DIMM Fail – Safe timer NMI failed 2. System board 0611 1. Load Setup Defaults in BIOS Setup Utility. IDE configuration changed 2. System board. 0612 1. Load Setup Defaults in BIOS Setup Utility. IDE configuration error 2.

  • Page 51: Error Messages

    Ch4. Symptom-to-part index Error message Symptom / Error FRU or action, in sequence Device address conflict. 1. Load Setup Defaults in BIOS Setup Utility. 2. Backup battery. 3. System board. Allocation error for device. 1. Load Setup Defaults in BIOS Setup Utility. 2.

  • Page 52: Lcd-Related Symptoms

    Ch4. Symptom-to-part index LCD-related symptoms Note Before removing or disassembling LCD, power off the computer, unplug all power cords from electrical outlets, remove the battery pack also. Symptom / Error FRU or action, in sequence LCD screen becomes dark suddenly. Check out Battery Miser.

  • Page 53: Indeterminate Problems

    1. Power off the computer 2. Visually check each FRU for damage. Replace any damaged FRU. 3. Remove or disconnected all of the following devices : a. Non-LG devices. b. Printer, mouse, and other external devices. c. Battery pack. d. PC cards.

  • Page 54: Ch 5. Removing And Replacing A Part (Fru)

    Ch5. Removing and replacing a part Chapter 5. Removing and replacing a part (FRU) Danger Before removing any FRU, power off the computer, unplug all power cords from electrical outlets, remove the battery pack, and then disconnect any interconnecting cables. Caution Before the computer is powered on after FRU replacement, make sure that all screws, springs, and other small parts are in place and are not loose inside the computer.
  • Page 55 Ch5. Removing and replacing a part ■ 1010 Battery Pack 1. Push the battery latch in the direction shown below; then slide the battery pack out of the slot. 2. Remove the Battery Pack.

  • Page 56: Memory Removing/Replacing

    Ch5. Removing and replacing a part ■ 1020 Memory ※ Remove the following parts in order before replacing this part a. Battery Pack(1010) 1. Remove the 3 screw. 2. Remove the Memory Cover.
  • Page 57 Ch5. Removing and replacing a part 3. Remove the Hook. Hook Hook Hook Hook 4. Remove the Memory.

