Summary of Contents for YURAKU YUR.BEAT MEDIAX
- Page 1 YUR.BEAT MEDIAX INSTRUCTION MANUAL Version: 1.00 http://www.yuraku.com.sg...
-
Page 2: Connection Diagram
CONNECTION DIAGRAM Connect to computer or USB hub Earphones USB type A interface USB eMediaX cable Mini USB interface Power On/Off switch... - Page 3 Declaration of Conformity EC-Declaration of Conformity to the essential requirements of the applicable EMC Directive 2004/108/EC We, Yuraku GmbH of Germany, declare under our sole responsibility as authorized representative that the following product Brand Name: Yuraku Model Name: YUR.BEAT MEDIAX Model No.:...
-
Page 4: Safety And Information
Safety and Information Do not violate or infringe the copyright law and other international copyright laws while using this player for recording. The copyright law forbids unauthorized reproduction of copyrighted music for any other purpose other than self-entertainment without the author’s permission. For the purpose of self-entertainment, it is strictly prohibited to compile and disseminate copyrighted music to a third party without the author’s permission. - Page 5 Do not use this player in locations whereby there are high-temperatures or high humidity levels (For instance, bathrooms); ideally, the player should be used in a location free of dust and exposure to direct sunlight. Do not insert foreign objects, such as pins, into this player. Do not touch this player when your hands are wet as this may result in electric shocks.
- Page 6 Yur.Beat MEDIAX Introduction Watch your movies and photo album while on the move with Yur.Beat MediaX portable multimedia player. Carry it in your pocket and travel with it. Enjoy digital music playbacks with support for MP3, and WMA songs. Small and compact, the Yur.Beat MediaX comes with built-in speaker and 3.5mm stereo audio output socket for earphones connection.
-
Page 7: Installation
Yur.Beat MEDIAX Installation 1. Connecting to the PC a. Connect the Yur.Beat MediaX to the computer’s USB port with the USB cable (as included in the package) b. The player will turned on automatically. An image indicating the connection will appear on the LCD screen. - Page 8 Yur.Beat MEDIAX 4. Upgrade or Recovery of Firmware Attention: Do not carry out this operation unless the MP3 player is not working, e.g., the player cannot be turned on, or when the company issues a new software version for the player.
- Page 9 Yur.Beat MEDIAX 6. Upgrading/Recovering the software of the player. a. Connect the player to the computer while pressing and holding the PLAY button; continue pressing for 5 seconds. b. Right click My computer - Properties - Device Manager, wait till the player Recovery Device Class appears in the device manager.
- Page 10 Yur.Beat MEDIAX d. Once all procedures have been completed, please follow the steps below to remove the player to avoid damaging your files. 2. Removing hardware a. Double-click on the applet that says “safely remove hardware” under the Notification area.
-
Page 11: Basic Functions
Yur.Beat MEDIAX WMA music files in “My Computer.” d. Secondly, select specific music files and click on those files with the right button of the mouse and select “Copy.” e. Next, locate the Removable Drive (F :\) in “My Computer”. After doing so, right click on the mouse to “Paste”... - Page 12 Yur.Beat MEDIAX 2. Browsing through the stored files a. Press and hold the M button. The Browse menu will appear with a list of categories such as the following: • Internal Media • External Media • Artist • Album •...
- Page 13 Yur.Beat MEDIAX 3. Operating in Music Mode Once the player is turned on, the main Music menu will appear. Press or , which is located at the left and right hand of the screen, to search for the desired track. The LCD screen will display the ID3 tag which shows the current song name, artist, total number of songs, play time of current song, etc.
- Page 14 Yur.Beat MEDIAX d. Press M to stop playing that video and to return to the VIDEO menu. e. Press the M button again to activate the main menu so as to carry out other functions. NOTE: Pressing and holding the button while the video is playing would result in the shutting down of the player.
- Page 15 Yur.Beat MEDIAX step 2.1 to browse for the recorded files under the RECORDED LIST category c. Press button to start playback. 7. Operating in Photo Mode You must create a “photos” directory in your computer before being able to copy photos that you want to display in. the player.( “JPEG” format files are supported.)
- Page 16 Yur.Beat MEDIAX storing the relevant stations with sequential channel numbers and its frequency. NOTE: All buttons will not be active until the scanning is complete. Manual scan the Channel When the player may not be able to locate the exact FM frequency that you desire, you may use this function to adjust accordingly: •...
- Page 17 Yur.Beat MEDIAX c. There are 8 sub-menus and corresponding sub-menus in the System Settings menu , which are listed as below: Contrast Select the LCD Contrast by pressing the button Brightness Select the LCD Brightness by pressing the button iii.
-
Page 18: Key Functions
Yur.Beat MEDIAX Key Functions External View of Product M – menu Play/Pause On/Off switch A/B – repeat Microphone Down Built-in speaker MicroSD slot Mini USB Lanyard loop 3.5mm stereo socket All specifications and information are subject to changes without further notice... - Page 19 Yur.Beat MEDIAX LCD Display screen All specifications and information are subject to changes without further notice...
-
Page 20: Troubleshooting
Yur.Beat MEDIAX Troubleshooting 1. Problems playing MP3/WMA files compressed by user Answer: The player supports only the standard compression mode. Thus, when user compresses MP3/WMA files, please select standard compression. 2. What is the storage capacity of the player in terms of total number of... - Page 21 Yur.Beat MEDIAX 5. Why does different music have different volumes? Answer: MP3 music has different volumes as their parameters are different. 6. No display on screen despite power being on Answer: Check if power is low. The firmware might be missing. In this case, program recovery or upgrade is necessary.
-
Page 22: Technical Specifications
Yur.Beat MEDIAX Technical Specifications • 2.2" TFT LCD screen, 262K colours • 220 x 176 pixel resolutions • Supports digital music files: MP3, WMA, and WAV formats • Supports digital video files: SMV, AVI (MPEG4) and WMV formats • Supports JPEG image file display with zoom and pan functions •... -
Page 23: Package Contents
Yur.Beat MEDIAX Package Contents • Yur.Beat MediaX • 1 pair of earphones • USB cable • CD for Windows® 98 SE driver and manual System Requirements • Intel® Pentium® III or later • 128MB of system RAM or more •...
