Jumper and Connector Information

M/B Placement

No Label
1 CPU socket
3 DIMM1~4
5 CMOS
Chapter 5
Description
LGA1155 socket for 2
Intel
240-pin DDR3 4
SDRAM slots
Clear CMOS header 6
No Label
CPU_FAN1
ATXPOWER
FRONT PANEL
Chapter 5
Description
CPU cooling fan
connector
Standard 24-pin ATX
power connector
Front panel switch/
LED header
