TP-Link TL-WN751ND Quick Installation Manual

Quick Installation Guide

150Mbps Wireless N PCI Adapter
TL-WN751ND
MODEL NO.
2

Software Installation

1 Insert the TP-LINK Resource CD into the CD-ROM
drive.
Find the appropriate model and choose
2
Install Driver&Utility.
7106503554

Package Contents

TL-WN751ND
Resource CD
System Requirement
· Windows 7 · Windows Vista · Windows XP
(The installtion procedures in Windows 7/ Vista/ XP are similar. Here takes the procedures in Windows 7 for example.)
The InstallShield Wizard window will appear.
3
Click Next to continue.
Select Install TP-LINK Wireless Con guration
4
Utility and Driver and then click Next .
1

Hardware Connection

150Mbps Wireless Lite N PCI Adapter
MODEL NO. TL-WN751ND
QIG
Steps
1. Turn o your computer and unplug the power cord from the computer.
2. Open the case. Locate an available PCI slot and remove its slot cover.
Keep the screw.
3. Insert the adapter into the PCI slot as shown above.
4. Secure the adapter with the screw removed in Step 2.
5. Close the case and insert the power cable back into the computer.
6. Turn on your computer.
Click Change to specify the destination location
5
or you can leave it default. Click Next to continue.
Click Install to install the driver and utility for your
6
adapter.
You may see the Found New Hardware Wizard after the
adapter has been inserted. Please click 'Cancel'.
For Windows XP
For Windows Vista
7 The drivers and utility will install. This may take
1~2 minutes.
The follwing screen will then appear.
8
Click Finish to complete the setup.