  • Page 58: Hdd Removing/Replacing

    Ch5. Removing and replacing a part ■ 1030 HDD ※ Remove the following parts in order before replacing this part a. Battery Pack(1010) 1. Remove the 2 Screw. 2. Remove the HDD Cover.
  • Page 59 Ch5. Removing and replacing a part 3. Remove the HDD 4. Remove the 4 Screw. FRU No. Specification FAB30479801 (M3.0*3.0MM) White...
  • Page 60 Ch5. Removing and replacing a part 5. Remove the HDD Shield.
  • Page 61 Ch5. Removing and replacing a part ■ 1040 Wi-Fi Cover ※ Remove the following parts in order before replacing this part a. Battery Pack(1010) 1. Remove the 1 Screw. 2. Remove the Wi-Fi Cover.
  • Page 62 Ch5. Removing and replacing a part ■ 1050 WLAN Module ※ Remove the following parts in order before replacing this part Battery Pack(1010), b. Wi-Fi Cover(1040) 1. Remove the Antenna Cable 2 Screw. 2. Remove the 1 Screw. FRU No. Specification FAB30208501 (M2.0*3.0MM) White...
  • Page 63 Ch5. Removing and replacing a part 3. Remove the WLAN Module.
  • Page 64 Ch5. Removing and replacing a part ■ 1060 Turbo Memory ※ Remove the following parts in order before replacing this part Battery Pack(1010), b. Wi-Fi Cover(1040) 1. Remove the 1 Screw. FRU No. Specification MM20030ICI3 (M2.0*3.0MM) White 2. Remove the Turbo Memory.
  • Page 65 Ch5. Removing and replacing a part ■ 1070 ODD ※ Remove the following parts in order before replacing this part a. Battery Pack(1010) 1. Remove the 1 Screw. FRU No. Specification FAB30479701 (M2.5*6.5MM) black 2. It uses JIG and pushes separates with arrow ticket direction.
  • Page 66 Ch5. Removing and replacing a part 3. Remove the ODD. 4. Remove the ODD Bezel. Bezel...
  • Page 67 Ch5. Removing and replacing a part ■ 1080 Retainer/Keyboard ※ Remove the following parts in order before replacing this part a. Battery Pack(1010) 1. Remove the 6 Screw.. FRU No. Specification FAB30479701 (M2.5*6.5MM) black FAB30255101 (M2.5*3.0MM) White 2. It uses JIG and it removes the Hooks.
  • Page 68 Ch5. Removing and replacing a part 3. Remove the 2 Screw. FRU No. Specification FAB30255101 (M2.5*3.0MM) black 4. Remove the Retainer/Keyboard Cable. Cable Cable...
  • Page 69 Ch5. Removing and replacing a part 5. Remove the Keyboard. 6. Remove the Retainer.
  • Page 70 Ch5. Removing and replacing a part ■ 1090 Display Module ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1080) 1. Remove the 4 Screw. FRU No. Specification FAB30479701 (M2.5*6.5MM) black FAB30255101 (M2.5*3.0MM) White 2.
  • Page 71 Ch5. Removing and replacing a part 3. Remove the Display Module.
  • Page 72 Ch5. Removing and replacing a part ■ 1100 Button Sub Board ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1080), c. Display Module(1090) 1. Remove the 1 Screw. Cable 2. Remove the Button Sub Board.
  • Page 73 Ch5. Removing and replacing a part ■ 1120 Keydeck ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1080), c. Display Module(1090), d. Button Sub Board(1100) 1. Remove the 10 Screw. FRU No. Specification (M2.5*6.5MM) black 10EA...
  • Page 74 Ch5. Removing and replacing a part 3. Remove the Keyboard deck.
  • Page 75 Ch5. Removing and replacing a part ■ 1130 USB(R) Sub Board ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1080), c. Display Module(1090), d. Button Sub Board(1100) e. Keydeck(1120) 1. Remove the Cable and 2 Screw. Cable Cable FRU No.
  • Page 76 Ch5. Removing and replacing a part ■ 1140 Bluetooth Module ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1080), c. Display Module(1090), d. Button Sub Board(1100) e. Keydeck(1120) 1. Remove the Bluetooth. 2.
  • Page 77 Ch5. Removing and replacing a part ■ 1150 Touch Pad ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1080), c. Display Module(1090), d. Button Sub Board(1100) e. Keydeck(1120) 1. Remove the 1 Connector. Connector 2.
  • Page 78 Ch5. Removing and replacing a part ■ 1160 Mainboard ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1080), c. Display Module(1090), d. Button Sub Board(1100) e. Keydeck(1120) , f. USB(R) Sub Board(1130) 1.
  • Page 79 Ch5. Removing and replacing a part 3. Remove the Mainboard Case.
  • Page 80 Ch5. Removing and replacing a part ■ 1170 CPU/GPU Fan Assembly ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Memory(1020) 1. Remove the 7 Screw. Cable 2. Remove the CPU/GPU Fan Assembly.
  • Page 81 Ch5. Removing and replacing a part ■ 1180 CPU ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1080), c. Display Module(1090), d. Button Sub Board(1100) e. Keydeck(1120) , f. Mainboard(1160) , g. CPU/GPU Fan Assembly(1170) 1.
  • Page 82 Ch5. Removing and replacing a part ■ 1190 Modem Module ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1080), c. Display Module(1090), d. Button Sub Board(1100) e. Keydeck(1120) , f. Mainboard(1160) 1. Remove the 2 Screw and Cable. Cable 2.
  • Page 83 Ch5. Removing and replacing a part ■ 1200 AC Connector ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1080), c. Display Module(1090), d. Button Sub Board(1100) e. Keydeck(1120) 1. Remove the 2 Screw and Cable. Cable 2.
  • Page 84 Ch5. Removing and replacing a part ■ 1210 Speaker ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1080), c. Display Module(1090), d. Button Sub Board(1100) e. Keydeck(1120) , f. Mainboard(1160) 1. Remove the 2 Screw. 2.
  • Page 85 Ch5. Removing and replacing a part ■ 1220 LCD Front Case ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard(1080), c..Keydeck(1120) 1. Remove the 4 Rubber and 4 Screw . FRU No. Specification FAB30479701 (M2.5*6.5MM) black 2.
  • Page 86 Ch5. Removing and replacing a part 3. Remove the Hinge Cap.
  • Page 87 Ch5. Removing and replacing a part ■ 1230 LCD Assembly ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1080), c. Display Module(1090 ) d. LCD Front Case(1220) 1. Remove the 4 Screw. FRU No.
  • Page 88 Ch5. Removing and replacing a part ■ 1240 LCD Panel Bracket ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1080), c. Display Module(1090 ) d. LCD Front Case(1220) e. LCD Assembly(1230) 1. Remove the 4 Screw. FRU No.
  • Page 89 Ch5. Removing and replacing a part ■ 1250 LCD Cable ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1080), c. Display Module(1090 ) d. LCD Front Case(1220) e. LCD Assembly(1230), f. LCD Panel Bracket(1240) 1.
  • Page 90 Ch5. Removing and replacing a part ■ 1260 Web Cam Module ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1080), c. Display Module(1090 ) d. LCD Front Case(1220) 1. Remove the Web Cam Module.
  • Page 91 Ch5. Removing and replacing a part ■ 1270 Wireless ANT ※ Remove the following parts in order before replacing this part a. Battery Pack(1010), b. Retainer/Keyboard (1080), c. Display Module(1090 ) d. LCD Front Case(1220) e. LCD Assembly(1230), f. LCD Panel Bracket(1240) 1.

