TiffMaker
User's Guide

Advertisement

Table of Contents
loading

Related Manuals for Muratec TIFFMAKER

Summary of Contents for Muratec TIFFMAKER

  • Page 1 TiffMaker User’s Guide...

  • Page 2: Table Of Contents

    Using your Muratec Internet Fax as a PC Printer ......10 Using your Muratec Internet Fax as a PC-Fax .......11...

  • Page 3: Introduction

    TiffMaker is a print driver that converts files into Tagged Image File Format (TIFF) from your software application. For example, if you send a TIFF file converted by TiffMaker to the Muratec Internet Fax via e-mail, you can use the Muratec Internet Fax machine as a PC printer. Also, by using the e-mail forwarding feature on the Muratec Internet Fax machine, you can send your electronic document to a remote fax machine without printing.

  • Page 4: Installing The Tiffmaker

    Carefully reveiw the end user license agreement. Then click Yes if you agree. Choose the directory in which you want to install TiffMaker. To install it in a directory otherthan the default directory, click Browse and locate the directory of your choice. If a directory does not exist, the installer will create onefor you.
  • Page 5 The installer has collected the necessary information and is ready to begin installation. Click Next. The installer will begin to copy files to your computer. Select “Yes, I want to restart my computer now”, and then click Finish. After rebooting your computer, you must install the print driver as instucted below. Note: The following example is for Windows 2000 users.
  • Page 6 Select “Local printer attached to this computer”, then click Next. Note: Check off the “Automatically detect and install my Plug and Play printer.” Select “Muratec TiffMaker Port” as your printer port, then click Next. When the Install Printer Software screen appears, click Have Disk.
  • Page 7 Locate the directory in which you saved the downloaded TiffMaker installer file. You will find the Driver folder in that directory. If your Windows version is Windows 95, 98 or Me, click on the Win9x folder and then click Open.
  • Page 8 Set “Muratec OfficeBridge TiffMaker” as the printer name, then click Next. When the Printer Sharing screen appears, select “Do not share this printer” and click Next. When the Printer Test Page screen appears, select “No” and click Next.
  • Page 9 Click Finish to complete the installation. Note: In Windows ® 2000, the following display may appear on your screen. However, since there is not a functionality problem, click Yes to continue installing.

  • Page 10: Converting An Electronic File To Tiff

    TiffMaker will ask you where to place the TIFF file. Select the desired location and enter the file name, then click Save. Note: By default, TiffMaker will append the extension “.tif” and place the file into the PRINT folder under Muratec TiffMaker folder.

  • Page 11: Important Features Using Your Tiffmaker And E-Mail Software

    Note: To use these features, both the TiffMaker and e-mail software must be installed on your computer. Using your Muratec Internet Fax as a PC Printer By sending a TIFF file that has been converted by the TiffMaker to the Muratec Internet Fax via e-mail, you can utilize the Muratec Internet Fax as a PC printer.

  • Page 12: Using Your Muratec Internet Fax As A Pc-Fax

    Using your Muratec Internet Fax as a PC-Fax The Muratec Internet Fax can forward received e-mail to other fax machine(s) whose fax numbers have been designated in the e-mail text. By using this feature with TiffMaker, you can send documents to other fax machine(s) without using paper.

  • Page 13: Uninstalling The Tiffmaker

    Uninstalling the TiffMaker Open the Printers window. Right click on the Muratec OfficeBridge TiffMaker, and click Delete. After deleting the “Muratec OfficeBridge TiffMaker” fromthe Printers window, open the “Add/Remove Programs” window from the Control Panel. Select “OfficeBridge TiffMaker” and click Change/Remove.
