Chapter 2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - How it works - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Chapter 2
Accounting
Enable this option to have the WAP-200 generate a RADIUS accounting request ON/
OFF for each user authentication. The WAP-200 respects the RADIUS interim-update-
interval attribute if present inside the RADIUS access accept of the authentication.

Location-aware

Note: Location-aware is only available if Use Colubris access controller is enabled
under General.
This feature enables you to control logins to the public access network based on the
wireless access point to which a customer is connected. For details see the
documentation that came with the access controller you are using.
Group name
Specify a group name for the access point. You can assign the same group name to
more than one access point.
The WAP-200 returns the value you specify in all Access Requests as a Colubris
Networks Vendor-Specific Attribute identified with the string "group".
Address list
Construct a list of MAC addresses to either Allow or Block by entering the MAC
address and clicking either Remove or Add.

MAC filter

Note: The MAC filter option is not available if Use Colubris access controller is
enabled under General.
When enabled, this option enables you to control access to the WAP-200 based on the
MAC address of client stations. You can either block access or allow access, depending
on your requirements.
Note: When both the MAC filter option and the MAC-based authentication options
are enabled, if a customer's MAC address does not appear in the MAC filtering list,
MAC-based authentication is used for that customer.
Specify the MAC address as six pairs of hexadecimal digits separated by colons. For
example: 00:03:52:0a:0f:01.
Filter behavior
• Allow: Only client stations whose MAC addresses appear in the MAC address list can
• Block: All client stations whose MAC addresses appear in the MAC address list are
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 36 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
connect to the wireless network.
blocked from accessing the wireless network.