  • Page 92: Ch 6. Part List

    Ch6. Part lists Chapter 6. Part lists REV.18 Category Loc. No. LG P/N Description Remark NMLB01 EBR63154402 QL5 MB INT,GL40(A1)BT W/O CPU (DDR2) NMLB01 EBR63154502 QL5 MB INT,GL40 W/O CPU,MODEM (DDR2) NMLB01 EBR63154401 QL5 MB (INTEL,UMA) W/O CPU (DDR2) NMLB01...
  • Page 93 Ch6. Part lists Category Loc. No. LG P/N Description Remark NCVR02 ACQ74458802 HDD DOOR ASSY_Black NCVR02 ACQ74458801 HDD DOOR ASSY_White Cover NCVR03 ACQ74459702 MINI CARD DOOR ASSY_Black NCVR03 ACQ74459701 MINI CARD DOOR ASSY_White NHDD01 EAZ60666901 160GB SATA 5400RPM FUJITSU 6/10 add(09')
  • Page 94 Ch6. Part lists Category Loc. No. LG P/N Description Remark NMRY01 EAN51348602 1GB DDR3 1066MHz HYNIX 12/28 add(09') Racer 15 video Memory NMRY01 EAN51348902 2GB DDR3-1066MHz HYNIX refresh model application NBATT01 EAC34785411 QL6 BATTERY LI 6-CELL 4.4A S.P. NBATT01 EAC34785410 QL6 BATTERY LI 6-CELL 4.8A S.P.
  • Page 95 CABLE ASSY QL5 LCD(40/40P,3A)300V,FOX(Remark:HD+) NLCD03 ABQ72944101 HINGE L SZS QL5(FBQL5001,REV3A) NLCD09 ABQ72944102 HINGE R SZS QL5(FBQL5002,REV3A) NLCD04 ABQ72944003 QL5 LCD COVER ASSY/STANDARD/WH/LG NLCD04 ABQ72944005 QL5 LCD COVER ASSY/STANDARD/BK/LG NLCD04 ABQ72944006 QL5 LCD COVER ASSY/STANDARD/BK/XONTE NLCD04 ABQ72944004 QL5 LCD COVER ASSY/STANDARD/WH/XNOTE...
  • Page 96 Ch6. Part lists Category Loc. No. LG P/N Description Remark NPWCD01 EAD55718603 POWER CORD(EU) 1.8M 3PBLACK FM010008-010 NPWCD01 EAD50481701 POWERCORD1.83M(EU,2P,BLK)FW0-I0008-005EP NPWCD01 EAD55718604 PWR CORD V3N5B30161218006 UK 3P NPWCD01 EAD50476201 POWERCORD1.83M(UK,2P,BLK)FWO-I0008-006EP NPWCD01 6410BW21601 POWER CORD(RSA)1.83M 3P FZ0V0005-046 NPWCD01 EAD55718607 PWCRD(ISR)1.83M 3P 250V S606B30161218307...
  • Page 97 Ch6. Part lists Category Loc. No. LG P/N Description Remark NCPU01 EAN51675701 T9400 2.53GHZ 9/30 add(09') NCPU01 EAN51675601 T9600 2.8GHZ 1/14 add(10') NCPU01 EAN61018001 P9700 2.8GHZ 1/14 add(10') NCPU01 EAN61017901 Celeron 900, R-0 2.2GHZ 1/14 add(10') NVCPEMWR002G2 QJL7 16GBIT 1GX16BIT 2.7VTO3.6V...
  • Page 98 NLCD05 NLCD09 NLCD03 NLCD01 NWEBC01 NLCD02 NLCD04 NLCD08 NLCD07...
  • Page 99 CABLE ASSY QL5 LCD(40/40P,3A)300V,FOX(Remark:HD+) NLCD03 ABQ72944101 HINGE L SZS QL5(FBQL5001,REV3A) NLCD09 ABQ72944102 HINGE R SZS QL5(FBQL5002,REV3A) NLCD04 ABQ72944003 QL5 LCD COVER ASSY/STANDARD/WH/LG NLCD04 ABQ72944005 QL5 LCD COVER ASSY/STANDARD/BK/LG NLCD04 ABQ72944006 QL5 LCD COVER ASSY/STANDARD/BK/XONTE NLCD04 ABQ72944004 QL5 LCD COVER ASSY/STANDARD/WH/XNOTE...
  • Page 100 NMINI02 NMINI01 NKDECK01 NKDECK02 NRTN01 NKEYBD01...

