Summary of Contents for DLO HomeDock HD
- Page 1 ® User ManUal...
-
Page 2: Table Of Contents
In the Box setting Up HomeDock HD HomeDock HD Connections Connecting HomeDock HD Using an HDMI Cable Connecting HomeDock HD Using the Included aV Cable Connecting HomeDock HD Using an s-Video Cable Viewing the Video Content of Your iPod touch On-screen navigation... -
Page 3: Getting Started
HomeDock HD remote Control. STEP 2 - Power up Turn on your TV and select the correct input for HomeDock HD. Plugging in your HomeDock HD will turn it on and start the boot-up process, which may take a few minutes. STEP 3 –... -
Page 4: Setting Up Homedock Hd
Connecting HomeDock HD Using an HDMI Cable Plug the included aC Power adapter into the back of the HomeDock HD Base, and the other end into any available aC power outlet. Plugging in your HomeDock HD will turn it on and start the boot-up process, which may take a few minutes. -
Page 5: Connecting Homedock Hd Using The Included Av Cable
Turn on your TV and/or home stereo and then select the correct input(s) for HomeDock HD. at this time, you’ll see a screen on your TV with a DlO logo and a small box of moving squares until your HomeDock HD has finished booting up. Once complete, a “no iPod Connected” screen will appear. -
Page 6: On-Screen Navigation
On-screen navigation HomeDock HD lets you navigate and select your music, videos and more via the intuitive graphical interface. The included remote Control uses radio frequency (rF) so you can navigate your iPod and control playback from the comfort of your couch without a direct line of sight to the HomeDock HD Base. -
Page 7: Album Art And Your Homedock Hd
HomeDock HD can display album art for the track currently playing (if available) or while browsing by album. Up to 250 album art images can be held in memory by your HomeDock HD. Once that limit is reached, your HomeDock HD will delete the least-used image in order to store a new one. -
Page 8: Homedock Hd Menus
• about DlO HOMeDOCK HD User ManUal enjoying Photos + slideshows To view photos and slideshows from your photo-compatible iPod on your TV using HomeDock HD: select iPod Mode (see remote Control diagram below). ensure that “TV Out” under your iPod Photo settings is set to either remote Control’s nav arrow Buttons to make this selection. -
Page 9: Settings + Features
Cataloging album art Cataloging album art will allow HomeDock HD to retrieve album art faster during use. Due to the nature of iPod artwork, it may take several seconds for the album art to display during playback. By choosing the Cataloging option, HomeDock HD will download and store all the album artwork from your iPod library, allowing it to be displayed much faster during playback. -
Page 10: Additional Usage
TV. remember, depending on the type of cables you are using, the HomeDock HD boot-up process can take a few minutes. at this time, you’ll see a screen on your TV with a DlO logo and a small box of moving squares until your HomeDock HD has finished booting up. - Page 11 First, adjust volume for the best sound quality. If listening to your music through your HomeDock HD sounds un- usually low or noisy, be sure that your HomeDock HD’s volume is set at an adequate level. The balance of volume between your HomeDock HD and stereo/TV can affect the audio quality significantly.
-
Page 12: Tech Specs
5G iPod with video (30GB, 60GB, 80GB) Standard Def: nTsC/Pal High Def: 720p/1080i NOTE: apple iPod models listed as of October 2008 DlO HOMeDOCK HD User ManUal service + support For more information, software updates and tips, please visit our website at and click Support. www.dlo.com... -
Page 13: Warranty/Fcc Statement/Safety Instructions
HOW lOnG THIs WarranTY lasTs. retail purchase. If a defect exists, DlO will exchange the product, at its option, with a product that is new or WHaT DlO WIll DO. has been manufactured from new or serviceable used parts and that is at least functionally equivalent to the original product. -
Page 14: Safety Instructions
8. Only use attachments, accessories or cables specified by the manufacturer. (including amplifiers) that produce heat. 9. refer all servicing to DlO customer service personnel. 7. Protect the power cord from being pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. - Page 15 ™ THANkS fOR PURCHASINg HOMEDOCk HD digital lifestyle outfitters • visit us at www.dlo.com • ©2008 PhiliPs consumer lifestyle...