  • Page 101: Key Deck

    Key deck Category Loc. No. LG P/N Description Remark NKEYBD01 AEW72909402 KB (USA) QL5(AEQL5U00,REV3A)CNY NKEYBD01 AEW72909401 KB (KOREA) QL5(AEQL5Y00,REV3A)CNY NKEYBD01 AEW72909408 K/B(TURKEY)QL5(AEQL5A00,REV3A)CNY NKEYBD01 AEW72909410 K/B(BRAZILIAN)QL5(AEQL5600,REV3A)CNY NKEYBD01 AEW72909404 K/B(GERMAN)QL5(AEQL5G00,REV3A)CNY Keyboard NKEYBD01 AEW72909405 K/B(FR CANADA)QL5(AEQL5K00,REV3A)CNY NKEYBD01 AEW72909407 K/B(NORDIC)QL5(AEQL5N00,REV3A)CNY NKEYBD01 AEW72909406 K/B(SPANISH)QL5(AEQL5P00,REV3A)CNY NKEYBD01...
  • Page 102 NMRY01 NMRY01 NTHMO01 NMINI04 NRBS01 NCPU01 NMINI03 NMLB01...
  • Page 103 Main Category Loc. No. LG P/N Description Remark NMLB01 EBR63154402 QL5 MB INT,GL40(A1)BT W/O CPU (DDR2) NMLB01 EBR63154502 QL5 MB INT,GL40 W/O CPU,MODEM (DDR2) NMLB01 EBR63154401 QL5 MB (INTEL,UMA) W/O CPU (DDR2) NMLB01 EBR63154501 QL5 MB (INTEL,UMA) W/O CPU,MODEM (DDR2)
  • Page 104 Main Category Loc. No. LG P/N Description Remark Racer 15 video Memory NMRY01 EAN51348902 2GB DDR3-1066MHz HYNIX refresh model application THERMAL MODULE DIS ASSY (FOX)(with Heat sink and NTHMO01 AJJ72913001 Fan)_PM THERMAL MODULE UMA ASSY (FOX)(with Heat sink and NTHMO01...
  • Page 105 NCVR02 NCVR03 NHDD02 NCVR01 NHDD01 NODD02 NHDD03 NBATT01 NODD01 NBOTM01 NBOTM02 NBOTM03...
  • Page 106 Etc. Category Loc. No. LG P/N Description Remark NODD01 EAZ57414901 ODD,Blu-ray Combo(CT10N) NODD01 EAZ49013701 ODD,DVD Rewritable(GSA-T50N) NODD01 EAZ60668201 ODD,DVD Rewritable(GT20N) NODD02 ACQ74498601 QL5 ODD BEZEL ASSY NODD02 ACQ74498603 QL5 ODD BEZEL ASSY/BK NODD02 ACQ74498602 QL5 ODD BEZEL ASSY/BLUE RAY NODD02...
  • Page 107 Etc. Category Loc. No. LG P/N Description Remark NBOTM01 AFP72919104 Case Assy Racer15 BOTTOM/White/DIS/wo RJ11 NBOTM01 AFP72919105 Case Assy Racer15 BOTTOM/BK/UMA/w RJ11 NBOTM01 AFP72919106 Case Assy Racer15 BOTTOM/BK/DIS/w RJ11 Bottom NBOTM01 AFP72919107 Case Assy Racer15 BOTTOM/BK/UMA/wo RJ11 NBOTM01 AFP72919108 Case Assy Racer15 BOTTOM/BK/DIS/wo RJ11...
